- Page 1 INSTALLATION AND OPERATION MANUAL AMC+ SERIES POWER AMPLIFIERS AMC+120P AMC+250P AMC+1202P AMC+460P...
-
Page 2: Important Safety Information
20. AMC+120P, AMC+250P, AMC+1202P, AMC+460P – Risk of hazardous 20. AMC+120P, AMC+250P, AMC+1202P, AMC+460P – Danger de voltage. voltage. Class 2 wiring should be used. -
Page 3: Introduction And Contents
INTRODUCTION AND CONTENTS AMC+ SERIES INTRODUCTION The Australian Monitor Installation Series AMC+ range of booster FRONT PANEL amplifiers take the rugged reliability of the famous AMIS range and deliver the same high quality audio reinforcement, in a low cost, REAR PANEL 2 rack unit package. -
Page 4: Front Panels
FRONT PANELS ALL MODELS HAVE THE SAME FRONT PANEL. This LED indicates the unit is powered “on”. POWER This switch switches power on or off the mains. The up position is on. To indicate hazards arising from dangerous voltages. Pour indiquer les risques résultant de tensions dangereuses. Hot surface! Don’t touch here! PAGE 4 AMC+ SERIES INSTALLATION AND OPERATION MANUAL... -
Page 5: Rear Panel
These 3 pin XLR sockets accept the source input for each IMPEDANCE AMC+120P AMC+250P AMC+1202P AMC+460P channel. One input is a male XLR, the other is a female XLR. The male XLR is normally used as a thru output. When... -
Page 6: Installation
INSTALLATION MOUNTING MONTAGE Your amplifier is designed for standard 19” rack mounting and occupies 2 EIA Cet ampli convient pour un montage en rack de 19” et a 2 unités de 3.5”. rackunits (3.5”). Les centres de montage sont: The mounting centres are: Vertical: 3.0”... - Page 7 0.35mm2) or spade lugs. The following table should be used as a guideline for cable sizes. Regulations in your area may require different gauged wire and should be checked before using. OUTPUT DISTANCE WIRE SIZE AMC+120P / AMC+1202P AMC+250P AMC+460P 100V Up to 50m AWG24(0.2mm2) AWG22(0.35mm2)
-
Page 8: Troubleshooting
Volume controls down Check volume controls Amplifier has overheated Check for obstructions above and below Make sure the amplifier is well ventilated DC fuse(s) blown Refer product to local Australian Monitor dealer PAGE 8 AMC+ SERIES INSTALLATION AND OPERATION MANUAL... -
Page 9: Block Diagram
BLOCK DIAGRAM Single channel amplifier shown here AMC+ SERIES INSTALLATION AND OPERATION MANUAL PAGE 9... - Page 10 DIMENSIONS ALL MODELS HAVE THE SAME FRONT & REAR PANEL DIMENSIONS. AMC+120P AMC+250P AMC+1202P AMC+460P PAGE 10 AMC+ SERIES INSTALLATION AND OPERATION MANUAL...
-
Page 11: Specifications
SPECIFICATIONS AMC+ 120P AMC+ 250P AMC+ 1202P AMC+ 460P POWER OUTPUT (0.5%THD, 1KHZ) 120 W 250 W 2 x 120 W 4 x 60 W S/N RATIO >88 dBr >88 dBr >88 dBr >82 dBr FREQ RESPONSE (-3DB +1DB) 50 Hz–20 kHz 40 Hz–20 kHz 50 Hz–20 kHz 50Hz–20kHz... - Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: Level 7, 130 Pitt Street, Sydney NSW 2000 Australia. Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au...
