Wireless Base Stations
▫
Surveillance Cameras
▫
Remote Gate Control
▫
Electric Fence
▫
Up to 120W loads
▫
Congratulations! on your purchase of the UPSPro™ outdoor
backup power system. Please take a moment to review this Qwik
Install Guide before assembly or battery installation.
When following the instructions in this guide take extreme care
to avoid contact with overhead power lines, lights and power circuits.
Contact with power lines, lights or power circuits may be fatal. We rec-
ommend to install no closer than 20 feet to any power lines.
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below when you are
working on a roof or ladder.
Recommended Tools: Phillips Screwdriver, 13mm and 10mm
Open End Wrench, 8mm nut driver, Flat Blade Screwdriver
Please help preserve the environment and return
used batteries to an authorized depot
UPSPro™ Backup
DANGER! Avoid Powerlines!
You Can Be Killed!
UPS-ST12 / 24 / 48
Power System
Advertisement
Table of Contents
Related Manuals for Tycon Power Systems UPS-ST12
Summary of Contents for Tycon Power Systems UPS-ST12
- Page 1 UPS-ST12 / 24 / 48 UPSPro™ Backup Power System Wireless Base Stations ▫ Surveillance Cameras ▫ Remote Gate Control ▫ Electric Fence ▫ Up to 120W loads ▫ Congratulations! on your purchase of the UPSPro™ outdoor backup power system. Please take a moment to review this Qwik Install Guide before assembly or battery installation.
- Page 2 Qwik Install STEP 1: Add Grounding Wire Between Door and Enclosure: Remove plastic covers on cop- per studs on inside of door and inside of enclosure. Add jumper wire between 2 copper studs and use copper washers and nuts to secure. STEP 2: Add wire feedthrus into the bottom connector plate.
- Page 3 STEP 5: Insert the battery platform in the bottom of the enclosure. The bat- tery platform has cutouts so wires can be routed under the battery as needed. STEP 6: Mount any extra equipment that will reside inside the enclosure. Equipment can be mounted to removable backplate or to a plate mount- ed to the door rails.
- Page 4 24VDC Four Battery 48VDC Four Battery STEP 8: If batteries are installed on their side make sure to apply an insulator to the top of the battery terminal to prevent the battery terminals from shorting to the metal enclosure in case the battery shifts inside the enclosure during an earthquake.
- Page 5 Note: The load will turn on immediately as soon as AC power is re- stored. 2. CAPACITY: The UPSPro UPS-ST12 is rated at 120W load output. The UPS-ST24 and UPS-ST48 are also rated at 120W load output.
-
Page 6: Specifications
SPECIFICATIONS Subject to change without notice UPS-ST12 UPS-ST24 UPS-ST48 Load Voltage 12V +/-0.5 24V +/- 0.5 48V +/- 0.5 Max Load 10A (120W) 5A (120W) 2.5A (120W) Min Load 1 battery 51Ah 600VA 2 battery 51Ah 2 battery 102Ah 1200VA... - Page 7 Compatible Solar Panel Kits Tycon Power Systems Solar Panel kits come with High Performance solar panels, battery charge controller, side of pole mounts and outdoor rated connection cabling. Solar panels have a 25 year output warranty. Pole mounts and panels are designed for wind loads to 90MPH.
-
Page 8: Limited Warranty
TPW-400DT-12/24 400W 12V or 24V Autovoltage select Wind Turbine Integrated controller with dump load • Good low wind performance • Self braking in high wind • 80MPH survivability • Sealed and maintenance • free Limited Warranty The UPSPro™ products are supplied with a limited 24 month warranty which covers material and workmanship defects.
