DV-1394 connections
The following illustration shows how to connect your DV-1394 device to your
Matrox RT.X2 system. For other typical connections, see your Matrox RT.X2
Installation Manual.
DV-1394 device
DVI monitor
To DVI connector
on RT.X2 card
(not available on
RT.X2 LE/SD)
To RT.X2 card
Computer speakers
Connecting your external devices
5
To AUDIO
connector on
RT.X2 card
