Page 1: Setup Guide
MC-i3 1000082-06: MC-I3 Dig UHF II W/ Modem, BT, & Single GPS 1000082-07: MC-I3 Dig UHF II W/ Modem, BT, & Dual GPS 1000082-08: MC-I3 FH915+ W/ Modem, BT, Single GPS 1000082-09: MC-I3 FH915+ W/ Modem, BT, Dual GPS INSTALLATION AND... - Page 2 INTRODUCTION The MC-i3 comes in a number of different configurations. This manual covers MC-i3’s that contain DUHF2 or FH915+ modems. These units can be purchased as part of a machine control kit which may contain: 1000082-XX: MC-i3 o 1000082-06: Assy, MC-I3 Dig UHF II W/ Modem, BT, & Single GPS o 1000082-07: Assy, MC-I3 Dig UHF II W/ Modem, BT, &...
- Page 3 SL-100 SIM CARD INSTALLATION SIM Card installation relates to all MC-i3 models. For the Models covered in this manual, the SIM card is optional. 1. Remove the eight (8) retaining screws from the base of the MC-i3, and remove the base 2.
- Page 4 TRU. If the GPS serial number ID is not set in each of the GPS boards in the MC-i3, it can be set using TRU. Connect in receiver managing mode -> Information. Click on the Cog icon at the bottom of the receiver...
- Page 5 Bluetooth It is possible to connect to the MC-i3 using Bluetooth. Bluetooth is connected to Port C of the Main GPS board. Bluetooth should be configured correctly from the factory. If the Bluetooth ID and Pin need are not correctly set, they can be configured using TRU. Connect in receiver managing mode ->...
- Page 6 GPS. Once the connection is established 3DMC will establish a network connection. At this point the NTRIP mount points need to be downloaded from the NTRIP server. Go to Topcon Icon -> Tools -> Configure Radios. Select the NTRIP Tab and press the spanner besides the Mount-point dropdown Box to download mount points.
-
Page 7: Safety Warnings
Safety Warnings RF Radiation Hazard Warning To ensure compliance with FCC and Industry Canada RF exposure requirements, this device must be installed in a location where the antennas of the device will have a minimum distance of at least 20 cm from all persons. Using higher gain antennas and types of antennas not certified for use with this product is not allowed. - Page 8 2.1dBi. Antennas not included in this or having a gain greater than 2.1dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. MC-i3 FH915 2.1 dBi Dipole Antenna Manufacture/Type 890‐960 MHz LARSEN SPDA17RP918...
- Page 9 Topcon Positioning Systems, Inc. 7400 National Drive, Livermore, CA 94550 800∙443.4567 www.topconpositioning.com ISO 9001:2000 FM 68448 MC-i3 DUHF2-FH915 Installation and Setup Guide P/N: xxxxxxx-xx ©2012 Topcon Positioning Systems, Inc. All rights reserved. No unauthorized duplication.
