FortiAnalyzer-2000B
®
Version 4.0 MR1
Rack and Hardware Install Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FortiAnalyzer-2000B and is the answer not in the manual?

Questions and answers

Related Manuals for Fortinet FortiAnalyzer-2000B

Summary of Contents for Fortinet FortiAnalyzer-2000B

  • Page 1 FortiAnalyzer-2000B ® Version 4.0 MR1 Rack and Hardware Install Guide...
  • Page 2 FortiGuard-Antivirus, FortiGuard-Intrusion, FortiGuard-Web, FortiLog, FortiAnalyzer, FortiManager, Fortinet®, FortiOS, FortiPartner, FortiProtect, FortiReporter, FortiResponse, FortiShield, FortiVoIP, and FortiWiFi are trademarks of Fortinet, Inc. in the United States and/or other countries. The names of actual companies and products mentioned herein may be the trademarks of their respective owners.

  • Page 3: Table Of Contents

    Installing a Hot-Swap Hard Drive ............... 24 Removing a Hard Drive From a Hard-Drive Carrier ........... 25 Installing a Hard Drive Into a Hard-Drive Carrier ..........25 Index......................27 FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...
  • Page 4 Contents FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...

  • Page 5: Introduction

    • Conventions Registering your Fortinet product Before you begin, take a moment to register your Fortinet product at the Fortinet Technical Support web site, https://support.fortinet.com. Many Fortinet customer services, such as firmware updates, technical support, and FortiGuard Antivirus and other FortiGuard services, require product registration.

  • Page 6: Fortinet Tools And Documentation Cd

    Fortinet Tools and Documentation CD Many Fortinet publications are available on the Fortinet Tools and Documentation CD shipped with your Fortinet product. The documents on this CD are current at shipping time. For current versions of Fortinet documentation, visit the Fortinet Technical Documentation web site, http://docs.fortinet.com.
  • Page 7 Type a name for the remote VPN peer or client, such as Central_Office_1. Navigation Go to VPN > IPSEC > Auto Key (IKE). FortiAnalyzer Rack and Hardware Publication For details, see the Install Guide FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...
  • Page 8 Conventions Introduction FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...

  • Page 9: Rack Installation Instructions

    Rack Installation Instructions Rack Installation Instructions The FortiAnalyzer-2000B comes with a sliding rail kit. Use the instructions below to install the rails. Caution: Only trained service technicians are authorized to remove the system cover and access any of the components inside the system. Before you begin, review the safety instructions that came with the system.
  • Page 10 Position the left and right rail end pieces of the rail module labeled FRONT facing inward and orient each end piece to seat in the round holes on the front side of the vertical rack flanges (7). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...
  • Page 11 4 To install the system into the rack, do the following: • Pull the inner slide rails out of the rack until they lock into place (11). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...
  • Page 12 (14). 5 To engage and release the slam latch, do the following: • Facing the front, locate the slam latch on either side of the system (15). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...
  • Page 13 Phillips screwdriver (17). 6 To route the cables, do the following: • Locate the inner and outer CMA brackets on the interior sides of both rack flanges (18). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...

  • Page 14: Removing The System From The Rack

    Removing the system from the rack To remove the system from the rack 1 Locate the lock levers on the front ends of both inner rails (1). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...

  • Page 15: Cable Management Arm Installation

    J-slots. Lift the system up and away from the rack and place on a level surface (3). Cable Management Arm Installation The FortiAnalyzer-2000B comes with a Cable Management Arm. Use the instructions below to install the Cable Management Arm.
  • Page 16 Align and engage each side of the tray with the receiver brackets on the inner edges of the rails and push forward until the tray clicks into place (4). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/...
  • Page 17 At the back of the system, fit the latch on the front end of the CMA on the innermost bracket of the slide assembly until the latch engages (6). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/...
  • Page 18 4 To move the CMA away from the CMA tray, do the following: • The CMA can be pulled away from the system and extended away from the tray for access and service (9). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...
  • Page 19 CMA. • Using the tie wraps provided, bundle the cables together as they enter and exit the baskets so they do not interfere with adjacent systems (11). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...

  • Page 20: Installing The Bezel

    3 Rotate the left end of the bezel away from the system to release the right end of the bezel. 4 Pull the bezel away from the system. See Figure 13. FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...

  • Page 21: Connecting The Keyboard, Mouse, And Monitor

    The connectors on the back of your system have icons indicating which cable to plug into each connector. Be sure to tighten the screws (if any) on the monitor's cable connector. FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/...

  • Page 22: Connecting The Power Cables

    Plug the other end of the power cables into a grounded electrical outlet or a separate power source such as an uninterruptible power supply (UPS) or a power distribution unit (PDU). FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...

  • Page 23: Turning On The System

    Figure 16: Securing the power cord Turning on the System Press the power button on the system and the monitor. The power indicators should light. Figure 17: Turning on the system FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...
  • Page 24 Turning on the System Rack Installation Instructions FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...

  • Page 25: Installing Hard Drives

    2 Grasp the front of the hard-drive blank, press the release lever on the right side, and slide the blank out until it is free of the drive bay. See Figure 1. FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/...

  • Page 26: Installing A Hard-Drive Blank

    Inserting a hard-drive carrier and attempting to lock its handle next to a partially installed carrier can damage the partially installed carrier's shield spring and make it unusable. FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...

  • Page 27: Removing A Hard Drive From A Hard-Drive Carrier

    When aligned correctly, the back of the hard drive will be flush with the back of the hard-drive carrier. 3 Attach the four screws to secure the hard drive to the hard-drive carrier. FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ •...
  • Page 28 Installing Hard Drives Figure 3: Installing a Hard Drive into a Drive Carrier hard-drive carrier screws (4) hard drive SAS screw hole FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...

  • Page 29: Index

    25 system installing, 24 turning on, 21 mixed configurations, 23 removing, 24 hot-swap hard drives, 23 technical support, 3 turning on the system, 21 FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...
  • Page 30 Index FortiAnalyzer-2000B Version 4.0 MR1 Rack and Hardware Install Guide Revision 1 http://docs.fortinet.com/ • Feedback...
