DF65 – LogicView Configuration Manual
SQR
CLASS
I
P
O
V

Square Root (SQR)

Description
This function block will find the square root of the input and places the result in the OUT output. If IN
is negative, OUT= 0 then the ENO output will indicate false.
Control World - Input/Output Type
The data type in the inputs and outputs may be set as "Regular" or "Percentages".
If the Percentage option was chosen, then there are two modes of operation:
If the input was set to integer:
=
OUT 100 * IN
If the input was set to real:
=
OUT 10 * IN
Option "Regular" will make the function block operate normally, i.e. calculating the SQR function
directly.
SQUARE ROOT
MNEM DESCRIPTION
EN INPUT ENABLE
IN INPUT
CTW CONTROL WORLD
CTO LEVELING
ENO OUTPUT ENABLE
OUT OPERATION RESULT
PER PERCENTAGE OPERATION
I: Input. P: Parameter. O: Output. V: Variable
IF EN=1 THEN
ENO := 1
OUT := SQR( IN )
ELSE
ENO := 0
OUT := 0
TYPE
BOOLEAN
ANY_NUM
WORD
REAL
BOOLEAN
ANY_NUM
WORD
2.39
