PRE-ASSEMBLY
Before you begin: These instructions will guide you in properly assembling the unit. Please review all the steps before beginning
assembly. Carefully adhere to the Assembly Instructions and Owner's Manual to help ensure user safety and product integrity.
1. It is your responsibility to familiarize yourself with the proper use of the equipment and the inherent risks of inversion, such as
falling on your head or neck, pinching, entrapment or equipment failure.
2. This product is not designed for persons over 198 cm (6'6") or 136 kg (300 lbs). Structural failure could occur or head/neck may
impact floor during inversion. Serious injury or death could result.
3.
DO NOT
use this equipment without a licensed physician's approval and a review of the medical contraindications, as noted in
the Owner's Manual.
4. Failure to assemble and/or use the equipment as directed may void the manufacturer's warranty on this product and could result
in injury or death.
5.
DO NOT
use the inversion table until you have thoroughly and carefully read the Owner's Manual, viewed the Instructional Video,
reviewed all other accompanying documents, and inspected the equipment. The Instructional Video is in English. The steps in
the video directly coincide with the steps detailed in these Assembly Instructions.
6. Choose a level surface for assembling and operating the table.
7. Follow each step in sequence. Do not skip ahead.
8. Make sure that all fasteners are secure.
9.
PRIOR TO USE,
test and inspect the table. Make sure the table rotates smoothly to inverted position and back.
10. Replace defective components immediately and/ore keep the equipment out of use until repair.
Carefully remove the individual parts from the carton. You should have all of the items listed below. If any items are missing or
damaged, contact your retailer or customer service directly (See Pg. 4).
ITEMS FOR ASSEMBLY
A-frame base
w/ EZ-Angle Tether Strap
Main shaft w/ ankle clamp
Table frame with mat
Hand grips (2) and
13 mm
hex bolts (6)
(1/2")
Two (2) roller hinges
Two (2) wrenches
ASSEMBLY
STEP ONE
Assemble the A-frame Base (F71002)
•
Open the A-frame and make sure that the spreader arms are locked flat. (See
Figure 1)
Figure 2
(R)
ASSEMBLY INSTRUCTIONS
F9000
TM
!
F71002
ITEM #'s
F71002
F51008
F91039
F51021
F51069
F51008
H11202
F51064
F51088
NOTE: Bolts may be
packaged separately
or assembled in
hand grips.
STEP TWO
Install Hand Grips (F51069) on A-frame Base (F71002)
•
Place one of each hand grip (left / right) over the outside edge of the corre-
sponding hinge plate. (See Figure 2)
(L)
•
Insert three 13 mm (1/2") hex bolts (H11202) through the hinge plate into each
hand grip. Use the wrenches provided to tighten the bolts, being careful not to
over tighten.
DO NOT DISCARD - KEEP FOR FUTURE REFERENCE.
WARNING
F91039
F51021
Spreader Arms
U.S. and foreign patents apply. Other foreign patents pending.
F51069
F51088
H11202
Bolts may be
p a c k a g e d
separately or
a s s e m b l e d i n
hand grips.
F51064
Figure 1
