Mitel S720 Quick Start Manual

Quick Start Guide
Q
Mitel S720 Bluetooth Speakerphone
Congratulations on your purchase of the Mitel
Speakerphone. The Mitel S720 Bluetooth Speakerphone is
supported with the Mitel MiVoice 6930 and 6940 IP phones that
allows you to instantly transform any room into a conference room.
You can easily connect and enjoy the crystal clear HD audio, while
maximizing productivity during conference calls through this
premium portable and easy-to-use Bluetooth speakerphone.

Features

• HD voice audio
• Omni directional microphone
• Functionally integrated with desk phone - volume / mute sync,
pulling call to / from conference phone
• Connect two speakerphones wirelessly to extend speakerphone
range and for stereo music playback
• Play smartphone audio from mobile with auto pause when in-
coming call to desk phone
• Intuitive connectivity through Bluetooth®
• Portable design, protective travel pouch, and battery powered
with USB charging (15 hours of talk time)
• Flexible and scalable for office side tables and small meeting
rooms

How to use

Bluetooth Button Mute Button
Volume
Down
Link
Button
Answer Call Power On/Off
Button Description
Turns on or off.
Answers a call.
Ends or rejects a call.
Hold (8 secs) to turn on or off
voice guidance.
Increases or descreases the volume.
® S720 Bluetooth
Battery Status
Button
Volume
Up
Smart
Button
End Call
Mutes the microphone.
Shows the battery status.
Connects to a Bluetooth device.
Links two speakerphones.
Turns on or off the voice assistant application on your
smartphone.
The buttons are backlit and only visible when the speakerphone is
powered on. After one minute of inactivity the buttons will fade, and
can be reactivated by tapping the area where the buttons are located.
The button, button, and
certain conditions (that is, the
speakerphone is in close proximity to another speakerphone).

Pairing to the Mitel MiVoice 6930 IP phone

2 seconds 10 m/30 ft
To pair the Mitel S720 Bluetooth Speakerphone to the Mitel MiVoice
6930 IP phone:
1. Press the key on the IP phone to enter the Settings
menu.
2. Navigate to the Bluetooth menu and press the Select button or
Select softkey.
3. Ensure Bluetooth functionality is enabled. If it is not enabled,
press the Turn On softkey to enable Bluetooth functionality.
4. Press and hold the Bluetooth button on the speakerphone (the
voice prompt directs you to go to the Bluetooth menu on your
device).
5. Press the down navigation key to view the list of Available
Devices.
6. Press the right navigation key to move to the Bluetooth device
selection column.
7. Using the up and down navigation keys, select S720 BT Speak-
erphone and press the Pair softkey. The phone pairs the
speakerphone and automatically connects it.
8. Press OK to acknowledge the successful connection. The MWI
indicator flashes blue and the speakerphone announces "Device
button will only be visible under
button is only visible when the
