SANKO Coating Thickness Meter

ＳＷＴ－７０００Ⅲ／７１００Ⅲ

Instruction Manual

CAUTIONS:

Before using the Meter, read this INSTRUCTION MANUAL

thoroughly and use the Meter correctly.

Keep this INSTRUCTION MANUAL carefully and refer to this

when necessary.

In the event of any doubt arising, the original

INSTRUCTION MANUAL (Japanese) is to be of final authority.

SANKO ELECTRONIC LABORATORY CO., LTD.

Tokyo･Osaka・Sendai・Nagoya・Fukuoka・Kawasaki

December 2014

Table of Contents

Need help?

Do you have a question about the SWT-7000 III and is the answer not in the manual?

Questions and answers

Summary of Contents for SANKO SWT-7000 III

Page 1 Meter correctly. Keep this INSTRUCTION MANUAL carefully and refer to this when necessary. In the event of any doubt arising, the original INSTRUCTION MANUAL (Japanese) is to be of final authority. SANKO ELECTRONIC LABORATORY CO., LTD. Tokyo･Osaka・Sendai・Nagoya・Fukuoka・Kawasaki December 2014...
Page 2: Table Of Contents
Contents Pages Attention for safety ･･････････････････････････････････････････････････････････････１ Notes ･･････････････････････････････････････････････････････････････････････････３ Get started ･･････････････････････････････････････････････････････････････････････４・ Contents in a package ･････････････････････････････････････････････････４・ Names of part ････････････････････････････････････････････････････････５・ How to fit batteries ････････････････････････････････････････････････････６・ How connect, disconnect probes ･･････････････････････････････････････････７...
Page 3: Attention For Safety
Attention for safety （to use in correct ways） To prevent you and your properties from damaging please take some time to read thoroughly this “Attention for Safety” and correct uses keep these instructions attentive to read when necessary. Warning ● Do not dump nor wet the gauge unit in water, otherwise it may cause damages. Please contact our distributor or sales office should submerged water into the unit.
Page 4 Attention For Safety （to use safely and correctly） Warning ！ ● Never fail to remove batteries from the unit when not in use for a long time. Leakages occurred from deterioration of batteries may cause erroneous reactions or damages. Must ！...
Page 5: Notes
Attention For Safety （to use safely and correctly） Attention ● Do not use Benzene or Thinner for cleaning and spray pesticides on the meter, otherwise it may cause cracks or malfunctions. Prohibition ● Do not store the meter in places getting high in temperatures such as in a car in strong sunlight or near heaters, otherwise it will be hazardous to the meter and may cause malfunctions.
Page 6: Get Started
Get started ◆ Contents in a package Please make sure if the following items sre included. ・ Main unit ＳＷＴ－７０００Ⅲ, or ＳＷＴ－７１００Ⅲ ・ Dry batteries LR6 (2 pieces) ・ Carrying case ・ Instruction manual （this manual）・ＡＣ adaptor （ＳＷＴ－７１００Ⅲ ｏｎｌｙ）・...
Page 7: Names Of Part
◆ Names of part Probe socket Display Power ON/OFF key Hand strap Keys Battery compartment （the back） Socket for AC adaptor connector （SWT-7100Ⅲ only） Socket for ＵＳＢ cable connector (SWT-7100Ⅲ only) ● Probe socket Connect an optional-exclusive SWT probe to the probe socket. (１) To measure a film thickness of coated, plated, lining layer on substrates made of ferrous material please use a probe of (Fe) series for the connection.
Page 8: How To Fit Batteries
◆ How to fit batteries ① Open the battery lid on the back of the unit. Press down and slide the lid in direction of arrow to open. ② Insert batteries. Ensure correct battery polarity ○ 、 ○ for placement. ＋...
Page 9 ◆ How to connect or disconnect a probe ◆ Connect an optional, exclusive SWT probe to the main unit. Select one of the probes suited for your application. Insert a probe connector into the probe socket of the main unit. Make sure of aligning the keyway leading to a smooth joint without doing by force.
Page 10: How To Hold Probes
◆ How to hold probes Cable Pinch and hold this part using fingers (thumb and forefinger) Black resinous ring Tip to press against a measurement object ◆ How to press a probe to an object ・ Keep the probe 5 cm or over away off metallic objects when not in use of measuring. ・...
Page 11: How To Operate
How to operate （１） How to switch Power source Press ON／OFF key. ＳＴＡＲＴＵＰ This message lasts for about 3 seconds. ＰＨＡＳＥ Caution ＨｏｌｄＰｒｏｂｅ Hold the probe in air without operation when ｉｎｔｈｅａｉｒ the reading is on display. Or it may indicate Ｄｏｎ‘ｔ...
Page 12: ３）Zeroing
（３） Zeroing It is capable of getting started on measurements immediately after the message of 「START UP PHASE」 has disappeared as described on page 9. However, it makes errors depending on material formation and shapes to be measured. To minimize measurement errors and obtain as accurate results as possible please be sure of carrying out 2 points of adjustments of 「Zeroing」...
Page 13 The buzzer beeps. It stopes its DELETION function of CAL/DELETE The reading shows that 「Zeroing」 has completed and Ｆｅ it becomes possible to take measuring and adjusting operations of this unit. ０ μｍ ● It is correct that numerical values measured by pressing the probe to the 「Zero Plate」 indicates 「０」 or in the neighborhood of 「０」.
Page 14: ４）Calibration Standard (Cal)
(4) Calibration standard (CAL) ● Pepare 「Zero Plate」 used for 「ZEROing」 ● Prepare 「Thickness standard」、foiles that are the same thick as the measuring film or thicker than that. ● Place the 「Thickness standard」 on the 「Zero Plate」． ● Press the CAL/DELETE The buzzer beeps.
Page 15 After adjusting the reading value to the Standard thickness, press CAL/DELETE key. The buzzer beeps, 【Calibration Standard】 on the upper left disappears and it returns to a measuring mode. Ｆｅ 1００ This is a measusring mode. μｍ ● It is correct that numerical values measured by pressing the probe a few toimes to the 「Standard theickness」 on the 「Zero Plate」...
Page 16: ５）Zeroing -In Special Cases
（５）Zeroing in special cases (Multi-layers) ◎ In case of being painted as shown with multi-layers on the substrate there may be needs to measure thicknesses of each layer. For example, measuring only the thickness of the 4 layer please zero as an assumed ZERO at the surface of the 3 layer stacked on the substrate.
Page 17 ＯＦＦＳＥＴ．Ｔｏｃｏｎｔｉｎｕｅ，ｐｒｅｓｓ ZERO ｔｗｉｃｅ． Press ZERO key . －－ ① The buzzer beeps. Press ZERO key. －－ ② The buzzer beeps. 【ＺＥＲＯＣａｌ．】１．Ｍｅａｓｕｒｅｓｕｂｓｔ－ｒａｔｅＳｅｖｅｒａｌｔｉｍｅｓ．２．ｐｒｅｓｓ ZERO ｋｅｙ． Press the probe to Zero plate. The buzzer beeps. The reading shows that it is process of zeroing adjustments ＺＥＲＯ...
Page 18 The buzzer beeps. It stopes the DELETE function of CAL/DELETE key. Ｆｅ「Zeroing」 has completed (the zeroing letters ０ disappeared) and it becomes possible totake measuring and adjusting operations of this unit. μｍ ● It is correct that numerical values measured by pressing the probe to the 「Zero Plate」 indicates 「０」 or in the neighborhood of 「０」.
Page 19 (６) 2-foil calibration when “Zeroing “ is difficult to perform. In case zeroing is difficult to perform such as measuring the thickness of the film on the rough surface of Blast-steel plates, a calibration method using 2 different thicknesses of standard plates pinching a thickness of the object is defined as ｢JIS K5600｣Standard.
Page 20 ●Try measuring plural times in range of 1―20 times by pressiing the probe on a thinner 「Thickness Standard」. ( a mean value is indicated whenever the probe is pressed ) Press ZERO key afterwards. ◆When repeating measurements 20 times, the buzzer beeps, beeps 2 times and afterward ｔｈe unit does not accept any entry.
Page 21 Press the probe on the thicker 「Thickness Standard」 stacked on the 【２-ｆｏｉｌ’ｓｃａｌ】 substrate. Ｍｅｓｅｕｒｅｔｈｉｃｋｅｒｆｏｉｌｏｎｍｅｔａｌｓｅｖｅｒａｌｔｉｍｅｓ．Ａｆｔｅｒｗａｒｄｓ，ｐｒｅｓｓ ZERO ｋｅｙ． The buzzer beeps whenever pressing the probe. 【2 - f. c. 】Ｆｅ Mean value １９８...
Page 22 A press of ▲ or ▼ key makes the buzzer beeps, Indicating the last measured value on the reading. 【2 - f. c. 】Ｆｅ Mean value １９８ μｍ Equate the displayed value with the thickness of Thickness Standard (in this example 200 μm) by pressing ▲ key.
Page 23 ● It is correct that numerical values measured by pressing the probe to the 「Thickness Standard」 placed on the substrate like a blast steel plate ndicate 「０」 or in the neighborhood of 「０」. ● When the measured value results deviate largely from 「Thickness Standard」, please try again performing 2-folils calibration from the beginning.
Page 24: ７）How To Delete Calibration
（7） How to delete calibration Take the following procedures to delete calibration when the reading on the screen is locked or after batteries replaced or when it becomes impossible to process 「Zeroing」、「Calibration Standard」（CAL）. When holding ZERO key , press ▼ key.
Page 25: Measuring
Measuring Hang the meter through a strap over your wrist never to drop it. When pressing the probe against the object, the buzzer beeps. The reading shows that the unit is set tomeasure Ｆｅ on a substrate material of Ferrous by connecting a 「Fe-325」...
Page 26: Function Switching
Function switching （１）Switching to Non-Interrupt Measurement Mode Switch to「non-interrupt measurement mode」when it is necessary to slide a probe along the measuring surface of a substrate as illustrated on the right figure Substrate for continuous measurements of films. A measuring value is indicated and stored Ｆｅ...
Page 27 Caution Note that this measuring method may damage the measuring surface or the probe tip due to sliding frictions. Please try fewer to take this method to minimize the frictions. 《Returning to the beginning》 To return 「non-interrupt measurement mode」 to the beginning take the same procedures as at the initial setting.
Page 28: ２）Switching To Resolution
（２）Switching to Resolution To inspect precisely a thickness up to 500μｍ it is possible to take solution measurements by switching to a 0.1μｍ（0～400μｍ） unit , to a 0.5μｍ（400 ～ 500μｍ） unit. In this case it changes resolution units by taking the following procedures. ●...
Page 29: ３）Setting To Auto-Power-Off
（３） Setting of Auto-Power-Off When no entry of key operations and measuring procedures for 3 minutes, the unit switcehes automatically to Off to save battery. This function can be released by yhe following operations. No entry for 3 seconds continues, and then the buzzer beeps. ＰＯＷＥＲ...
Page 30 ● To enable Auto-Power-Off function Switch to Off when Power is On. While pressing and holding ▲ key, press ON/OFF key for 5 seconds or over. The buzzer beeps., beeps. ＡｕｔｏｍａｔｉｃＳｗｉｔｃｈＯＦＦ It indicates for 5 seconds. 【ＥＮＡＢＬＥ】（）...
Page 31 （４） Switching to a corresponding mode to substrate when using FN-325 probe The unit is set to 「AUTO」 mode when FN-325 probe is connected. (EX-factory setting) Setting can be switched in the procedures below. And, modes change as shown below. 【EX-factory setting】...
Page 32 （５） ON/OFF of Backlight This unit has a Backlight function. The Backlight can be used at the place which is dark and difficult to read messages on display. ● Lighting the Backlight Press and hold ▲ key for 3 seconds It is shown when the backlight is ON （ＡＵＴＯ）...
Page 33: Transferring Data (Swt-7100Ⅲ)
Transferring data （SWT-7100Ⅲ） Transfer data to a PC (personal computer) by using a ＵＳＢ cable Refer to separately attached information for arrangements to install a driver into a PC side. ※Data is not transferred when the unit is set to 「Non-intrerrupt measuring mode」. Please make sure that the unit is set to 「General measuring mode」...
Page 34: Note To Improve Measuring Accuracy
Note to improve measuring accuracy ① Zero plate Prepare the same material, thick and sized plate as the measuring object for zeroing and calibration standard (CAL). Different materials may not bring about correct measuring results. ※As accessories to probe, “zero plates for zeroing” are for testing purpose only. Select a most optimal zero plate to meet actually measuring objects.
Page 35: Trouble Shooting
Trouble Shooting Before contacting us please check with the following points. Symptoms Points to check Measures to be taken No response upon press of Are batteries worn out? Replace them with new ones (2 ea.) ON/OFF key. No response after replacing Something wrong inside a meter Contact us for repair batteries and pressing a key...
Page 36 Symptoms Points to check Measures to be taken Something wrong with probe Contact us for repairs TROUBLE！ The probe may have trouble. Change it to the other one. 《Power OFF》 Contact us for repairs TROUBLE！ Something wrong with probe, The probe and the and main unit main unit may have trouble.
Page 37: Specifications
Specifications ◆ Unit Items Applications Model names Dual ( electromagnetic／eddy current) SWT－7000Ⅲ, SWT-7100Ⅲ Display method Graphic LCD （data ・ message）, Backlight Ranges Depending on optional probes Calibrations 2 points calibration type Zeroing ： for substrate （CAL） Calibration point : substrate and standard thicknesses ①...
Page 38 ◆ Probe (option) Models FN-325 Methods Dual electromagnetic／eddy current （Auto-selection substrate） Ranges Ferrous: 0～3.00mm, Nonferrous: 0～2.50mm Both ferrous/nonferrous 1μm: 0～999μm by switching Both ferrous/nonferrous 0. 1μm: 0～400μm、 Display Solutions Both ferrous/nonferrous 0. 5μm: 400～500μm Ferrous substrate 0. 01mm:1. 00～3. 00mm Nonferrous substrate 0.
Page 39: Probe
◆ Probe （option） Fe－2．5※ Models Ｆｅ－2．5LwA Ｆｅ－10 Ｆｅ－20 ／Fe－2．5Ｌ Methods Magnetic inducing type Ranges 0～2．50ｍｍ 0～10ｍｍ 0～20ｍｍ 1μｍ：0～999μｍ Switching to 1μｍ：0～999μｍ Display 1μｍ：0～999μｍ 0．1μｍ：0～400μｍ、 0．01mm：1～5mm resolitions 0．01mm：1～10mm 0．5μｍ：400～500μｍ 0.1mm：5～20mm 0．01mm：1．00～2．50mm 0～100μｍ：±１μｍ Accuracies 0～3mm：±（5μm+ 3％ the reading value） or within ±2％ the reading value （on flat face）...
Page 40 ◆ Probe （option）ＮＦｅ－2．0※ Models Fe－0.6ＰｅｎＮＦｅ－0．6 ＮＦｅ－8 ／ＮＦｅ－2．0Ｌ Methods Magnetic inducing type Eddy current type Ramnges 0～600μｍ 0～2．00ｍｍ 0～600μｍ 0～8．00ｍｍ 1μｍ：0～600μｍ 1μｍ：0～999μｍ Switching to Switching to 1μｍ：0～600μｍ Display 0．1μｍ：0～400μ 0．1μｍ：0～400μｍ、 Switching to 1μｍ：0～999μｍ solutions ｍ、 0．5μｍ：400～500μｍ 0．1μｍ：0～400μｍ、 0．01mm：1～8mm 0．5μｍ：400～500μ 0．01mm：1．00～2．...
Page 41 Reference (Principle of measurements) Electro-Magnetic type ● When metals approach to AC- magnetic fields emitted from probe, the metal and the magnet pull each other. It makes the pulling force stronger as they come closer. In other words, it makes the magnetic density higher as they come closer.
Page 42 Sales of Coating thickness meter, Pinhole detector, Condensator, Viscosity cup, Moisture meter, Needle detector, Iron piece detector Manufacturer: Sanko Electronic Laboratory Co., Ltd. Tokyo branch：Shibata Bldg., 2-6-4, Uchikanda, Chiyoda-ku, Tokyo 101-0047, Japan Tel 81-3-3254-5031 Fax 81-3-3254-5038 Osaka branch：Konishi Bldg., 2-3, Sugawara-cho, Kita-ku, Osaka 530-0046, Japan Tel 81-6-6362-7805 Fax 81-6-6365-7381 Sendai Branch：Bonuer Est, 72-2 Teppo-cho, Miyagino-ku, Sendai 983-0861 Japan...
