Table 4-4. Serial Port Connector Pin Assignments for the CPTM04
Pin Signal
Number Mnemonic
1 DCD
3 RX
5 TX
7 DTR
8 GND
http://www.motorola.com/computer/literature
Solution Systems Technologies Inc.
720-565-5995 | info@solusys.com | www.solusys.com
Transition Module (COM1)
Signal Description
Number
Data set has detected
the data carrier
Receives serial data
input from
communication link
Sends serial data to
communication link
Data set is ready to
establish a
communication link
Ground
720-565-5995 | info@solusys.com | www.solusys.com
Pin Signal
Mnemonic
2 DSR Data set is ready to
establish a
communications
link
4 RTS UART is ready to
exchange data
6 CTS Data set is ready to
exchange data
8 RI Modem has
received a
telephone ringing
signal
10 GND Ground
Signal
Description
4-5
