INSTALLATION
INSTRUCTIONS
C
ommerCial
TABLE OF CONTENTS
Washer Safety .......................................................................... 2
Tools & Parts ............................................................................ 3
Dimensions .............................................................................. 4
Location Requirements ........................................................... 5
Installation instructions .......................................................... 6
Level Washer ............................................................................ 7
Connect Drain Hose ................................................................ 8
Drain System ............................................................................ 9
Connect Inlet Hoses .............................................................. 10
Electrical Requirements........................................................ 11
Complete Installation ............................................................ 12
Installing Coin Slide and Coin Box ....................................... 12
Typical Full Load Sizes .......................................................... 12
Washer Maintenance............................................................. 13
If You Need Assistance ......................................................... 14
Alternate Parts & Accessories ............................................. 14
Electronic Controls Set-Up Instructions ............................. 15
Warranty ................................................................................. 19
W10837721A
W10861220A - SP
W
asher
Page
INSTRUCTIONS
D'INSTALLATION
l
aveuse CommerCiale
TABLE DES MATIÈRES
Sécurité de la laveuse ........................................................... 20
Outillage et pièces ................................................................. 21
Dimensions ............................................................................ 22
Exigences d'emplacement ................................................... 23
Instructions d'installation ..................................................... 24
Établissement de l'aplomb de la laveuse ............................ 25
Raccordement du tuyau de vidange .................................... 26
Système de vidange .............................................................. 27
Raccordement des tuyaux d'arrivée d'eau ......................... 28
Spécifications électriques .................................................... 29
Achever l'installation ............................................................. 30
Installation de la glissière et de la boîte à monnaie ........... 30
Taille typique des charges complètes ................................. 30
Entretien de la laveuse .......................................................... 31
Si vous avez besoin d'assistance ........................................ 32
Pièces supplémentaires et accessoires .............................. 32
Instructions de paramétrage des commandes
électroniques ......................................................................... 33
Garantie .................................................................................. 40
www.maytagcommerciallaundry.com
Page
Advertisement
Table of Contents
Related Manuals for Maytag W10837721A
Summary of Contents for Maytag W10837721A
-
Page 1: Table Of Contents
Si vous avez besoin d’assistance ........32 Alternate Parts & Accessories ..........14 Pièces supplémentaires et accessoires ......32 Electronic Controls Set-Up Instructions ......15 Instructions de paramétrage des commandes électroniques ................. 33 Warranty ................. 19 Garantie .................. 40 W10837721A W10861220A – SP www.maytagcommerciallaundry.com... -
Page 2: Washer Safety
WASHER SAFETY... -
Page 3: Tools & Parts
TOOLS & PARTS Tools Needed: Level Pliers Utility Knife 9/16" (14 mm) Flat-Blade Screwdriver Open-End Wrench Optional tools: Flashlight Bucket Parts Supplied: Drain Hose with Clamp, Water Inlet Hoses (2) Inlet Hose Washers (4) U-Form, and Cable Tie... -
Page 4: Dimensions
DIMENSIONS Front View Side View 27" (686 mm) Non-coin-operated models: ⁄ " " (159 mm) (210 mm) Coin-operated models: ⁄ " (210 mm) " " (1.080 m) (921 mm) 1" (25 mm) Back View Non-coin-operated models Coin-operated models 16" 16" (406 mm) (406 mm) "... -
Page 5: Location Requirements
LOCATION REQUIREMENTS Selecting the proper location for your washer improves Recessed Area or Closet Installation performance and minimizes noise and possible washer “walk.” This washer may be installed in a recessed area or closet. Your washer can be installed in a basement, laundry room, or The installation dimensions shown are the minimum spaces recessed area. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS 3. Remove tape from washer lid, open lid, and remove cardboard packing tray from tub. Be sure to remove all parts from tray. NOTE: Keep tray in case you need to move washer later. It is necessary to remove all shipping materials for proper operation and to avoid excessive noise from washer. -
Page 7: Level Washer
LEVEL WASHER IMPORTANT: Level washer properly to reduce excess noise HELPFUL TIP: You may want to prop up front of washer about and vibration. 4" (102 mm) with a wood block or similar object that will support weight of washer. Jam nut Jam nut 1. -
Page 8: Connect Drain Hose
CONNECT DRAIN HOSE Proper routing of the drain hose avoids damage to your floor 5. Place hose into standpipe (shown in picture) or over side due to water leakage. of laundry tub. Remove drain hose from the washer basket IMPORTANT: D rain hose is not to exceed 8"... -
Page 9: Drain System
DRAIN SYSTEM Floor drain system Drain system can be installed using a floor drain, wall standpipe, floor standpipe, or laundry tub. Select method you need. Floor standpipe drain system 39" (990 mm) 8" (203 mm) Floor drain system requires a Siphon Break Kit (Part Number 285320). -
Page 10: Connect Inlet Hoses
CONNECT INLET HOSES Connect Inlet Hoses to Washer Insert new hose washers (supplied) into each end of the inlet hoses. Firmly seat the washers in the couplings. 1. Attach cold water hose to cold water inlet valve marked with a blue ring. Screw coupling by hand until it is snug. Washer Coupling Connect Inlet Hoses to Water Faucets... -
Page 11: Electrical Requirements
ELECTRICAL REQUIREMENTS A 120-volt, 60 Hz., AC-only, 15- or 20-amp, fused electrical supply is required. A time-delay fuse or circuit breaker is recommended. It is recommended that a separate circuit breaker serving only this appliance be provided. This washer is equipped with a power supply cord having a 3 prong grounding plug. -
Page 12: Complete Installation
COMPLETE INSTALLATION Check that all parts are now installed. If there is an extra part, go back through steps to see what was skipped. Check that you have all of your tools. Check that shipping materials were completely removed from washer. Dispose of/recycle all packaging materials. -
Page 13: Washer Maintenance
WASHER MAINTENANCE Transporting Your Washer Operating Tips Shut off both water faucets. Disconnect and drain water inlet hoses. Disconnect drain from drain system and drain any remaining water into a pan or bucket. Disconnect drain hose from back of washer. Unplug power cord. -
Page 14: If You Need Assistance
IF YOU NEED ASSISTANCE Contact your authorized Commercial Laundry distributor. To locate your authorized Commercial Laundry distributor, or for web inquiries, visit www.MaytagCommercialLaundry.com. If you cannot locate your distributor, the Commercial Laundry Support Center will answer any questions about operating or maintaining your washer not covered in the Installation Instructions. -
Page 15: Electronic Controls Set-Up Instructions
ELECTRONIC CONTROLS SET-UP INSTRUCTIONS Basic Operation of Commercial Washer Free Cycles This is established by setting the cycle price to zero. When this For additional information, see www.MaytagCommercialLaundry.com. happens, ‘SELECT CYCLE’ will appear and cycle price will show 0.00. Debit Card Ready This washer is debit card ‘cable’... - Page 16 ELECTRONIC CONTROLS SET-UP INSTRUCTIONS Control Set-Up Procedures CODE EXPLANATION IMPORTANT: Read all instructions before operating. 6.07 NORMAL ECO Regular Cycle Vend Price - Increase or The lower fabric setting key pads and the digital display are NORMAL decrease between 0 and 200 by pressing the POWERWASH or used to set up the controls.
- Page 17 ELECTRONIC CONTROLS SET-UP INSTRUCTIONS CODE EXPLANATION CODE EXPLANATION OPTIONS TO USE IF SPECIAL PRICING IS SELECTED: g Press the MIXED key pad once to advance to next code. 3.07 DELICATES Special Cycle Vend Price - Increase or decrease A.00 VAULT VIEWING OPTION between 0 and 200 by pressing the POWERWASH or DELICATES This option is either SELECTED ‘ON’...
- Page 18 ELECTRONIC CONTROLS SET-UP INSTRUCTIONS If cycle counter (9.0C) is selected, the following is true: CODE EXPLANATION 1 xx Number of cycles in THOUSANDS. 1 02 = 2,000 H.01 HEAVY SOIL LEVEL Upgrade Price - Increase or decrease between 2xxx Number of cycles in ONES. 2225 = HEAVY 0 and 200 by pressing the POWERWASH or TEMPERATURE key...
-
Page 19: Warranty
DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY Maytag makes no representations about the quality, durability, or need for service or repair of this major appliance other than the representations contained in this Warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes with this major appliance, you should ask Maytag or your retailer about buying an extended warranty.
