USING AN FS3X FOOTSWITCH

An optional DigiTech FS3X
Footswitch can be connected
to the CONTROL IN jack for
additional hands-free control.
A TRS (tip-ring-sleeve) 1/4"
cable must be used when
connecting the FS3X to the
TRIO+.
When using an optional FS3X
Footswitch for control, there
are 3 modes of operation to
select from. The table below
shows the 3 modes and the
functions controlled by each
of the FS3X footswitches in
each mode.
FS3X Press & Hold
Mode While Connecting
Live
FS3X Footswitch 1
(Default)
Table Top FS3X Footswitch 2
Live Mixer
FS3X Footswitch 3
To change the FS3X mode:
1. Ensure the TRIO+ is powered up and running.
2.
Unplug the FS3X from the TRIO+ (if it is currently plugged in).
3. Press and hold the FS3X FOOTSWITCH corresponding to the desired mode (see table above).
4. While holding the FOOTSWITCH, plug the FS3X into the CONTROL IN jack. Keep holding the
FOOTSWITCH down for at least 1 second after plugging in the FS3X before releasing it.
5.
The TRIO+ will now use the new footswitch mode.
Footswitch 1
Go to next STYLE
(hold to go to
on drum stick count-in
previous STYLE)
Same as TRIO+
LOOPER footswitch on drum stick count-in
Hold to mute bass
TRS Cable
Footswitch
1
FS3X Control
Footswitch 2
Go to next PART (hold
when stopped to turn
or metronome)
Go to next PART (hold
when stopped to turn
or metronome)
Hold to mute drums
Footswitch Footswitch
2 3
Footswitch 3
Toggle ALT TIME
mode
Same as TRIO+
BAND footswitch
Hold to mute bass
and drums
32
