- Page 1 ® Einstart -C User Manual ® Einstart USER MANUAL HANGZHOU SHINING3D TECH CO., LTD. STOCK CODE：830978 Website：www.shining3d.com Add: NO.1398 XIANGBIN RD. WENYAN XIAOSHAN, HANGZHOU, 311258, CHINA www.3dker.cn...
-
Page 2: Table Of Contents
® Einstart -C User Manual CATALOG 1 Summary ..............................1 1.1 How to use the User Manual ......................1 1.2 Attention ............................1 1.3 Product Model ..........................1 2 Product Introduction ..........................2 2.1 Product Appearance ........................2 2.2 Device parameters and accessories ..................... 2 2.3 Sound illustration .......................... - Page 3 ® Einstart -C User Manual 7.6 Set the Print Bed ......................... 23 7.7 Sliding Rail ..........................23 7.8 Consumable Parts List ........................ 23 8 FAQ ............................... 24 8.1. The filament is blocked ......................24 8.2. Extruder height adjustment ......................24 8.3.
-
Page 4: Summary
The printer operates at a room temperature of 5℃ to 30 ℃. Print quality may be affected if the temperature is not in this range. Shining 3D has no responsibility for any damage caused to the printer through using print material or a power supply not offered by Shining 3D. -
Page 5: Product Introduction
® Einstart -C User Manual 2 Product Introduction The Einstart®-C 3D printer is easy to operate and maintain. Its basic principle is that, upon digital input, plastic is heated, melted and deposited to form the desired 3D model. The design is built up layer upon layer with each successful layer turning solid to give a finished printed model that is sturdy and durable. -
Page 6: Preparation
® Einstart -C User Manual 3 Preparation 3.1 Hardware Installation 3.1.1 Remove the package Unpack the inner and outer packaging and remove the cushioning foam. Use this manual and technical drawings above to learn about accessories and set-up. 3.1.2 Print bed installation Remove the print bed, open the printer door and fit it to the platform holder. - Page 7 ® Einstart -C User Manual 3.2.1 Software Installation and Registration for Windows OS. 3.2.1.1 Steps: Open the file folder in the USB drive or download the installation software from our website. Find the Setup.exe and run it. Click “Next” to enter the below interface and click “I Agree” after reading and accepting the 3DPRINT END USER LICENSE AGREEMENT.
- Page 8 ® Einstart -C User Manual Note: If you’ve installed “Microsoft Visual C++ 2013”, just click “Repair” as below picture shows. Install the FTDI CDM Drivers. Click “Extract” and operate according to the guidance given until installation is complete.
-
Page 9: Using The Printer
® Einstart -C User Manual 4 Using the Printer To obtain model data, please refer to charter 5.1 . There are also some 3D files available on the USB drive provided. 4.1 Slicing 4.1.1 For slicing, open the 3dStar software and choose corresponding device model in “setting”, “Application”. - Page 10 ® Einstart -C User Manual 4.1.3 The 3dStar software allows users to view, move, rotate and scale their 3D model according to requirements. To zoom in and out, use the scroll wheel on the mouse. To rotate around your model, left-click and drag.
-
Page 11: Print
® Einstart -C User Manual 4.1.5 The sliced file is stored in the same folder as the original STL file. Copy the GSD file on to USB flash drive. Note: When saving your file, the file name should avoid special characters and contain English characters and numbers only. -
Page 12: Software
® Einstart -C User Manual 5 Software 5.1 A detailed look at the software interface Model saving path: After 3dStar loads the model, you can see the model stored location in this area. Additionally, the sliced data path for printing will be stored in the same location. Menu：The menu of 3dStar contains File, Edit, View, Print, Tools and Help. -
Page 13: Software Functions
® Einstart -C User Manual 5.2 Software functions Positio Legend Submenu Description Software Clear current model Open… Open local STL file Add… Add new model to current Menu- Recent Files model Link to recently opened files File Save Save current model Save current model as other Save As position... - Page 14 ® Einstart -C User Manual Building Check the status of current Status print Generate Slice current model Path generate path Select Select online machine Machine Machine Calibrate the machine Calibration Firmware Detect firmware update Update Manager for Manage local STL file STL File Menu- Manager for...
-
Page 15: Advanced Parameters
® Einstart -C User Manual 5.3 Advanced Parameters 5.3.1 Path Generator The use of “basic setting” is normally sufficient. We suggest you generate path with our default parameters since improper changes could lead to print failure or extruder blockage. 5.3.1.1 Print Mode Simple: 0.4mm layer thickness；... -
Page 16: Introduction Of Led Screen Button And Its Logic
® Einstart -C User Manual Full Support：Both outer and inner support when generating path. “Inner Support” means support is created on the model surface. Add Raft: When generating path, the software will generate a raft for your model, which can secure the model effectively and compensate height variance. - Page 17 ® Einstart -C User Manual Searching for available WIFI Skip WIFI or trying to connect to the Skip to 4 Checking automatically WIFI used previously. Refresh the list A list of available WIFI is generated. Scroll using the WIFI List arrows“...
- Page 18 ® Einstart -C User Manual Firmware The printer is checking Skip Skip to 9 updates that the firmware is up to date. automatically The printer updates firmware automatically if it detects updates are available. Updating Skip DO NOT turn off the printer Skip to 10 page automatically...
- Page 19 ® Einstart -C User Manual Local default model Skip to 11 Skip to 17 or 18 Printing Select a model file for Confirma-- Skip to 24 printing. tion Skip to 12 Select any model When the USB drive is Skip to 16 in the list USB drive plugged in, this interface will...
- Page 20 ® Einstart -C User Manual during bed level checking. Skip to 14 Skip Skip to 20 Printer automatically Displayed during the print Heating head heating process. Skip to 14 If an error occurs during Bed Error bed auto leveling , this display Skip to 17 will be seen.
- Page 21 ® Einstart -C User Manual Skip to 26 Filament Manage filament, you can Skip to 26 Managem select to load or unload filament here. Skip to 11 Skip Printer This display can be seen Skip to 27 or 28 automatically Heating during the print head heating process.
- Page 22 ® Einstart -C User Manual Skip to 32 Skip to 33 Skip to 34 Skip to 36 Skip to 37 Currently Select Settings on the Nonfictional Settings HOME page to change various parameters. Mute or not Unlock door Currently Nonfictional Skip to last page or 11 To next page...
- Page 23 ® Einstart -C User Manual Skip to 30 Skip to 8 About Firmware/software Printer version and total printing time. Skip to 30 Skip to 35 34 Preheat A Allows user to preheat. Skip to 30 Change target temp Preheat temperature Save target 35 Preheat B setting.
- Page 24 ® Einstart -C User Manual Touch Relocate touch screen Skip screen Skip to 10 area. automatically locate...
-
Page 25: 3Dker Platform（Website Address：http://Www.3Dker.com
® Einstart -C User Manual 6 3Dker Platform（Website address：http://www.3dker.com/） 6.1 Model Downloading Visit the 3Dker platform where you can find and download 3D model data designed by other users or designers. 6.2 Software and Firmware Down loading. Click “Tools” in the top menu to enter downloading page and select “3D printer”. Scroll down the page and download the newest software, firmware and user manual on the below page. -
Page 26: Maintenance
® Einstart -C User Manual 7 Maintenance 7.1 Printer Working Environment Make sure the printer is set on a stable flat surface. Do not interfere with moving parts during the printing process. Please hold the print bed securely when turning the printer off in the occurrence the bed drops with loss of power. -
Page 27: Faq
® Einstart -C User Manual Heat rod 3 months Thermistor 3 months 8 FAQ 8.1. The filament is blocked Problem: A skipping sound is heard during printing or the loading of filament. Solution: First, unload the filament and ensure the tip is even before reloading. If this does not solve the problem, please take apart the extruder and clean. -
Page 28: 3Dstar Software Cannot Connect To The 3D Printer
® Einstart -C User Manual refer to the video or document instruction named “Clean nozzle”.). Reason: The filament has failed to stick to the model or platform and as such has gathered round the nozzle. 8.5. 3dStar software cannot connect to the 3D printer. Problem: Error message indicating lack of connection to the printer or printer not registered. -
Page 29: Appendix
® Einstart -C User Manual Appendix： 1. List of Product and Accessories Einstart®-C Einstart®-C 3d Printer 1 unit Power Supply(Output 19V/4.95A） 1 PCS USB cable 1 PCS Bowden tube 1 PCS 3D printing Material 2 reels Print bed 1 PCS USB flash drive (4G) 1 PCS... - Page 30 ® Einstart -C User Manual Scraper 1 PCS User manual 1 PCS Handy tool 1 PCS...
- Page 31 ® Einstart -C User Manual 2. Parameter of the Printer...
- Page 32 ® Einstart -C User Manual FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 33 ® Einstart -C User Manual More information please join our WeChat by scanning below QR code Company Desktop 3D printer department 3Dker Hangzhou Shining3D Tech Co., Ltd. Add: NO.1398 XIANGBIN RD. WENYAN XIAOSHAN, HANGZHOU , 311258, P.R. CHINA Zip code： 311258 Working time：8:30-17：30 Tel：0571-83821911 Tax：0571-82999510...
- Page 34 This document is copyrighted and contains proprietary information that is the property of Hangzhou Shining 3D Tech Co., Ltd. The user does not have the right to copy, reproduce, or translate this document in any way or to any media without the prior written consent of Hangzhou Shining 3D Tech Co., Ltd.
