User Guide
Install the Camera
1
Remove fixed block,install the camera on retainer plate,
then fix the camera with retainer bar and screws.
Fixed block
!
Attention!
Knob ring
Reference
point
Loosen the knob ring and adjust
the arm length to fit the different
cameras.
Session
(1) Please install the camera before powering
on the gimbal.
(2 )When not in use, turn off the gimbal and then
remove the camera.
Attention: Make sure the camera is secure
before powering on the gimbal.
Power On: Press and hold function button
until the green light is on.
Hero4
Power Off: Press and hold function button
until the red light changes from quick
Hero5
Cross
flashing to always on.
arm
Power on / off
2
!
In case of low battery, the red LED
indicator flashes for three times for
every 5 seconds.Please charge WG2.
2
