Summary of Contents for DigiTech TONE DRIVER
- Page 2 European Contact: Your local DigiTech Sales and apparatus has been exposed to rain or moisture, does Service Office or not operate normally, or has been dropped.
- Page 3 6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tam- pered with by anyone other than a certified DigiTech technician or, if the product is used with AC volt- ages outside of the range suggested by the manufacturer.
- Page 4 DigiTech’s exclusive AudioDNA™ technology is what makes the Tone Driver more than your standard overdrive stompbox. Rather than working from a single overdrive circuit, the Tone Driver features a Morph knob which blends between three totally distinct overdrive types.
- Page 5 2 3 4...
- Page 6 4. Gain Knob Controls the amount of overdrive distortion. Turn this knob clockwise to increase the amount of distortion, and counter-clockwise to decrease the amount of distortion. 5. Morph Knob Morphs the three different overdrive voicings. The minimum position is an edgy, mid boost overdrive.
- Page 7 11. Out 2 (Mixer) Jack This output features DigiTech’s CIT™ cabinet modeling technology, that lets you run the pedal directly into a mixer or recorder input without having to use a guitar amplifier.
- Page 8 Connections The Tone Driver has a single input (INPUT) and a pair of outputs (AMP and MIXER). The two outputs give you the following options: running into a guitar amplifier, or running directly to a mixing console or recording device, or both. The MIXER output uses DigiTech’s advance CIT™...
- Page 10 Battery Replacement 1. Using the tip of a 1/4” guitar cable, push one of the release pins in on either side of the pedal, and remove the pedal from the pedal chassis. 2. Remove the battery from the battery compartment and disconnect the battery cable.
- Page 12 PH (801) 566-8800 • Jacks - Input, Out 1 (Amp), Out 2 FAX (801) 566-7005 (Mixer) DigiTech and X-Series are trademarks • Input Impedance - 280 kOhms of the Harman Music Group Inc. • Output Impedance - 100 Ohms • Power Supply - 9V Alkaline Dry Battery Copyright - Harman Music Group •...
