9 INCH LCD TWIN HEADREST
ENTERTAINMENT PACKAGE
with BUILT-IN DVD-CD PLAYER
SPECIFICATIONS
- 9 Inch (23cm) LCD-TFT Touch Monitor
- 800 x 480 Pixels Resolution
- LED Backlight
- 16:9 Screen Format
- DVD/CD/VCD.RMVB/MP3/WMA/DIVX/MPEG4 Playback System
- USB 2.0 Port (Front Panel)
- SD/MMC/MS Card Reader (Front Panel)
- AV Input (Front Panel)
- Optional DC Input (Front Panel)
- IR Transmitter (2 Ch for Wireless Headphones)
- Wireless FM Modulator (8 Ch for Audio Output)
- On-Board Stereo Speakers
- Video Games (included)
- PAL/NTSC/AUTO Colour System
- Universal Headrest Replacement
- Adjustable Tilt
- Removable Monitor Covers with Zippers (for Safety & Protection)
- 6-Pole Adapters (12/12.5/12.7/13.8/14/16 mm)
- 12V DC Input / Negative Ground
--10° ~ +55°C Operating Temperature
- 250(L) x 200(W) x 145(H)mm Dimensions
AX1509
INSTRUCTION MANUAL
Removable
Flap Covers
Flap Covers
with Zipper
with Zipper
INCLUDED:
- 2 x 9 Inch LCD Twin Headrest Entertainment Packages
- 1 Pair of Universal Headrests Included
- 2 Pairs of Folding IR Headphones
- 2 x Remote Control (Dual Function)
- 2 x Removable Flap Covers with Zipper
- 6 Sets of Pole Adapters (12/12.5/12.7/13.8/14/16 mm)
- Installation Wiring & Hardware
- 6 x AAA Batteries
- 2 x Video Game Discs
- 2 x Cig Power Leads
2
YEAR
WARRANTY
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Axis AX1509
Summary of Contents for Axis AX1509
-
Page 1: Specifications
AX1509 9 INCH LCD TWIN HEADREST ENTERTAINMENT PACKAGE with BUILT-IN DVD-CD PLAYER Removable Flap Covers Flap Covers with Zipper with Zipper SPECIFICATIONS - 9 Inch (23cm) LCD-TFT Touch Monitor INCLUDED: - 800 x 480 Pixels Resolution - 2 x 9 Inch LCD Twin Headrest Entertainment Packages... -
Page 3: Table Of Contents
CONTENTS Precautions Notice before operation Accessories Battery installation of remote control Application of remote control Remote Control Function Touchscreen Menu Disc Play Controls Basic Setup Disc Setup Audio Setup Digital Setup Operation for games Trouble Shooting Technical Specification Pole Installation... -
Page 4: Precautions
PRECAUTIONS Thank you for purchasing this Axis product. Please carefully read these instructions and retain for future reference. Caution • For the sake of safety, do not install monitor within view of the driver. • The product contains high voltage. Do not attempt to dismantle or repair without professional assistance. -
Page 5: Accessories
ACCESSORIES Please check the following accessories after opening the package: Remote Control Native Game Disc Instruction Manual Pole Adaptors Headphones Power Connection Line with AV Cable HEADREST [PILLOW TYPE] DVD INSTALL METHOD Remove the original headrests. Match the steel pole spacing to the original diameter. -
Page 6: Battery Installation Of Remote Control
REMOVE DISC (1) Press key to eject the disc. (2) Do not scratch the surface when handling the disc. (3) Carefully store the disc. BATTERY INSTALLATION OF THE REMOTE CONTROL 1. At positions A and B on the remote control, press A in the arrowhead direction and then retract the battery holder. -
Page 7: Application Of Remote Control
PRECAUTIONS FOR REMOTE CONTROL • Please remove the PVC sheet (if present) to activate the remote control. • Point remote control in a straight line to receiver. Any barrier may affect the signal. • A strong light source may affect the efficiency of the device •... -
Page 8: Remote Control Function
REMOTE CONTROL FUNCTIONS START Load GAMES Disc,then press this START key to begin playing games. MODE Return to the Submenu PBC/MENU Press this key to return to the root menu in playing . POWER Power ON/OFF TFT MENU Menu for different functions:Brightness,contrast,IR etc. DISPLAY Display the disc information and play time. -
Page 9: Touchscreen Menu
TOUCHSCREEN MENU Choose the menu for Disc/USB/SD or AV and also control IR/FM/Speaker/Brightness and Contrast directly by touching the icons on the LCD. Touch OPEN to Display the panel. Touch OPEN again to close. Figure 1 AV IN USB/SD Card readers Main Panel IR OUT FM OUT... -
Page 10: Disc Play Controls
DISC PLAYING Touch Disc icon on the panel. The unit will enter into Disc reading mode. Control IR/FM/Speaker volume, brightness and contrast [Figure 2] Figure 2 IR in disc play mode MENU in disc play mode NUMBER CHOICE VOLUME MENU PLAYING... - Page 11 To use FM function, please find the FM Mode icon in the menu. Select to open or close FM Mode. To transfer the sound to your car audio system, make sure your car radio frequency is exactly the same as the AX1509.
-
Page 12: Basic Setup
BASIC SETUP Touch Setup key and the LCD will display as Figure 1. Touch desired function, then the submenu will display. Set up one by one. Touch Back to exit the setup Menu. Figure 1 1. System (see Figure 3) Touch System to set up the Panel calibration and version. -
Page 13: Disc Setup
2. Disc (see Figure 4) (1) Touch key to enter setup. Touch disc then screen will display setup OSD, Languages, Audio Language, Subtitle Language, Password and Rating. (2) Touch desired language option. Multiple languages are available for selection including: English, Japanese, German, Spanish, French, Portuguese and Russian. (3) Touch setup key to enter the setup system. -
Page 14: Audio Setup
3. Audio Setup 4. Speaker Setup... -
Page 15: Digital Setup
4. Digital Setup NOTE: LT/RT: If the disc has PROLOGIC dolby stereo effect, the disc signal can produce a cinema effect decoded by the player. Stereo: for 5.1 channel output, the audio will output two roads of signal (left channel and right channel) Virtual Sound: in playing 5.1 channel recorded discs, the main channel will output the virtual surround effect. -
Page 16: Operation For Games
OPERATION FOR GAME FUNCTION The player features game functions. 2 in 1 Remote Control 1. Description for Game Disc Operation (1) Press Eject and load the game disc. The game main menu will display in seconds. (2) Press direction key of the function control or game controller to select the games and then press ENTER on the function control or press START on the game controller to enter the game. -
Page 17: Troubleshooting
TROUBLESHOOTING SYMPTOM SOLUTIONS No Response 1. Check all power connections. 2. Check power is on. No Sound 1. Check whether the volume is on the main position or in Mute. 2. No sound from Unit: Check if FM or IR transmit status has been selected. -
Page 18: Technical Specification
TECHNICAL SPECIFICATIONS AND PARAMETERS PRODUCT NAME AUTOMOBILE HEADREST DVD PLAYER Disc Type MP3/DVD/SVCD/VCD/DVCD/CD/CDG/WMA/JPEG/CD-R/ (signal source) CD-RW Display 9” TFT LED digital touch panel (16:9) Output Port Audio: Stereo Video: Complex video signal output (AV) USB Port MS/MMC/SD Card Port Video System PAL/NTSC/AUTO Video 1.0Vp-p (75ohm) -
Page 19: Pole Installation
METAL POLES DETAILS PICTURE 2. Use screwdriver to 3. Insert the metal pole 4. Assemble as shown. 1. Take out the product from the gift box. loosen four screws on into the round hole of the white plastic cover the white plastic cover. on the bottom of the unit. - Page 20 AX1509...
