Connector Pin Assignments
EIDE Connector for the CPTM04 Transition Module
Table 4-10. EIDE Connector Pin Assignments for the CPTM04 Transition Module
Pin Signal
Number Mnemonic
1 RESET-
3 DD7
5 DD6
4
7 DD5
9 DD4
11 DD3
13 DD2
15 DD1
17 DD0
19 GND
21 DMARQ
23 IOW-
25 IOR-
27 IORDY
29 DMACK-
31 INTRQ
33 DA1
35 DA0
37 CS1-
39 DASP-
4-10
Solution Systems Technologies Inc.
720-565-5995 | info@solusys.com | www.solusys.com
Signal Description
Reset signal to drive
Drive data line
Drive data line
Drive data line
Drive data line
Drive data line
Drive data line
Drive data line
Drive data line
Drive data line
Drive DMA request
Drive I/O write
Drive I/O read
Drive is ready for I/O
cycle(s)
Drive DMA acknowledge
Drive interrupt request
Drive register and data
port address line
Drive register and data
port address line
Chip select drive 0, also
command register block
select
Drive active/slave present
720-565-5995 | info@solusys.com | www.solusys.com
Pin Signal
Number Mnemonic
2 GND
4 DD8
6 DD9
8 DD10
10 DD11
12 DD12
14 DD13
16 DD14
18 DD15
20 -
22 GND
24 GND
26 GND
28 CSEL-
30 GND
32 IOCS16-
34 PDIAG-
36 DA2
38 CS3-
40 GND
