OUTPUT JACK OPERATION

The output jacks have an auto-sensing feature which allows the TRIO+ to automatically optimize the outputs
for the application. The chart below describes how the TRIO+ will operate depending on which outputs are
connected.
Operation
Description
Speaker cabinet emulation will
be applied to the guitar signal,
including loops, and a mono mix of
the bass, drums, and guitar will be
sent to the MIXER OUT jack.
A mono mix of the bass, drums,
and guitar signal will be sent to
the AMP OUT jack. Complimentary
equalization will be applied to the
drum and bass parts to make them
sound better when played back
through a guitar speaker cabinet.
NOTE: When using your guitar
amp to play the drums and bass
from the TRIO+, set the amp to run
as cleanly as possible in order to
avoid distorting the backing band.
The drums and bass are pre-EQ'd
to sound best through a clean amp
with "flat" EQ settings.
The guitar signal, including loops,
will be fed to the AMP OUT jack only.
The mix of bass and drums will be
sent to the MIXER OUT jack.
Speaker cabinet emulation will be
applied to the guitar signal.
A stereo mix of the bass, drums,
and guitar will be sent to the
HEADPHONE OUT jack. The MIXER
and AMP outputs will be muted.
15
MIXER OUT
Connected
AMP OUT HEADPHONE OUT
Connected Connected
