Congratulations! on your purchase of the UPSPro
Backup Power System. Please take a moment to review this
Qwik Install Guide before use. Please also review other user
guides that are included in the package.
Operation Modes: AC/DC Grid, Solar Ready (May require
blocking diode on solar panels)
Key Features: Industrial Strength, Weatherproof, Key Lock,
24VDC or 48VDC Output, 60A MPPT Battery Charge Controller,
72V 900W AC/DC Power Supply, 8640Wh Backup Capacity
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below if you are
working on a roof or ladder.
Recommended Tools: Phillips and Small Flat Blade Screwdriv-
ers, adjustable wrench
Please help preserve the environment and return
any used batteries to an authorized depot
UPS-AL48-180-900
900W UPSPro
®
®
900W
Advertisement
Related Manuals for Tycon Power Systems UPS-AL48-180-900
Summary of Contents for Tycon Power Systems UPS-AL48-180-900
- Page 1 UPS-AL48-180-900 ® 900W UPSPro Wireless Base Stations ▫ and Client Devices Surveillance Cameras ▫ Communications Tow- ▫ Radio Towers ▫ ® Congratulations! on your purchase of the UPSPro 900W Backup Power System. Please take a moment to review this Qwik Install Guide before use. Please also review other user guides that are included in the package.
- Page 2 Qwik Install STEP 1: Prepare a foundation to provide level support for the enclo- sure. STEP 2: Place enclosure on the foundation. Install 8 batteries in the box. Use a rope tied to the battery tabs to lower batteries into the box. Connect all 8 batteries in series configuration for either 24VDC or 48VDC (See Wiring Diagram Below and near the end of this booklet) STEP 3: Install DIN rail adapters to the...
- Page 3 STEP 5: Remove the black cover from the MPPT controller to access the wire connection screws. Connect the temperature probe to the con- troller and place it on the batteries for temperature compensated charg- ing. STEP 6: Remove the fuses from the battery cables and connect the battery cables to the batteries and the MPPT Charge Controller BAT+ and BAT–...
-
Page 4: Specifications
Specifications Battery Voltage (DC) 24V or 48V (customer configure) Input Voltage (AC) 120/240VAC, 50/60Hz, 5A Max. Capacities (Amp Hr) 24V 360Ah, 48V 180Ah Avail Storage Capacity 8640Wh (Watt Hr) Max Output Power 900W Suggested Maximum 750W Load Maximum Instantaneous 20A 500msec Load Battery Type Valve Regulated Sealed Lead Acid / GEL... - Page 5 TECH CORNER Additional Information you may find useful Solar Ready: The system is solar ready. You may need to add a 100V 30A blocking diode between the solar panel and the PV input to avoid reverse current from the 72V AC/DC power supply going back into the solar panels.
-
Page 7: Limited Warranty
Email Alerts • Programmable functionality Limited Warranty The UPS-AL48-180-900 Backup Power System is supplied with a lim- ited 36 month warranty which covers material and workmanship de- fects. This warranty does not cover the following: • Parts requiring replacement due to improper installation, misuse, poor site conditions, faulty power, etc.
