3.7 PRINT 1 Mode ([5] key) : Perform at Production

<Figure 3.7-1> will be displayed after completion of printing
pressing the [5] key.
Before this inspection, set the "12 mm laminate black ink ribbon TZe tape cassette".
Start the printing by pressing the [Enter] key.
<Figure 3.7-2> will be displayed while printing.
After completion of printing, cut the tape and shift to
Perform at Production" (Figure 3.8-1
Print length : 440 dot (62.04 mm) from one end of frame to the other
P R N 1
Figure 3.7-1 PRINT 1 Mode Indication
P r i n t i n g . . .
* When change the country spec registration to the country
except U.S., display by the language after change.
Figure 3.7-2 In Printing Indication
Figure 3.7-3 Printing Pattern
display)
Figure 3.7-4 <Printing Pattern> of 9 mm tape
Figure 3.7-5 <Printing Pattern> of 6 mm tape
Figure 3.7-6 <Printing Pattern> of 3.5 mm tape
III - 39
<Figure
1 / 1
"3.8 CUT Mode ([6] key) :
3.5-9>, or by
