7.
The scaler checks several possibilities, in the following order, and then responds
accordingly:
•
•
•

Navigating the Default Web Pages

The DVS 304 default Web pages include four tabs (Status, Configuration, File
Management, and Control) for easy navigation of several administrative options including
system status, password control, file management, and scaler settings.

Status

The Status tab displays the System Status page for the DVS 304.
System Status page
The System Status page is the default page of the on-board Web server, and provides an
overall view of the status of the complete scaler. It provides immediate system information,
power status and serial port settings for the DVS 304 unit.
Figure 40.
Click OK.
Does the address include a specific file name, such as 10.13.156.10/file_
name.html? If so, the DVS 304 downloads that HTML page.
Is there a file in the scaler's memory that is named "index.html"?
If so, the scaler downloads "index.html" as the default start-up page.
If neither of the above conditions is true, the scaler downloads the factory-installed
default start-up page, "nortxe_index.html", also known as the System Status page.
System Status Page
DVS 304 Series • Ethernet Control 66
