Modules
Fig. &
index Tektronix part Serial no.
number
number effective
10- - 3- - 1 650- - 4317- - XX
- - 2 211- - 0738- - XX B010100
- - 3 174- - 4427- - XX
- - 4 174- - 4514- - XX
- - 5 039- - 0154- - XX B010100
039- - 0159- - XX B020000
039- - 0173- - XX B030000
- - 6 156- - 9442- - XX B010100
167- - 0428- - XX B030000
- - 7 211- - 1050- - XX B010100
- - 8 174- - 4894- - XX B010100
174- - 4865- - XX B020000
174- - 5351- - XX B030000
- - 9 174- - 4807- - XX
- - 10 671- - 5737- - XX
- - 11 119- - 6480- - XX
B010000
B010000
B010000
B010000
B010000
B010000
119- - 6969- - XX
- - 12 614- - 1023- - XX
614- - 1024- - XX
614- - 1025- - XX
614- - 1026- - XX
- - 13 366- - 0837- - XX
- - 14 366- - 0836- - XX
- - 15 366- - 0835- - XX
- - 16 174- - 4321- - XX
- - 17 259- - 0155- - XX
- - 18 650- - 4633- - XX
- - 19 650- - 4586- - XX B010100
650- - 4999- - XX B030000
- - 20 343- - 1676- - XX
TDS5000B Series Service Manual
Serial no.
discont'd Qty Name & description
1 PRINTER,THERMAL:TDS5000 SERIES PRINTER
B029999 2 SCREW,MACHINE:6- - 32 X 0.625,PNH,STL BLK ZI,TORX
1 CA ASSY, SP:DESCRETE,CPD,20, 18 AWG, 8.0L, 2 X 10,RCPT,STR,2X10 BOTH ENDS
1 CA ASSY,SP:GPIB,RIBBON
B019999 1 MOTHER BOARD ASSY;PENTIUM 4/CELERON BD,UATX,ASHLAND 2.1,W/O PROC-
ESSOR,D845GVAD2L
B029999 1 MOTHER BOARD ASSY;PENTIUM 4/CELERON BD,UATX,LA CROSSE,W/O PROC-
ESSOR,BLKD865GLCLK INTEL P/N,SAFETY CONTROLLED
1 MOTHER BOARD ASSY;PENTIUM 4,UATX,TAPPEN BD,GIG E, PROCSSOR LGA775,DDR2
667MHZ,TOTAL 4 GIG;BLKD945GTPLKR,SAFETY CONTROLLED
B029999 1 IC,MEMORY; 64M X 64,512M, 266MHZ,CL=2.5,PC2100; MT16VDDT6464A,DIMM184
1 IC,MEMORY; 64M X 64,512 MB DDR2,1.8V, 3- - 3- - 3;MT16HTF6464AY- - 40E,DIMM240,DS1
B029999 16 SCREW,MACHINE:6- - 32 X 0.312 L,PNH,STL CAD,T15
B019999 1 CABLE ASSY; 4 PIN P4 POWER,9.5 L,MOTHER BOARD TO INTERFACE BOARD
B029999 CABLE ASSY; 4 PIN P4 POWER,9.5 L,MOTHER BOARD TO INTERFACE BOARD
CABLE ASSY; 4 PIN P4 POWER,12 L,MOTHER BOARD TO INTERFACE BOARD
1 CA ASSY; ATX USB, PLUS MISC. TO DISPLAY
1 CIRCUIT BD ASSY; PC INTERFACE
1 POWER SUPPLY:300W,AC- - DC,STANDARD,ATX PC SUPPLY,90- - 132 180- - 264VAC 50- - 60 HZ
IN,+3.3V 16A +5V 26
B010004 TDS5032B
B010005 TDS5032B
B010020 TDS5034B
B010005 TDS5052B
B010029 TDS5054B
B010152 TDS5104B
All military and commercial products released with 119- - 6969- - xx, ecept for a limited number of
products listed above .
POWER SUPPLY; 300W, AC- - DC, ATX POWER SUPPLY, 100- - 240 VAC 50- - 60 HZ, 115 VAC
400 HZ IN,
1 PANEL ASSEMBLY:FRONT,4 CH- - NO TS
1 PANEL ASSEMBLY:FRONT,2 CH
1 PANEL ASSEMBLY:FRONT,2 CH- - NO TS
1 PANEL ASSEMBLY:FRONT
7 KNOB,CAP; 0.650 D,SOFT FEEL COATING,PC/ABS BAYBLEND,FR110,TEK SILVER GRAY
7 KNOB,CAP; 0.425 DIA,SOFT FEEL COATING,PC/ABS,BAYBLEND,FR110,TEK SILVER GRAY
1 KNOB,EPS; PUSH BUTTON ENCODER,SOFT FEEL COATING,PC/ABS BAY-
BLEND,FR110,TEK SILVER GRAY
1 CABLE ASSY:FLAT FLEX,26POS,10.4L,FRONT PANEL
1 FLEX CIRCUIT; POWER SWITCH,W/LED
1 MODULE ASSEMBLY; TOUCH PANEL;TDS5000B SERIES
B0299999 1 COMPONENT KIT:DISPLAY MODULE ONLY
1 COMPONENT KIT:DISPLAY MODULE ONLY
1 CLAMP,CABLE; PC/ABS ALLOY,SILVER GREY
Mechanical Parts List
10- 7
