Printer Frame
(SN B029999 and below)
TDS5000B Series Service Manual
1. Remove the printer frame if installed: See Figure 6- -6.
H CD-Rom Trim
H Right-side panel
H Printer or accessory tray
H Top cover trim
H Top two rear feet
H Pouch
H Right-side cover
2. Orient the oscilloscope: Set the oscilloscope so the rear is on the work
surface and the front of the oscilloscope is facing you.
a. Remove the four T-15 TORX drive screws that secure the printer frame
to the chassis.
b. Remove the two T-15 TORX drive screws that secure the cable restraint
to the printer frame.
c. Remove the printer frame from the chassis.
CAUTION. Take care not to bind or snag the covers on the oscilloscope internal
cabling as you remove or install components.
3. Reinstallation: Do in reverse steps a through c to reinstall the cabinet covers.
