Foundation Logic View Configuration Manual page 22

ACC_N
CLASS MNEM
EN
CLEAR
IN1
I
IN2
IN3
IN4
FACTOR1
FACTOR2
FACTOR3
FACTOR4
TR_ON1
TR_OFF1
P
TR_ON2
TR_OFF2
TR_ON3
TR_OFF3
TR_ON4
TR_OFF4
MP
ENO
MEM1
MEM2
O
MEM3
MEM4
THR1
THR2
THR3
THR4
TACC1
TACC2
TACC3
TACC4
TAMC
V OVRFLW
B_THR
INCR1
INCR2
INCR3
INCR4
2.6
PULSE ACCUMULATOR
DESCRIPTION
INPUT ENABLE
CLEARS TOTALIZATION AND SENDS ALL VALUES TO THE MEM OUTPUTS
PULSE INPUT 1
PULSE INPUT 2
PULSE INPUT 3
PULSE INPUT 4
SCALE CONVERSION FACTOR (EU) OF INPUT 1.
SCALE CONVERSION FACTOR (EU) OF INPUT 2
SCALE CONVERSION FACTOR (EU) OF INPUT 3.
SCALE CONVERSION FACTOR (EU) OF INPUT 4.
TR_ON HYSTERESIS UPPER LIMIT
TR_OFF HYSTERESIS LOWER LIMIT
TR_ON HYSTERESIS UPPER LIMIT
TR_OFF HYSTERESIS LOWER LIMIT
TR_ON HYSTERESIS UPPER LIMIT
TR_OFF HYSTERESIS LOWER LIMIT
TR_ON HYSTERESIS UPPER LIMIT
TR_OFF HYSTERESIS LOWER LIMIT
TIME WHERE PULSES ARE COUNTED
ENABLE OUTPUT
VALUE OF ACCUMULATED PULSES
VALUE OF ACCUMULATED PULSES
VALUE OF ACCUMULATED PULSES
VALUE OF ACCUMULATED PULSES
INDICATES IF HYSTERESIS LIMITS WERE REACHED FOR INPUT 1
INDICATES IF HYSTERESIS LIMITS WERE REACHED FOR INPUT 2
INDICATES IF HYSTERESIS LIMITS WERE REACHED FOR INPUT 3
INDICATES IF HYSTERESIS LIMITS WERE REACHED FOR INPUT 4
PULSE ACCUMULATOR OF INPUT 1
PULSE ACCUMULATOR OF INPUT 2
PULSE ACCUMULATOR OF INPUT 3
PULSE ACCUMULATOR OF INPUT 4
TIME ACCUMULATOR (TIMER)
OVERFLOW INDICATION OF TOT AND MEM
BOOLEAN THRESHOLD AND STATUS
INCREMENTS FOR CARRY OVER
INCREMENTS FOR CARRY OVER
INCREMENTS FOR CARRY OVER
INCREMENTS FOR CARRY OVER
I: Input. P: Parameter. O: Output. V: Variable
Function Blocks
TYPE
BOOL
BOOL
INT
INT
INT
INT
REAL
REAL
REAL
REAL
INT
INT
INT
INT
INT
BOOL
REAL
REAL
REAL
REAL
REAL
REAL
REAL
REAL
INT
INT
INT
INT
INT
BYTE
BYTE
REAL
REAL
REAL
REAL
