SPECIFICATIONS

MULTIRANGER PLUS

Power:
Fuse:
Range:
Accuracy:
Resolution:
Memory:
Display:
Operating Temperature:
Outputs: transducer drive: » 41 KHz, 400 V peak pulses of 1 msec
analog:
relays:
All relays are certified for use in equipment where the short
circuit capacity of the circuits in which they are connected is
limited by fuses having ratings not exceeding the rating of the relays.
Enclosure:
Approvals:
Weight
PL-443
» 100/115/200/230 V ±15%, stab selective
» 50/60 Hz, 15 VA
» optional: » 12 V dc model, 10 to 18 V dc
» 24 V dc model, 18 to 36 V dc
» 1/4 amp MDL Slo-Blo or equivalent
» 0.3 to 15 m (1 to 50 ft)
» 0.25% of range or 6 mm (0.24"), whichever is greater
» 0.1% of range or 2 mm (0.08"), whichever is greater
» EEPROM (non-volatile) no back-up battery required
» Liquid Crystal Display of 4 digits, 18mm (0.7") high
» – 20 to 60 °C (– 5 to 140 °F)
max duration at a max
repetition rate of 300 msec
» 0 - 20 or 4 - 20 mA
» max loading: » 350 ohms, return to ground
» 750 ohms, return to –12 V
» resolution: 0.1% of range
» optional mA isolator
» 5 multipurpose relays (for alarms, pump control,...)
» 1 Form "C" SPDT contact per relay, rated 5 A at
220 V ac non-inductive
» adjustable deadband
» CSA enclosure type 4 (similar to NEMA 4)
» 160 mm W x 250 mm H x 82 mm D
(6.3" W x 9.5"H x 3.2"D)
» polycarbonate
» CE
» 1.8 kg (4lb)
2 – 1
96/01/22
