Video Connector for the CPV5370 (J17) and CPTM04 (J20)
Modules

Table 4-5. Video Connector Pin Assignments for the CPV5370 (J17) and

Pin
Number
1
4
2
3
4
5
6
7
8
9
10
11
12
13
14
15
4-6
Solution Systems Technologies Inc.
720-565-5995 | info@solusys.com | www.solusys.com
CPTM04 (J20) Modules
Signal
Mnemonic
RED Red signal
GREEN Green signal
BLUE Blue signal
NC no connection
DACVSS Video return
DACVSS Video return
DACVSS Video return
DACVSS Video return
NC no connection
DACVSS Video return
NC no connection
DDCDAT Display Data Channel data signal for DDC2 support
HSYNC Horizontal synchronization
VSYNC Vertical synchronization
DDCCLK Display Data Channel clock signal for DDC2 support
