- Page 1 110 SERIES COMPACT NETWORK SWITCHES Quick Start Guide AN-110-SW-C-5P AN-110-SW-C-8P AN-110-SW-C-16P...
-
Page 3: Fcc Warning
Operations of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. © 2017 Araknis Networks®... - Page 4 110 Series Compact Network Switches Quick Start Guide CE Warning This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. UL Statement All models have been evaluated by UL.
- Page 5 Quick Start Guide Welcome to Araknis Networks™ Thank you for choosing an Araknis 110-series Compact Network Switch. This PoE-powered switch features Gigabit connectivity on all ports, updated modern aesthetics, and a level of control (Unmanaged+) rarely seen in unmanaged solutions. The Araknis 110-series switch is a sleek and highly capable addition to any network.
- Page 6 110 Series Compact Network Switches Quick Start Guide Step 1: Unbox Switch Rubber Feet (4) Structured Wiring Spare Can Mounting Can Mounting Kit Push Pins (4) w/ Push Pins (2) Body: 8.5mm(D), 10.4mm(L), 6.35mm(W) Pin: 8.5mm(D), 18.2mm(L), 3.7mm(W) Quick Start Guide VersaBox Shelf Wall Mount Kit Power Supply...
- Page 7 Quick Start Guide Step 2: Install 110 compact switches feature several mounting options for easy setup in any scenario. See the following pages for specific instructions. Shelf Wall Structured Wiring Can Strong™ VersaBox™ (use included rubber feet) Shelf © 2017 Araknis Networks®...
- Page 8 110 Series Compact Network Switches Quick Start Guide Structured Wiring Can Installation NOTE: The switch may only be mounted to the structured wiring can with the Ethernet ports facing right or left.
- Page 9 110 Series Compact Network Switches Quick Start Guide Strong™ VersaBox™ Shelf Installation NOTE: 5 and 8-port models may be positioned with the Ethernet ports facing any direction. 16-port models fit only as shown. © 2017 Araknis Networks®...
- Page 10 110 Series Compact Network Switches Quick Start Guide Step 3: Connect The switch may be powered using either PoE or optional power supply (AN-ACC-PS-48V1A), sold separately. PoE OUT port functionality varies depending on model and power input type. PoE+ IN (30W) PoE IN (15W) PoE+ 802.3at IN (30W) PoE 802.3af IN (15W)
-
Page 11: Poe Specifications
Full load w/o 4.7W 11.22W PoE Out Full load with 23.20W 24.4W PoE Out (max) NOTE: 100m PoE output distance guaranteed only when pow- PoE Specification – PoE Out Port Max Output: 15.4W ered by DC adapter. © 2017 Araknis Networks®... - Page 12 110 Series Compact Network Switches Quick Start Guide Step 4: Verify Power LED – On: system is up. Off: system is down. 1Gbps LED – On: port connected at 1Gbps speed. Off: port is connected at 10/100Mbps speed. Link/Act LED – On: port is connected to another device. Blinking: packets are running through the port.
- Page 13 Connect the switch to the network (Internet access required). Log Into OvrC (www.ovrc.com) or load the OvrC app. Add the device (MAC address and Service Tag numbers needed for authentication). Web Browser Access 1 Gbps Link/Act ENABLED AN-110-SW-R-8 Mobile Apps © 2017 Araknis Networks®...
- Page 14 110 Series Compact Network Switches Quick Start Guide Pro Tip: Rebooting the Switch ACTIVE PoE/+ 15W OUT 30W IN Reboot – Press and hold the RESET button on the back of the switch for 5 seconds, then release. The switch will power cycle and the front status lights will flash.
-
Page 16: Year Limited Warranty
2-Year Limited Warranty Araknis Networks® products have a 2-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products that have been abused, modified, or disassembled. Products to be repaired under this warranty must be returned to a designated service center with prior notification and an assigned return authorization (RA) number.
