● Connect/disconnect the probe after surely confirming the power OFF. It causes out of order. ● In the event of any doubt arising, the original INSTRUCTION MANUAL in Japanese is to be final authority. SANKO ELECTRONIC LABORATORY CO., LTD. (株式会社 サンコウ電子研究所)...
CONTENTS ITEM PAGE 1.FEATURES AND APPLICATIONS 2.SPECIFICATIONS 3.NAME OF PARTS 3-1 Instrument proper 3-2 LCD display 3-3 Standard probe 4.OPERATING INSTRUCTIONS 4-1 Connecting (Disconnecting) the probe 4-2 Power ON・OFF 4-3 Various measuring methods 5.MEASUREMENT 5-1 Preparation for the measurement 5-2 Converting the measurement mode 5-3 Converting the hold mode 5-4 Setting upper and lower limit values 5-5 Releasing upper and lower limit values...
1.FEATURES AND APPLICATIONS ● The moisture contents for various materials/products can be measured with the probe connecting to the instrument proper. Kinds of the probe: probe for wood, probe for paper, probe for mortar and plaster ● The moisture contents of all kinds of objects can be compared in the MC mode. Measurement can be carried out by converting the mode of the instrument proper keeping on each probe connecting.
2.SPECIFICATIONS ■ MR-300 Instrument proper(Common specifications) Measuring method DC electric resistance method Measuring range Depends on connecting probe Probe Selection for the objects Conversion of mode Moisture %, MC mode (Moisture Content) Resolution Moisture : 0.1 % MC mode : 0.5,...
Page 5
■ MR-300 Standard probe ● Probe for wood Type TG-PA(Standard probe for wood) Measuring range 3.5 to 50.0% Hardwood(Hard)/Softwood(Soft) by conversion MC-3(Moisture Content) by 1 to 100 indication (1 to 50 : 0.5 pitch, Over 50 : 1.0 pitch) Dimensions and Weight 50(W) ×...
3.NAME OF PARTS 3-1 Instrument proper ① Group key (GROUP) Measurement mode is different depending on the connected probe. The mode is converted each press of the key. TG-PA:Measured value of the moisture in Wood (HARD/SOFT) and MC-3 mode are converted. KG-PA:Measured value of the moisture in Paper and MC-2 mode are converted.
Page 7
⑦ Mem. key Key for setting the memory block. ⑧ Com. key Key for setting the communication mode with PC. ⑨ Print key Measuring data, statistically calculated result and histogram are printed out. ⑩ Setting key of the values (「 」「...
Page 8
Receptacle for RS-232C ・Out-put port for RS-232C ・When the Meter is connected to the instrument having the port of RS-232C such as P.C., use the Button for the EL back light attached communication cable for ・Button for switching ON the EL RS-232C.
3-2 LCD display h.Hold mode g.Communication speed i.Upper limit value mark j.Lower limit value mark a.Connecting probe k.Upper limit value TG-H HOLD H 20.0% b.Comm. with P.C. l.Lower limit value COM:19200bps L 10.0% c.Memory mode m.No. of Mem:Blk. 150 № d.Operation of printer measurement memory e.Voltage drop of the...
Page 10
f. Voltage drop of the printer When the voltage of the battery supplying the power to the mechanical part and control part of the printer drops until less than specific voltage, this mark is displayed. (Displayed only while operating the printer) When this mark is displayed, slide the cover of the battery space at the back side of the instrument proper downwards and replace all four alkaline dry batteries for the printer unit part placed in left hand...
Page 11
● Indicating function by kana When the Meter is delivered, the Meter is set with LCD display/printing mode by alphabet. But the Meter can be converted to LCD display/printing mode by kana. By pressing the [Clear] key ⑬ and [Cancel] key ⑫ simultaneously, display and printing mode are converted. By pressing these two keys again, the mode returns to the mode by alphabet.
Page 12
◎ Printing Indication by the alphabet Indication by the kana TG-H モクザイ-H TG-S モクザイ-S カミ PLASTER プラスタ MORTAR モルタル HOLD ホールド COM: ツウシン プリント Mem: メモリ BLK. ブロック H-set ジョウゲン L-set カゲン Statistics トウケイデータ Memory Block No メモリブロックバンゴウ Total Count ゼンスウ...
4.OPERATING INSTRUCTIONS 4-1 Connecting(Disconnecting) the probe (Be sure to confirm the power OFF.) ・To connect the probe: Carefully insert the probe connector ○ of the using probe to the bottom into the receptacle for the probe connector ⑱. ・To disconnect the probe: ○...
4-3 Various measuring methods MR-300 can be used with the combination of the probes and the following functions as well. When the Meter is used with the combination of the functions, it is necessary to set up each function. Set up the necessary function only when the Meter is used.
5.MEASUREMENT 5-1 Preparation for the measurement 1. Connect the probe suitable for an object (wood, paper, mortar and plaster) to be measured. 2. Power switch ⑤ ON and confirm the indications on the LCD display ⑰. For wood =[TG-H] For paper =[KG] For mortar and plaster =[MORTAR] TG-H Example: In case of connection...
5-2 Converting the measurement mode ・Normally the initial measurement mode of the selected probe is indicated on the LCD display. ・The measurement mode is converted each press of the「Group」key ① as shown in the following charts. [Probe for Wood] Indication on the LCD Power ON Wood-Hard(Hard wood) TG-H...
5-3 Converting the hold mode When the hold key ② is pressed, the「Hold」mark is indicated on LCD ⑰ and indicated measured value will TG-H HOLD be held until the next measurement. Hold mode will be converted ON or OFF each press of the key.
5-5 Releasing upper and lower limit values(in the operating measurement mode) ↓ Clear (Releasing both upper and lower limit values) ※ When erasing of upper and lower limit values in the memory block is needed, repeat above procedures after selecting the storage memory block. 5-6 Converting the key lock mode When the「LOCK」key ④...
For releasing the printing out, refer to item "5-8". 5-13 Setting the memory mode MR-300 can store up to Max. 15,000 data in the memory mode. There are following two ways for setting the memory block, so select one way of the two and set the memory block.
5-14 Restoring the construction of the memory(All data are erased for resetting.) For restoring to the non-constructed conditions the constructed memory block, following procedures are needed. Pay attention to proceed the procedures because all data are erased. ※ Same procedures are applied to both a fixed block system and an arbitrary block construction system. By restoring the memory, the upper and lower limit values have been set in each block are also erased together.
5-17 Measurement in the memory mode and releasing Completing above item "5-16 Selecting the memory block" measurement in the memory mode can be done. When [Non Mem.] key ⑥ is pressed while measuring in the memory mode, the memory mode is released and transfers to the measurement in non-memory mode keeping the hold mode ON.
5-20 Measurement in the memory mode, communication with PC and printing out ◇ Confirm the ON condition of the hold mode before pressing the key Mem. [BLK. X] is indicated blinking on the LCD ↓ (Selection of the storing blocks) ・...
5-23 Communication with PC and printing out of the memorized data Com. [COM:19200bps] is indicated blinking on the LCD. ↓ (Selection of the communication speed) ・ (Example) [192000bps] ← Communication speed to be set(blinking indication) ↓ Print [Prt] is indicated blinking on the LCD. ↓...
5-28 Communication with PC of the histogram Com. [COM:19200bps] is indicated blinking on the LCD. ↓ (Selection of the communication speed) ・ (Example) [19200bps] ← Communication speed to be set(blinking indication) ↓ Mem. [BLK.X] is indicated blinking When continuous plural blocks are communicated, on the LCD.
Please contact us at the nearest branch for the details. 7.COMMUNICATION WITH PC MR-300 has a function for the communication with PC (Connection to RS-232C). The communication cable is attached as standard. Transmission of the data is carried out with the ASCII code.
Page 27
Communication output ① Data while measuring When the function of the communication with PC is ON, transfer the measured values (values on hold) to PC. Transmit the measurement mode, upper limit value, lower limit value, measured values with the first transmission of the data.
Page 28
② Memory data Transfer the data stored in the memory in a block as a unit. Transfer the measurement mode, upper limit value, lower limit value and number of the data at first and followed by all data in blocks. When the measured value exceeds the upper limit value, add the letter「H」in front of the measured value, and letter「L」for the value under the lower limit value.
Page 29
③ Statistical data Statistical results of the data memorized in the memory are transferred. Those are transferred in block units. ◎ Output format (Example: TG-H mode) Index data C: Command X: Figure 1 letter △: Space Block No. Measurement mode Upper limit value Lower limit value Data No.
Page 30
④ Histogram data Histogram of the data memorized in the memory are transferred. The measured values only of which data have been memorized are transferred in block unit. ◎ Output format (Example: TG-H mode) Index data C: Command X: Figure 1 letter △: Space C Block No, Measurement mode Upper limit value Lower limit value...
8.TEMPERATURE COMPENSATION The automatic temperature compensating function is set ON at the initial setting condition and the indicating value is automatically temperature compensated based on 20 ℃. When an object to be measured is high temperature due to dry treatment by heating etc., measure it after the automatic temperature compensating function OFF.
Page 32
When the automatic temperature compensating function is set OFF, refer to the following list for the temperature compensation. ◎ For wood Moisture(%) Temperature(℃) 4 to 11 12 to 20 above or 21 below + 2.0 + 2.5 + 3.0 0 to 1 +...
9.NOTES FOR THE MEASUREMENT The electric resistance type Moisture meter utilizes the characteristics that the electric characteristics of an object to be measured reacts specially sensitively on its moisture contents, but the relation is not perfectly related in one-to-one ratio. When its composition and proportion are different or change in quality and contamination exist or special processing and chemical treatment are performed even though the same object, it is necessary to avoid the measurement at these places or to use the measured values after compensating.
12.Miscellaneous How to use the Moisture reading checker(option) Press the electrode against the checker as shown in the following sketch in power ON condition. When the reading of the Meter matches the figure on the checker, the Meter's reading is acceptable. When the reading deviates from the checker's, please request our agent or the nearest our branch to calibrate the Meter.
Page 35
Products sold: Sales of Coating thickness meter Pinhole detector Condensator Viscosity cup Moisture meter Needle detector Iron piece detector Manufacturer: Sanko Electronic Laboratory Co., Ltd. ., 2 6 4, Tokyo branch Shibata Bldg Uchikanda Chiyoda-ku 101 0047, Tokyo Japan 81 3 3254 5031 81 3 3254 5038 ., 2 3,...
