IRQSL0 (Bit 0), IRQSL1 (Bit 1), IRQSL2 (Bit 2) and IRQSL3 (Bit 3)
These bits determine which IRQ is driven when an IRQ event triggers.
Refer to Table 3-12.

Table 3-12. Bit values for determining driven IRQ lines

Interrupt Line
No IRQ Selected
No IRQ Selected
No IRQ Selected
No IRQ Selected
No IRQ Selected
Select IRQ5
No IRQ Selected
Select IRQ7
No IRQ Selected
Select IRQ9
Select IRQ10
Select IRQ11
No IRQ Selected
No IRQ Selected
No IRQ Selected
No IRQ Selected
720-565-5995 | info@solusys.com | www.solusys.com
IRQSEL3 IRQSEL2
0 0
0 0
0 0
0 0
0 1
0 1
0 1
0 1
1 0
1 0
1 0
1 0
1 1
1 1
1 1
1 1
Computer Group Literature Center Web Site
IRQSEL1 IRQSEL0
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
