- Page 1 StructureScan 3D User Guide ENGLISH...
-
Page 2: Table Of Contents
Viewing image history 11 The 2D image 2D view options 13 The 3D Image The 3D mode options Fish rendering The 3D view options 16 Setting up the image Range Advanced menu options Contrast Palettes View Contents | StructureScan 3D User Guide... -
Page 3: About Structurescan 3D
StructureScan 3D is a multi-beam sonar technology that allows anglers to see underwater structure and bottom contours in customizable, three-dimensional views. The StructureScan 3D module supports both 2D and 3D views: • 2D Sidescan views and 3D view provide a 182 m (600 ft) wide... - Page 4 NSO evo2 are identical, but HDS Gen3 might differ slightly from the images used in this document. Where there are considerable differences between the displays both HDS Gen3 and NSS evo2 examples are included. About StructureScan 3D | StructureScan 3D User Guide...
-
Page 5: Basic Operation
StructureScan HD menu is replaced by the StructureScan 3D menu. StructureScan HD menu StructureScan 3D menu This document covers use of the StructureScan 3D features. Refer to your display's Operator manual for information about how to use StructureScan HD. Zooming You zoom a StructureScan image by: •... -
Page 6: Stopping/Pausing Sonar Transmitting
Refer to "Viewing image history" on page 10. Note: Ú For DownScan and for 3D images you can select to turn off the History bar. Refer to "Advanced menu options" on page 16. Basic operation | StructureScan 3D User Guide... -
Page 7: Goto Cursor
Position the cursor on the second measuring point - A line is drawn between the measuring points, and the distance is listed in the Cursor Information window Continue selecting new measuring points if required Basic operation | StructureScan 3D User Guide... -
Page 8: Viewing Image History
You pan the image history by dragging on the image, or by dragging the highlighted region of the history bar. To resume normal StructureScan scrolling, select the Clear cursor menu option or press the X key. Basic operation | StructureScan 3D User Guide... -
Page 9: The 2D Image
The 2D image examples are from the NSS evo2. On HDS Gen3 images the range scale is located at the bottom of the image, and temperature and depth overlay can be placed in a user specified location. The 2D image | StructureScan 3D User Guide... -
Page 10: 2D View Options
The DownScan image can be added as an overlay to the traditional Sonar image. The SideScan image can be added as an overlay on a chart. The 2D image | StructureScan 3D User Guide... -
Page 11: The 3D Image
Depth indication line 3D panel buttons Zoom panel buttons Note: Ú If a page includes more than one StructureScan panel, only one of them can have the 3D view at one time. The 3D Image | StructureScan 3D User Guide... -
Page 12: The 3D Mode Options
On HDS Gen3 temperature and depth overlay can be placed in a user specified location. The 3D mode options There are two modes for the StructureScan 3D panel: • Vessel Mode • Cursor Mode You switch between vessel mode and cursor mode by selecting the 3D panel buttons. -
Page 13: The 3D View Options
The Auto option automatically adjusts the settings to the optimal levels. Auto sensitivity can be adjusted (+/-) to your preference while still maintaining the auto sensitivity functionality. The 3D Image | StructureScan 3D User Guide... -
Page 14: Setting Up The Image
Flipping the image left/right If required, the left/right SideScanning images can be flipped to match the corresponding side of your vessel if the transducer has been mounted backwards. Refer to the transducer installation guides. Setting up the image | StructureScan 3D User Guide... -
Page 15: Contrast
Auto contrast This option sets the contrast value automatically based on the current conditions. Auto contrast can be adjusted (+/-) to your preference while still maintaining the auto contrast functionality. Setting up the image | StructureScan 3D User Guide... -
Page 16: Palettes
"The 2D image" on page 11 and in the "The 3D Image" on page 13. Shop the largest selection of reliable marine electronics & navigation in our online store. Setting up the image | StructureScan 3D User Guide...
