Tycon Power Systems UPSPro UPAL48-900 Manual

900w backup power system
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Wireless Base Stations
▫
and Client Devices
Surveillance Cameras
▫
Communications Tow-
▫
ers
Radio Towers
▫
Congratulations! on your purchase of the UPSPro
Backup Power System. Please take a moment to review this
Qwik Install Guide before use. Please also review other user
guides that are included in the package.
Operation Modes: AC/DC Grid, Solar Ready (May require
blocking diode on solar panels)
Key Features: Industrial Strength, Weatherproof, Key Lock,
24VDC or 48VDC Output, 20A MPPT Battery Charge Controller
with integral 7 port Gigabit PoE switch, 72V 900W AC/DC Power
Supply, up to 1440Ah Battery Capacity.
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below if you are
working on a roof or ladder.
Recommended Tools: Phillips and Small Flat Blade Screwdriv-
ers, adjustable wrench
Please help preserve the environment and return
any used batteries to an authorized depot
UPAL48-900
900W UPSPro
®
®
900W

Advertisement

loading
Need help?

Need help?

Do you have a question about the UPSPro UPAL48-900 and is the answer not in the manual?

Questions and answers

Related Manuals for Tycon Power Systems UPSPro UPAL48-900

Summary of Contents for Tycon Power Systems UPSPro UPAL48-900

  • Page 1 UPAL48-900 ® 900W UPSPro Wireless Base Stations ▫ and Client Devices Surveillance Cameras ▫ Communications Tow- ▫ Radio Towers ▫ ® Congratulations! on your purchase of the UPSPro 900W Backup Power System. Please take a moment to review this Qwik Install Guide before use. Please also review other user guides that are included in the package.
  • Page 2 Qwik Install STEP 1: Prepare a foundation to provide level support for the enclo- sure. STEP 2: Place enclosure on the foundation. Install 4 or 8 batteries in the box. Batteries are heavy. Be sure to have a helper. Connect all batteries in series configuration for 48VDC (See Wiring Diagrams Be- low) STEP 3: Install DIN rail to enclosure using...
  • Page 3 STEP 5: Remove the fuses from the battery cables and connect the battery cables to the batteries and the Charge Controller large green connector BAT+ and BAT– connections. STEP 6: Make sure to set the AC input voltage selector on the 72V 900W AC/DC Power Supply to either 115 or 230 depending on your AC voltage source.
  • Page 4 controller. Once the charge controller is connected to the batteries, the Charge LED will turn on for about 60 seconds and then there will be no indicators lit until changes are made in the user interface. Please see the TPDIN-SC48-20 user guide for more infor- mation.

  • Page 5: Specifications

    Specifications UPAL48-900 Battery Voltage (DC) Input Voltage (AC) 115/230VAC, 50/60Hz, 5A Max. 4 batteries 720Ah Capacities (Amp Hr) 8 batteries 1440Ah 4 batteries 8640Whr Avail Storage Capacity (WHr) 8 batteries 17280Whr Max Output Power 900W Suggested Max Load 200W Valve Regulated Sealed Lead Acid Pure Battery Type Lead Carbon Battery Life...
  • Page 6 TPDIN-SC48-20 Charge Controller with integrated Gigabit PoE Switch • Remote Monitoring • 4 ports 802.3at or passive 24V or 48V PoE or POE Off. • 3 ports passive 24V or 48V PoE or Poe Off • 1 aux port 24 or 48VDC 2.25A •...

  • Page 7: Limited Warranty

    Limited Warranty ® The UPSPro Backup Power System is supplied with a limited 36 month warranty which covers material and workmanship defects. This warranty does not cover the following: • Parts requiring replacement due to improper installation, misuse, poor site conditions, faulty power, etc. •...
