  • Page 1 CQUBE SE20 BARISTA USER MANUAL UM_EN Part No.: 1764020_02...

  • Page 2: Table Of Contents

    CONTENT CQube SE20 BARISTA CONTENT ................................ 2 GENERAL ................................4 Introduction ................................4 Warnings ..................................4 Precautions ................................4 Intended use ................................4 Facts & weight ................................5 OVERVIEW OF COMPONENTS ......................6 Front exterior................................6 Front interior ................................7 Button functions ...............................8 User card ...................................9 INSTALLATION AND START-UP ..................... 10 Connecting CQube SE to BARISTA module ....................
  • Page 3 How to upload new recipe into machine ......................34 Drink menu options ............................. 35 Clean machine ............................... 36 Counters ................................. 37 DIMENSION SKETCH ..........................39 CQube SE20 BARISTA ............................39 CQube SE20 ................................40 BARISTA ................................41 Some important information may appear in textboxes seen below IMPORTANT! CAUTION! More INFO.

  • Page 4: General

    GENERAL CQube SE20 BARISTA Introduction Thank you for choosing a CQube SE20 BARISTA espresso vending machine. We hope you enjoy it ! Read the user guide before using the machine. Always keep this guide close at hand for future reference.

  • Page 5: Facts & Weight

    GENERAL CQube SE20 BARISTA Facts & weight FACTS CQUBE SE20 BARISTA Drink options 1-12 Function for selecting jug Grinder type 2 x EK-7 Number of bean hoppers Number of ingredient canisters Brewer type Espresso Touchscreen Standard Espresso pump type Vibration pump...

  • Page 6: Overview Of Components

    OVERVIEW OF COMPONENTS CQube SE20 BARISTA Front exterior Bean hoppers Touchscreen Drink menu ESPRESSO DRINKS Start energy save mode Door lock Smart-card reader Outlet hot drinks Cup shelf Drip grids Drip tray Door handle Barista unit...

  • Page 7: Front Interior

    OVERVIEW OF COMPONENTS CQube SE20 BARISTA Front interior Chocolate canister Bean hoppers Bean stops Grinders Grinder adjustment wheels Grinder outlets Espresso group Mixing bowl Milk fridge Drink outlets Milk waste container Waste box Ingredient canisters DETAIL INGREDIENTS WIDTH DEPTH HEIGHT CAPACITY...

  • Page 8: Button Functions

    OVERVIEW OF COMPONENTS CQube SE20 BARISTA Touchscreen navigation Button functions Choose drink type Double Espresso Coffee Double Espresso Coffee by pressing the icon on the touchscreen. Cappuccino Cafe Latte Cappuccino Cafe Latte Choco-milk Pitcher Milk Hot Water Double Espresso START...

  • Page 9: User Card

    OVERVIEW OF COMPONENTS CQube SE20 BARISTA User card Face Back User card Is used for cleaning and see counter settings. User card is supplied by your dealer. Insert the user card with the chip forward as in the figure A.

  • Page 10: Installation And Start-Up

    INSTALLATION AND START-UP CQube SE20 BARISTA Connecting CQube SE to BARISTA module Connect the communication cable and water tubes correctly as figure. Don’t mix the position of the A, B,C and D. Otherwise the machine will not function properly.
  • Page 11 INSTALLATION AND START-UP CQube SE20 BARISTA Connecting CQube SE to BARISTA module Guide the milk tube from the outlet beam Slide the front and back profiles in the middle through the holes in side panel of the machine of these two machine (E), push the profiles all and barista unit.

  • Page 12: Positioning

    INSTALLATION AND START-UP CQube SE20 BARISTA Positioning Place the machine on a flat horizontal surface that will minimum 10cm support the weight of the machine. After you have connected all water tubes and assembled the front and back profiles, push machine into position according to the picture.

  • Page 13: Fill Ingredient Canister And Bean Hopper

    INSTALLATION AND START-UP CQube SE20 BARISTA Fill ingredient canister and bean hopper Lift the lid and fill the bean hopper with freshly Open the door. roasted coffee beans without additives. also lift the barista lid and fill chocolate powder. When filling the chocolate powder, keep the opening of the canister chute upwards.

  • Page 14: Operation

    OPERATION CQube SE20 BARISTA Brewing a cup of coffee Double Espresso Coffee Double Espresso Coffee Cappuccino Cafe Latte Cappuccino Cafe Latte Choco-milk Pitcher Milk Hot Water Double Espresso START Place a cup under the outlet for hot drinks. (A) Choose drink by pressing the drink button on the screen.

  • Page 15: Cleaning Program

    CLEANING PROGRAM CQube SE20 BARISTA Detailed cleaning instructions Clean brewer Total cleaning time about 5 minutes. Espresso cleaning tablets are avalible from your dealer: Part No.: 1104171 IMPORTANT! After cleaning of the Open the door. brew mechanism is Press ENTER on the cleaning panel inside the door. (See fig. A)

  • Page 16: Clean Mixer

    CLEANING PROGRAM CQube SE20 BARISTA Detailed cleaning instructions Clean mixer Cleaning means rinsing with water and rotating the whipper. Cleaning of the mixing bowl should be performed once per day. Open the door. Press ENTER on the cleaning panel inside the door. (See fig. A) Cleaning Hot key appears on the display (Cleaning panel is now active).

  • Page 17: Clean Valves

    CLEANING PROGRAM CQube SE20 BARISTA Detailed cleaning instructions Clean valves Cleaning entails that the valves “knock” off any lime scale and other particles that may get stuck in the cylinders and flushing them with water. Open the door. Press ENTER on the cleaning panel inside the door. (See fig. A) Cleaning Hot key appears on the display (Cleaning panel is now active).

  • Page 18: Daily Milk Clean

    CLEANING PROGRAM CQube SE20 BARISTA Detailed cleaning instructions Daily milk clean This cleaning is also scheduled to run every night at 03:00 Milk system cleaning liquid are avalible from your dealer: Part No.: 1104165 Open the door. Press ENTER on the cleaning panel inside the door. (See fig. A) Cleaning Hot key appears on the display (Cleaning panel is now active).

  • Page 19: Rotate Brewer

    CLEANING PROGRAM CQube SE20 BARISTA Detailed cleaning instructions Rotate brewer This function can be used to position the espresso brewer so it’s easier to remove and get access to the filter in bottom of brew cylinder for cleaning. Open the door.

  • Page 20: Rinse Brewer

    CLEANING PROGRAM CQube SE20 BARISTA Detailed cleaning instructions Rinse brewer Open the door. Press ENTER on the cleaning panel inside the door. (See fig. A) Cleaning Hot key appears on the display (Cleaning panel is now active). the display shows: Cleaning Hot Key Put a jug or container for at least 200ml at the brewer outlet.

  • Page 21: Backflush Milk System

    CLEANING PROGRAM CQube SE20 BARISTA Detailed cleaning instructions Backflush milk system This cleaning should be preformed when changing milk bag or milk container. Open the door. Press ENTER on the cleaning panel inside the door. (See fig. A) Cleaning Hot key appears on the display (Cleaning panel is now active).

  • Page 22: Cleaning And Care

    CLEANING AND CARE CQube SE20 BARISTA Weekly cleaning Disassemble the espresso group Open the door and remove the waste box. Press down the safety ring on the connector simultaneously pull the teflon tube straight up. Loosen the fixation screw at the bottom of the brewer.

  • Page 23: Cleaning The Espresso Group

    CLEANING AND CARE CQube SE20 BARISTA Cleaning the espresso group First, remove the espresso group from the machine as explained earlier in this manual. Then proceed to clean it with neutral detergents (avoid solvents that could damage paint or plastics). Disinfectant products as chlorine-detergents are preferred.

  • Page 24: Reassemble The Espresso Group

    MAINTENANCE AND CARE CQube SE20 BARISTA Reassemble the espresso group “Click” Replace the brewer in front of the gearbox. Attach top part at the back of the brewer to the hooks on the gearbox. push in the bottom part untill a click is felt.

  • Page 25: Disassemble Mixing System

    CLEANING AND CARE CQube SE20 BARISTA Weekly cleaning Disassemble mixing system Pull out the outlet hose. Turn the mounting plate lever anticlockwise. Loosen the mixing bowl by pulling it straight out. Loosen the whipper by pulling it straight out. Loosen the mounting plate. Turn the lever anticlockwise, until it stops.

  • Page 26: Wash These Parts

    CLEANING AND CARE CQube SE20 BARISTA Weekly cleaning Wash these parts Clean with a moist Mixing Bowl Mounting Plate Whipper cloth and wipe dry. All parts must be dry before reassembly. Reassemble mixing system The flat side of the whipper shaft must correspond Check all seals(red) before with the marked arrow(A) on the whipper.

  • Page 27: Clean Fridge And Milk Container

    CLEANING AND CARE CQube SE20 BARISTA Clean fridge and milk container This cleaning should be preformed at least once a week. Milk container Open the fridge door and take out the milk container. Milk waste container Clean inside of the fridge with a soft cloth.

  • Page 28: Reset Counter For Milk Cleaning

    CLEANING AND CARE CQube SE20 BARISTA Reset counter for milk cleaning Reset Soldout Fig. B Milk Cleaner Double Espresso Coffee Double Espresso Coffee Cappuccino Cafe Latte Cappuccino Cafe Latte Choco-milk Pitcher Milk Hot Water Milk Cleaner Milk Cleaner Fig. C...

  • Page 29: Replace The Milk Cleaning Bottle

    CLEANING AND CARE CQube SE20 BARISTA Replace the milk cleaning bottle Open the door and remove the waste box. Take out the bottle and unscrew the old bottle (A). Keep the lid and tube connected to the machine, replace with a new bottle (B) Place the bottle into the original position.

  • Page 30: Empty Drip Trays And Containers

    CLEANING AND CARE CQube SE20 BARISTA Empty drip trays and containers Empty Drip Tray If the madchine indicate Emty Drip Tray (A), there is three different trays that might need to be emptied. ENTER Check the containers shown below and empty the water.

  • Page 31: Exterior Cleaning

    CLEANING AND CARE CQube SE20 BARISTA Exterior cleaning ESPRESSO DRINKS Exterior cleaning when necessary To clean the exterior of the machine, use a soft cloth and liquid cleaning agent that is non-abrasive. If using machine equiped with touchscreen do not spray cleaning liquid directly on the display.

  • Page 32: Message Shown On Display

    MESSAGE SHOWN ON DISPLAY CQube SE20 BARISTA Message on display Indication The machine is in energy saving mode. Energy Saving Mode Not Available Drink can not be selected as jug. Heating Water Low temperature in the water tank, the machine is heating up (blocked).

  • Page 33: Programming

    PROGRAMMING CQube SE20 BARISTA Activate programming with the user card Insert user card in the card reader (A) The display will look like this:...

  • Page 34: How To Upload New Recipe Into Machine

    PROGRAMMING CQube SE20 BARISTA How to upload new recipe into machine Insert service card(A) and open machine door. Insert the USB flash drive into the USB connection(B) inside the door. The machine must show the service menu before you Note insert the USB.

  • Page 35: Drink Menu Options

    PROGRAMMING CQube SE20 BARISTA Drink menu options Drink menu 1 Recipe file name: 422_x_CQube_SE20_Barista.mef Espresso Double Espresso Coffee Americano Using left grinder: Using right grinder: Coffee Cappuccino Cafe Latte Latte Macchiato Choco-milk Double espresso Americano Coffee Cappuccino Pitcher Milk Hot Water Café...

  • Page 36: Clean Machine

    PROGRAMMING CQube SE20 BARISTA Clean machine Open the door. Press ENTER on the cleaning panel Cleaning Hot Key inside the door. Choose button X for each cleaning. See the pages for cleaning programs in order to perform cleaning. Press Clean Brewer...

  • Page 37: Counters

    PROGRAMMING CQube SE20 BARISTA Counters See the counter of each drink or total counters for all Service Menu drinks. It’s also possible to reset the drink counters. Counters Service Menu Counters Press ENTER Press Press Counters Beverage Counters Drink 1...
  • Page 38 PROGRAMMING CQube SE20 BARISTA Counters See the number of times cleaning has been performed Service Menu or reset the clean counter. Counters Press Clean Counter Counters ENTER Brewer xxx Clean Counter Press to go forward in the menu Clean Counter...

  • Page 39: Dimension Sketch

    DIMENSION SKETCH CQube SE20 BARISTA Dimensions CQube SE20 BARISTA Model CQube SE20 BARISTA 818mm 562mm 532mm 50mm...

  • Page 40: Cqube Se20

    DIMENSION SKETCH CQube SE20 BARISTA Dimensions CQube SE20 Model CQube SE20 818mm 290mm 532mm 110mm 155mm...

  • Page 41: Barista

    DIMENSION SKETCH CQube SE20 BARISTA Dimensions BARISTA Model BARISTA 818mm 222mm 456mm...
  • Page 44 For the warranty to be valid the conditions for maintenance must have been followed according to our instructions, proper precaution has been made and warranty claim been issued without delay. The affected equipment may not be used during awaiting service if there is any risk that the damage or defect would worsen.
