Foundation Logic View Configuration Manual page 75

DF65 – LogicView Configuration Manual
CLASS
I
P
O
Tables 5 e 6
A-Crude Oil
B-Generalized
products
C-MTBE
D-Lubricating oil
Control Word (CTW)- Select Products
The type of product should be selected in this field. Available products are crude oil, generalized
products, MTBE and lubricating oil. Once the inputs and product are selected, we have the table
that will be used in the calculations.
Control Word (CTW)- Select Output
The user should set the type of the output. There are 2 options:
VCF
CCF
Tables
Once the user has set inputs, product and output will have to be implicitly set a table of the API
standard.
Input Scale Conversion Factors Conversion
The Input scale has two factors (parameters the user must set) to convert these parameters to
engineering units (EU). IN1 input must be adjusted through the parameters K1 (GAIN) and K2
(BIAS). Similarly IN2 input must be set through parameters K3 (GAIN) and K4 (BIAS). After
conversion they will be in the following format:
Density (EU)= IN1*K1+K2
Temperature (EU)=IN2*K3+K4
Pressure (EU)=IN3*LOW+HIGH
MNEM DESCRIPTION
EN INPUT ENABLE
IN1 DENSITY AND CORRECTED DENSITY INPUT
IN2 TEMPERATURE INPUT
CTW CONTROL WORLD
INPUT GAIN FOR DENSITY TO CONVERT IT TO
K1 ENGINEERING UNITS ACCORDING TO THE TABLES
ATTACHED.
INPUT BIAS FOR DENSITY TO CONVERT IT TO
K2 ENGINEERING UNITS ACCORDING TO THE TABLES
ATTACHED.
INPUT GAIN FOR TEMPERATURE TO CONVERT IT TO
K3 ENGINEERING UNITS ACCORDING TO THE TABLES
ATTACHED
INPUT BIAS FOR TEMPERATURE TO CONVERT IT TO
K4 ENGINEERING UNITS ACCORDING TO THE TABLES
ATTACHED.
COEFFICIENT FOR THERMAL EXPANSION AT 60 ºF OR
K5
15ºC (1/ ºF OR 1/ ºC)
A VCF
B F – COMPRESSION FACTOR
PRESSURE INPUT GAIN TO BE CONVERTED IN
LOW ENGINEERING UNITS ACCORDING TO THE TABLES
ATTACHED
PRESSURE INPUT BIAS TO BE CONVERTED IN
HIGH ENGINEERING UNITS ACCORDING TO THE TABLES
ATTACHED.
R_PTR NOT USED
ENO OUTPUT ENABLE
LOW INPUT DATA WITHIN EXTRAPOLATION RANGE
HIGH INPUT DATA OUT OF EXTRAPOLATION RANGE
OUT OUTPUT: VCF VALUE OR INTERMEDIATE
I: Input. P: Parameter. O: Output. V: Variable
Inputs
API Gravity
Temperature Range(oF)
Range (oAPI)
0 up to 100 0 up to 300
0 up to 85 0 up to 300
(*) 0 up to 300
-10 up to 45 0 up to 300
TYPE
BOOLEAN
REAL
REAL
WORD
REAL
REAL
REAL
REAL
REAL
REAL
BOOLEAN
BOOLEAN
BOOLEAN
REAL
Outputs
Intermediate (table 5)
API at 60 oF
0 up to 100 oAPI
0 up to 85 oAPI
0.00027 up to 0.00097 oF-1
-10 up to 45 oAPI
Final (table 6)
VCF at 60 oF
2.59
