Keyboard/Mouse P/S2 Connector for the CPV5370 and
CPTM04 Modules
Table 4-6. Keyboard/Mouse P/S2 Connector Pin Assignments for the
1
2
http://www.motorola.com/computer/literature
Solution Systems Technologies Inc.
720-565-5995 | info@solusys.com | www.solusys.com
CPV5370 (J7) and CPTM04 (J24) Modules
Pin Signal
Number Mnemonic
1 KBDDAT
2 MDAT
(AUXDAT)
3 GND
4 KBDVCC
5 KBDCLK
6 MCLK
(AUXCLK)
7 CGND
AUXDAT is Data line for mouse for the CPTM04
AUXCLK is Clock for mouse for the CPTM04
720-565-5995 | info@solusys.com | www.solusys.com
Signal Description
Data line for keyboard
Data line for mouse
1
Keyboard Ground
Keyboard Power
Clock for keyboard
Clock for mouse
2
Common Ground
