• Do not install the device in areas with a capacity of less than 70 m
• Do not install the device in areas of large drafts of air, near fans, vents, etc.
• Do not place the device in close proximity to sources of humidity.
• It is obligatory to have a carbon-dioxide (CO
• The room in which the device will be installed must have efficient ventilation to ensure
• Do not start the device before installation.
• Do not fill the fuel tank prior to installation
