Table 4-19. Signal Descriptions for the CPV5370 Single Board Computer

Signal
Ethernet
Video Signal
4
Definitions
General
Hot Swap Control
Signals
PMC2 I/O
4-20
Solution Systems Technologies Inc.
720-565-5995 | info@solusys.com | www.solusys.com
Backplane Connector (J3)
Signal
Mnemonic
RD+, RD- Differential receive lines
TD+, TD- Differential transmit lines
V_RED Red signal
V_GREEN Green signal
V_BLU Blue signal
V_HSYNC Horizontal synchronization
V_VSYNC Vertical synchronization
VDDCCLK Display Data Channel clock signal for DDC2
support
VDDCDAT Display Data Channel data signal for DDC2 support
GND Ground plane
VCC-12 -12Vdc power
VCC5 5Vdc power
VCC3.3 3.3Vdc power
HS_REQ Hot Swap Request
HS_GNT Hot Swap Grant
HS_FLT Hot Swap Float
HS_EJ Hot Swap Eject
PMC [1 to 64] PMC I/O signals 1 through 64
