Operator's Manual
Controls
1
Platform Control Panel
1 Horn button
2 Platform level switch
3 Platform rotate switch
4 Jib boom up/down switch
5 Auxiliary power switch
6 Drive speed select switch
7 Glow plug switch (option)
18
2
3
20
8 Engine start switch
9 Engine idle (rpm) control switch
10 Gasoline/LPG models: Gasoline/LPG
11 Red Emergency Stop button
Z-60/34
Seventh Edition · First Printing
4
18
19
- Turtle symbol: low idle
- Rabbit symbol: high idle
select switch
5
6
17
Part No. 133083
