- Page 1 HDS Gen2 Touch Operator manual ENGLISH lowrance.com...
- Page 2 Government which is solely responsible for its operation, accuracy and maintenance. The GPS is subject to changes which could affect the Lowrance® and Navico® are registered accuracy and performance of all GPS equipment trademarks of Navico. anywhere in the world, including this instrument.
- Page 3 Please contact your Lowrance dealer if you require any further assistance. It is the owner’s sole responsibility to install and use the instrument and transducers in a manner that will not cause accidents, personal injury or property damage.
-
Page 4: About This Manual
The software This manual is written for Lowrance HDS Gen2 Touch Release to Market 2 (RTM2). Please check web site for details on release version. Touchscreen calibration... -
Page 5: Table Of Contents
Contents Introduction HDS Gen2 Touchscreen and keys The HDS Gen2 Touch home screen Basic operation The power key First time startup Using the touchscreen Menus Dialog boxes Positioning a Man Overboard waypoint Screen capture Pages Page overview Selecting pages, quick splits... - Page 6 Logging Structure data Using StructureMaps with mapping cards Scanning Fishing areas The Instruments panels The dashboards Customizing the Instrument panel Using Video (9” and 12” units only) The video page Setting up the video page Contents | Lowrance HDS Gen2 Touch...
- Page 7 Measuring range and bearing to a target EBL/VRM Setting a guard zone around your vessel Radar orientation MARPA Radar overlay Using AIS Target symbols Viewing information about AIS targets Vessel alarms The vessel settings panel Contents | Lowrance HDS Gen2 Touch...
- Page 8 112 SIRIUS™ weather Weather symbology Weather alarms Weather reports Animating SIRIUS™ weather graphics 118 Audio Enabling audio Audio controls Using the AM/FM radio Using SIRIUS radio 123 Maintenance Backing up your system data 127 Index Contents | Lowrance HDS Gen2 Touch...
-
Page 9: Introduction
Man Overboard (MOB) waypoint at the vessel’s position. Power key A long press turns the unit ON/OFF. A short press brings up the backlight and power dialog. Repeated short presses toggles between preset brightness levels. Introduction | Lowrance HDS Gen2 Touch... -
Page 10: The Hds Gen2 Touch Home Screen
The HDS Gen2 Touch home screen ¼ Note: video is only available on HDS Gen2 Touch 9” and 12” units. The radar option will only be shown when the unit is connected to a radar. Utilities panel Tap an icon to access utility data. -
Page 11: Basic Operation
Maybe later. Tap Close to manually configure settings. Using the touchscreen Basic touchscreen operation on the different pages is shown in the table. The Pages section later in this manual has more information about page-specific touchscreen operation. Basic Operation | Lowrance HDS Gen2 Touch... -
Page 12: Menus
Page menus can be hidden to allow pages to be displayed full screen. Drag the menu to the right to hide the menu. ¼ Note: When the cursor is active, some features on page menus will be replaced with cursor mode features. 10 | Basic Operation | Lowrance HDS Gen2 Touch... - Page 13 Hidden system menu The page menu for each operation mode has a hidden system menu. To access the hidden system menu, place your finger on the top menu item and drag down. | 11 Basic Operation | Lowrance HDS Gen2 Touch...
-
Page 14: Dialog Boxes
A dialog is closed by tapping the Close button. Numeric and alphanumeric keyboards will automatically be displayed when required for entering user information in dialogs. A virtual keyboard is operated by tapping the virtual keys. 12 | Basic Operation | Lowrance HDS Gen2 Touch... -
Page 15: Positioning A Man Overboard Waypoint
MOB waypoint is positioned at the vessel’s position • the display switches to a zoomed chart page, centered on the vessel position • the unit displays navigation information back to the MOB waypoint | 13 Basic Operation | Lowrance HDS Gen2 Touch... -
Page 16: Screen Capture
By default, screen captures are saved to internal memory. Refer to the Utilities section of this manual for information on viewing screen captures and saving files to a SD card. 14 | Basic Operation | Lowrance HDS Gen2 Touch... -
Page 17: Pages
Selecting pages, quick splits Tap a page icon to view the page full screen. Press and hold a page icon to view quick split combo page options. | 15 Pages | Lowrance HDS Gen2 Touch... -
Page 18: Selecting Active Panel
Select a panel configuration Save the page layout by tapping Save. Tap Clear to cancel changes and select a new panel ¼ Note: configuration. Tap Discard to cancel changes and return to the homescreen. 16 | Pages | Lowrance HDS Gen2 Touch... - Page 19 ¼ Note: You can cycle through favorite pages by pressing the key. editing favorites Tap Customize on the Favorites panel Tap an existing favorite Drag a page icon from the preview Tap Save | 17 Pages | Lowrance HDS Gen2 Touch...
-
Page 20: Data Overlay
Tap Save Customizing overlay data You can toggle the overlay data type between an analog and digital display, select data size, and change previously configured data from the Edit overlay configuration menu. 18 | Pages | Lowrance HDS Gen2 Touch... -
Page 21: Chart
Without a heading sensor installed, the icon will position itself using COG (Course over Ground). If no GPS is available the vessel symbol will include a question mark. | 19 Chart | Lowrance HDS Gen2 Touch... -
Page 22: Chart Scale
You Zoom in to see less of the map with more detail; zoom out to see more of the map with less detail. You can also use the dedicated +/- keys to zoom. 20 | Chart | Lowrance HDS Gen2 Touch... -
Page 23: Chart Menu
Save the route by tapping Save on the menu measuring distance The cursor can be used to measure the distance between your vessel and a selected position, or between two points on the chart. | 21 Chart | Lowrance HDS Gen2 Touch... -
Page 24: Chart Options
The chart orientation symbol in the upper right corner of the page indicates the north direction. North up Displays the chart with the north direction upward. Corresponds to the usual orientation of nautical charts. North up Heading up Course up 22 | Chart | Lowrance HDS Gen2 Touch... - Page 25 The camera angle is by default as seen from your eye position, look- ing toward the vessel. The vessel’s rotation on the chart is defined by the chart orientation settings. Chart tilted in rotate mode | 23 Chart | Lowrance HDS Gen2 Touch...
- Page 26 When you remove your finger from the chart the view will remain in the selected position. imagery Lowrance mapping can be displayed in two different imagery styles, either as 2D basic mapping style, or with shaded relief presenting chart including terrain imaging.
- Page 27 Tap the onscreen basic information display or tap the info button to view all available information for the item. ¼ Note: Popup information has to be enabled to see basic item information. | 25 Chart | Lowrance HDS Gen2 Touch...
-
Page 28: Chart Overlay
Selecting chart data This unit can use built-in Lowrance map data as well as Navionics, Fishing Hotspots, Jeppesen and other third-party mapping cards. Tap Change to Navionics or Change to Lowrance to switch chart data the unit is using. ¼ Note: The system will not automatically switch to embedded cartography if the SD card is removed. -
Page 29: Chart Settings
If there is no heading Heading sensor, heading will default to the COG value. For other vessels COG data is included in the message received from the AIS system. | 27 Chart | Lowrance HDS Gen2 Touch... -
Page 30: Navionics Chart Options
2D and a 3D chart are shown side by side. You can turn on/off Synchronize 2D/3D from the chart settings menu when Navionics is the selected chart data. 28 | Chart | Lowrance HDS Gen2 Touch... - Page 31 Navionics mapping cards. You can view photo overlays in either 2D or 3D modes. No Photo overlay Photo overlay, land only Full Photo overlay | 29 Chart | Lowrance HDS Gen2 Touch...
- Page 32 Displays pink dots for Shallow areas up to a 30-foot range. Navionics Fish’n Chip This unit supports Navionics Fish’n Chip (US only) chart feature. For more information, see www.navionics.com. Change to Lowrance Switches map display from Navionics to Lowrance mapping data. 30 | Chart | Lowrance HDS Gen2 Touch...
-
Page 33: Navionics Settings
The safety depth sets the limit for which depths that shall be drawn without blue shading. Contours depth Determines which contours you see on the chart down to the selected safety depth value. Rock filtering Filters rocks below a certain depth | 31 Chart | Lowrance HDS Gen2 Touch... -
Page 34: Waypoints, Routes & Trails
A waypoint is used to mark a position you later may want to return to. Two or more waypoints can also be combined to create a route. 32 | Waypoints, Routes & Trails | Lowrance HDS Gen2 Touch... - Page 35 Using the edit waypoint dialog This dialog is activated by tapping the waypoint and then tapping the waypoint name display on the screen. The dialog can also be activated from the Waypoint list. | 33 Waypoints, Routes & Trails | Lowrance HDS Gen2 Touch...
-
Page 36: Routes
Tap the chart screen to activate the cursor Tap new on the page menu Tap new route Tap the screen to position routepoints Tap Save on the menu 34 | Waypoints, Routes & Trails | Lowrance HDS Gen2 Touch... -
Page 37: Edit A Route
If you tap on a leg a new point will be added between existing routepoints To move existing routepoints, drag them to the desired location Tap Save on the menu | 35 Waypoints, Routes & Trails | Lowrance HDS Gen2 Touch... -
Page 38: Trails
¼ Note: The Trails option must also be turned ON in the chart settings to be visible. 36 | Waypoints, Routes & Trails | Lowrance HDS Gen2 Touch... -
Page 39: Navigating
When navigating a route, the active route leg will be colored red. The red arrow on the route leg shows the selected navigation method (forward or reverse) you are using to navigate the route. Upcoming route legs are colored orange. | 37 Navigating | Lowrance HDS Gen2 Touch... -
Page 40: Navigation Settings Panel
You can start navigating the route from the first or last routepoint (forward or reverse), or from a selected routepoint. Cancel navigation You cancel navigation from the Navigation menu. Navigation settings panel 38 | Navigating | Lowrance HDS Gen2 Touch... -
Page 41: Arrival Radius
Defines Loran chains (GRI) and preferred station for waypoint entry and cursor position. The graphic example shows cursor position window with Loran position information. For more information refer to your Loran system documentation. | 39 Navigating | Lowrance HDS Gen2 Touch... -
Page 42: Steer Page
If the XTE exceeds the defined off course limit this will be indicated with a red arrow including the distance from the track line. If the off course alarm is enabled, the alarm will activate if the XTE exceeds the defined off course limit. 40 | Navigating | Lowrance HDS Gen2 Touch... -
Page 43: Sonar
The cursor is by default not shown on the sonar screen. When you tap the screen the cursor will appear and the depth at the cursor position will be shown, the information window and history bar will be activated. | 41 Sonar | Lowrance HDS Gen2 Touch... -
Page 44: Zooming
If the cursor is active, the unit will zoom in where the cursor is pointed. Zoom bars Zooming in with the dedicated zoom keys will launch the Zoom bar. Drag the Zoom bar vertically to view different parts of the water column. 42 | Sonar | Lowrance HDS Gen2 Touch... -
Page 45: Viewing Sonar History
You can have all available sonar history shown at the top of the sonar screen. The Preview bar is a snapshot of available sonar history. You can scroll through sonar history by dragging the preview slider horizontally. Preview is turned on by default. | 43 Sonar | Lowrance HDS Gen2 Touch... -
Page 46: Sonar Menu
¼ Note: Digital depth can be lost when using a custom depth range. Frequency This unit supports 50kHz, 83kHz and 200kHz transducer frequencies, depending on the transducer installed. 44 | Sonar | Lowrance HDS Gen2 Touch... -
Page 47: Log Sonar Data
You can record sonar data and save the file on to a SD card inserted into the unit’s card reader. Log Sonar can be accessed from the Advanced sonar menu and the Sonar settings menu. | 45 Sonar | Lowrance HDS Gen2 Touch... - Page 48 You exit the replay mode by tapping the Close button. The function is activated from Sonar settings menu covered later in this section. 46 | Sonar | Lowrance HDS Gen2 Touch...
-
Page 49: View
Tap View on the Sonar menu and then tap Split to view split screen options. Zoom The Zoom mode shows a magnified view of the sonar image on the left side of the page. | 47 Sonar | Lowrance HDS Gen2 Touch... - Page 50 The scaling factor for the image on the left side of the panel is ad- justed as described for the Zoom option. Flasher The Flasher mode shows a flasher-style sonar in the left panel with a normal sonar view in the right panel. 48 | Sonar | Lowrance HDS Gen2 Touch...
-
Page 51: Measuring Distance
It is easier to use the measure function when the sonar is paused. ¼ Note: The Measure option will only be visible on the Sonar menu when the cursor is active. | 49 Sonar | Lowrance HDS Gen2 Touch... -
Page 52: Sonar Settings
You can share the sonar images from this unit with other units connected to the network. For more information about how to set up a sonar network, refer to the separate HDS Gen2 Touch Installation manual. Sonar source If you have more than one sonar on your Ethernet network, you can select which unit will be the sonar source for other units on the network. -
Page 53: Fishing Modes
≤ 400 ft White background Ice Fishing ≤ 400 ft Ice fishing Reset fishing mode Resets selected fishing mode to default settings, allowing you to clear settings adjustments made while using a fishing mode. | 51 Sonar | Lowrance HDS Gen2 Touch... -
Page 54: Installation Settings
B) For Depth Below Transducer: no offset required. C) For Depth Below Surface (waterline): Set the distance from trans- ducer to the surface: Enter a positive value., e.g. +0.5 -2.0 +0.0 20.5 ft 18 ft 20 ft 52 | Sonar | Lowrance HDS Gen2 Touch... -
Page 55: Water Speed Calibration
Transducer type is used for selecting the transducer model that came with your unit. In some transducers with built-in temperature sensors, the temperature reading may be inaccurate if the wrong transducer is selected from the transducer type menu. | 53 Sonar | Lowrance HDS Gen2 Touch... -
Page 56: Structurescan Hd
StructureScan transducer is connected. SideScan Access hidden Transducer context menu transmit burst Water column Water column between boat between boat and the bottom and the bottom Frequency Range keys Range scale Range scale 54 | StructureScan | Lowrance HDS Gen2 Touch... -
Page 57: Downscan
Press and hold the screen to activate cursor assist mode. To remove the cursor and cursor elements from the panel, press Clear cursor on the StructureScan menu. | 55 StructureScan | Lowrance HDS Gen2 Touch... -
Page 58: Zooming
The Preview bar is a snapshot of available sonar history. You can scroll through sonar history by dragging the preview slider horizontally. Preview settings are accessed from the Advanced menu. 56 | StructureScan | Lowrance HDS Gen2 Touch... - Page 59 Noise rejection Signal interference from bilge pumps, engine vibration and air bubbles can clutter the StructureScan image The noise rejection op- tion filters the signal interference and reduces on-screen clutter. | 57 StructureScan | Lowrance HDS Gen2 Touch...
-
Page 60: Log Sonar
The DownScan image can also be added as an overlay to the traditional sonar image. For more information, refer to “Overlay Downscan™” on page 51 . 58 | StructureScan | Lowrance HDS Gen2 Touch... -
Page 61: Stop Sonar
Structure settings StructureScan and sonar use the same settings menu. For more information refer to “Sonar settings” on page 50 . | 59 StructureScan | Lowrance HDS Gen2 Touch... -
Page 62: Structuremap
StructureMap can be used in Live mode or Saved mode. Live mode allows you to view real-time StructureMap data on the screen. Saved mode is used to display StructureMap data previously saved to a SD card. 60 | StructureMap | Lowrance HDS Gen2 Touch... -
Page 63: Live Mode
It can be used when revisiting an area that has already been scanned in order to assist the user in positioning the vessel or locating specific points of interest. | 61 StructureMap | Lowrance HDS Gen2 Touch... -
Page 64: Structure Options
Transparency Increases/decreases the visibility of Structure overlay so underlying chart detail may be revealed/obscured. This is helpful when using marine mapping cards. Minimum transparency Maximum transparency 62 | StructureMap | Lowrance HDS Gen2 Touch... -
Page 65: Logging Structure Data
(.sl2) file to StructureMap format (.smf ). This can be done automatically from the Sonar Log menu, or manually by converting logs from the Files menu. Due to the large size of StructureMap | 63 StructureMap | Lowrance HDS Gen2 Touch... -
Page 66: Using Structuremaps With Mapping Cards
Using StructureMaps with mapping cards StructureMap allows you to maintain full chart capability and can be used with embedded cartography as well as Navionics, Insight and other third-party charting cards compatible with HDS units. 64 | StructureMap | Lowrance HDS Gen2 Touch... -
Page 67: Scanning Fishing Areas
Steer the boat so the structure will be on the left or right side of your boat. • Set your structure range to a significantly greater level (two-to- three times) than the water depth to ensure a complete scan and to maximize conversion accuracy. | 65 StructureMap | Lowrance HDS Gen2 Touch... -
Page 68: The Instruments Panels
You can also set limits of analog gauges. All edit options are available from the Instrument panel menu. Available editing options will depend on the data sources that are connected to your system. 66 | Instruments | Lowrance HDS Gen2 Touch... - Page 69 Tap Edit on the Instrument page menu Tap the gauge you want to change. The selected gauge will be shaded in blue Tap Select info Tap a data category Tap a data type Tap Save on the menu | 67 Instruments | Lowrance HDS Gen2 Touch...
-
Page 70: Using Video (9" And 12" Units Only)
Video input can be set to display a mirrored image. This setting can be helpful for rear-facing cameras used to back-down the vessel. The video standard This unit supports NTSC and PAL video. Check the local video standard or the standard of your cameras. 68 | Video | Lowrance HDS Gen2 Touch... -
Page 71: The Alarm System
Sets thresholds for alarms that when exceeded will trigger the alarm. Thresholds are not used on all alarms. If an alarm supports thresholds, the Set Limit button will be active when the alarm is selected. | 69 Alarms | Lowrance HDS Gen2 Touch... - Page 72 3 alarms. The alarms are listed in the order they occur with the alarm activated first at the top. The remaining alarms are available in the Alarms dialog. 70 | Alarms | Lowrance HDS Gen2 Touch...
-
Page 73: Acknowledging An Alarm
Alarms dialog. There is no time-out on the alarm message or siren. These remain until you acknowledge it or until the reason for the alarm is removed. | 71 Alarms | Lowrance HDS Gen2 Touch... -
Page 74: Utilities
Vessels Status listing List of all AIS, MARPA, and DSC vessels with available information. Message listing List of all messages received from other AIS vessels with time stamp. 72 | Utilities | Lowrance HDS Gen2 Touch... -
Page 75: Sun/Moon
List of all available alarm options in the system, with current settings. Waypoints/routes/trails List of waypoints, routes and tracks with details. Tap on the waypoint, route or track you wish to edit or delete. | 73 Utilities | Lowrance HDS Gen2 Touch... -
Page 76: Tides
Viewing screenshots When viewing a screenshot full screen, you can drag your finger across the screen to view other screenshots. Press Zoom In to return to the file list. 74 | Utilities | Lowrance HDS Gen2 Touch... -
Page 77: Copying Files To Sd Card
You can copy screenshots and logs to a SD card. You can also export system settings and waypoints, routes and trails to a SD card. Ex- porting files is covered in the Maintenance section. Copying all files | 75 Utilities | Lowrance HDS Gen2 Touch... -
Page 78: Settings
Use the PDF viewer to read manuals and other PDF files on the HDS display. The manuals can be read from an inserted SD card or from the unit’s internal memory. Settings Opens the system settings menu. 76 | Utilities | Lowrance HDS Gen2 Touch... -
Page 79: System Settings
Most paper charts are made in the WGS84 format, which also is used by your unit. If your paper charts are in a different format, you can change the datum settings accordingly to match your paper charts. | 77 System Settings | Lowrance HDS Gen2 Touch... -
Page 80: Units
Advanced Shows a dialog with more advanced settings. About Displays unit software information. Units Controls unit of measure used for various data types. Units are accessed from the Settings panel. 78 | System Settings | Lowrance HDS Gen2 Touch... -
Page 81: Using The Simulator
A set of source files is included in your system, and you can import files by using an SD card inserted into the unit’s card reader. You can also use your own recorded sonar files in the simulator. | 79 Simulator | Lowrance HDS Gen2 Touch... -
Page 82: Advanced Simulator Settings
Used to enter values when GPS source is set to Simulated course or Simulated route. Otherwise, GPS data including speed and course comes from the selected echosounder or radar files. Set start position Moves the simulated vessel position to the cursor position. 80 | Simulator | Lowrance HDS Gen2 Touch... -
Page 83: Using The Radar (Optional)
The power to the radar scanner is on, but the radar is not transmitting. Transmit The scanner is on and transmitting. Detected targets will be drawn on the radar PPI (Plan Position Indicator). | 81 Radar | Lowrance HDS Gen2 Touch... -
Page 84: Adjusting Range
Press the dedicated waypoint key to save a waypoint at the vessel position. ¼ Note: A heading sensor must be connected to the system to save a waypoint on the radar PPI. 82 | Radar | Lowrance HDS Gen2 Touch... -
Page 85: Measuring Range And Bearing To A Target
Sea clutter has a manual mode and two automatic modes (harbor, offshore). Select manual mode to make adjustments to Sea clutter. Automatic modes use a combination of Gain/Sea Clutter settings best suited for the selected mode (Harbor, Offshore). | 83 Radar | Lowrance HDS Gen2 Touch... - Page 86 Moves the radar PPI center to the bottom of the panel to give maxi- mum view ahead. Offset Allows you to move the PPI center to any location on the radar page. 84 | Radar | Lowrance HDS Gen2 Touch...
-
Page 87: Ebl/Vrm
You can position EBL/VRM by using the cursor, and edit the marker position as described below. When positioned, you can quickly turn the EBL/VRM on/off by tapping the desired EBL/VRM on the menu. | 85 Radar | Lowrance HDS Gen2 Touch... -
Page 88: Setting A Guard Zone Around Your Vessel
A guard zone is an area (either circular or a sector) that you can define on the radar image. When activated, an alarm will alert you when a radar target enters or exits the zone. 86 | Radar | Lowrance HDS Gen2 Touch... -
Page 89: Radar Settings Menu
You can select if the alarm will be activated when the target enters or exits the zone. Radar Settings menu Target expansion Increases signal processing to provide larger target returns for better visibility on the screen. | 87 Radar | Lowrance HDS Gen2 Touch... -
Page 90: Radar Orientation
This option works only when the unit is navigating an active route. If you are not navigating an active route the heading up orientation will be used until the navigation function is started. 88 | Radar | Lowrance HDS Gen2 Touch... -
Page 91: Marpa
MARPA tracking is an important tool for collision avoidance. ¼ Note: You must have a heading sensor connected to your system to use MARPA. | 89 Radar | Lowrance HDS Gen2 Touch... -
Page 92: Cancelling Target Tracking
When targets are being tracked, the radar menu will expand to include options for cancelling individual targets or to stop the track- ing function. Cancel tracking individual targets by tapping the target and then tapping Cancel target on the menu. 90 | Radar | Lowrance HDS Gen2 Touch... - Page 93 Defining dangerous vessels You can define dangerous vessels based upon CPA (Closest Point of Approach) or TCPA (Time to Closest Point of Approach). When | 91 Radar | Lowrance HDS Gen2 Touch...
-
Page 94: Radar Overlay
When the radar overlay is selected, basic radar operational functions are available from the Chart page menu. ¼ Note: You must have a heading sensor connected to your system to use Radar overlay. 92 | Radar | Lowrance HDS Gen2 Touch... -
Page 95: Radar Installation Menu
Sidelobe suppression (Broadband radar only) ¼ Note: This control should only be adjusted by experienced radar users. Target loss in harbour environments may occur if this control is not adjusted correctly. | 93 Radar | Lowrance HDS Gen2 Touch... - Page 96 Traverse the area again and readjust if sidelobes returns still occur. Exit the installation menu. Restore radar to Factory Default This can be used to revert all user adjustments to factory settings. 94 | Radar | Lowrance HDS Gen2 Touch...
-
Page 97: Using Ais
Sleeping AIS target (not moving or at anchor). Moving and safe AIS target with course extension line. Dangerous AIS target, A target is defined as dangerous based on illustrated with bold line. the CPA and TCPA settings. | 95 AIS | Lowrance HDS Gen2 Touch... -
Page 98: Viewing Information About Ais Targets
Viewing information about all AIS targets Chart pages You can view informa- tion about all AIS targets within range of your ves- sel from the menu. 96 | AIS | Lowrance HDS Gen2 Touch... -
Page 99: Vessel Alarms
Controls whether an alarm shall be activated when a message is received from an AIS target The vessel settings panel Vessel settings are accessed from the Utilities tab on the home- screen. | 97 AIS | Lowrance HDS Gen2 Touch... - Page 100 You can define an invisible guard zone around your vessel. When a target comes within this distance from your vessel, the symbol will change to the “dangerous” target symbol and an alarm will be triggered. 98 | AIS | Lowrance HDS Gen2 Touch...
-
Page 101: Networking
Allows you to select the network device that will supply source data for a selected data type. Tap Data sources to edit source names, change source scope and add/remove data source network instances. | 99 Networking | Lowrance HDS Gen2 Touch... - Page 102 Global scope to use the same data sources. Setting one display unit on the network to Local scope allows you to select data sources independent of other global scope units on the network. 100 | Networking | Lowrance HDS Gen2 Touch...
-
Page 103: Damping
Tap Rename and the touchscreen keyboard will appear. Damping Smooths out fluctuations in data on the display (course over ground, speed over ground, etc.) that occur when navigating at slower speeds. | 101 Networking | Lowrance HDS Gen2 Touch... -
Page 104: Device List
Used to view NMEA 2000 network information and the status of information shared between units. From the UDB tab, you can see IP addresses of attached Ethernet devices and if an Ethernet cable is connected or unplugged. 102 | Networking | Lowrance HDS Gen2 Touch... -
Page 105: Nmea 2000
Used to select the NMEA 0183 output sentences your unit will use when communicating with other NMEA 0183 devices. The default setting will work well with most configurations. Ethernet Displays the unit’s IP address on the Ethernet network. | 103 Networking | Lowrance HDS Gen2 Touch... -
Page 106: Gofree Wireless
GoFree wireless With a WIFI-1 unit connected to an HDS unit you can use a wireless device to view or remotely control the HDS display. Displaying HDS data on a wireless device requires a corresponding app. Please check the appropriate Apple or Android store for your device. ¼... - Page 107 Downloading the GoFree app Download the Lowrance GoFree Controller & Viewer app to your wireless device from the Apple App Store or Android Google Play app store. Connecting the wireless device to the WIFI-1 Set up the wireless device’s network to be the WIFI-1 defined as primary access point.
-
Page 108: Operating The Hds With A Wireless Device
When control is confirmed, the connection will be immediately established. ¼ Note: If control is rejected the wireless device will mirror the HDS screen, but no operation will be allowed from the remote device. All connected wireless devices will be listed in the HDS dialog, and you can change the access level for all connected devices. -
Page 109: Point 1 Antenna
On slower vessels, and large networks with a lot of network traffic, it may be preferable to reduce the network load. | 107 Point 1 antenna | Lowrance HDS Gen2 Touch... -
Page 110: Disabling The Heading Sensor
¼ NOTE: When the Point-1 detects another heading source in the network, it will automatically disable its own heading output in preference of the other source. 108 | Point 1 antenna | Lowrance HDS Gen2 Touch... -
Page 111: Gnss Configuration
GLONASS enabled. Calibrate With the Point 1 mounted securely in its permanent location, follow the on-screen instructions to calibrate the compass. | 109 Point 1 antenna | Lowrance HDS Gen2 Touch... -
Page 112: Fuel
The fuel utility allows your unit to calculate and monitor the overall fuel performance of your vessel. The Fuel utility requires a fuel used sensor, like a Lowrance Fuel Flow sensor, an engine interface with fuel used output capability, or a Lowrance Storage Device. -
Page 113: Fuel Used
Allows you to search for fueling stations near your location. Find fuel search results can be sorted by distance, cost and fuel type. ¼ Note: You must have a LWX module and a SIRIUS data subscription to use the Find Fuel feature. | 111 Fuel | Lowrance HDS Gen2 Touch... -
Page 114: Sirius™ Weather
The SIRIUS™ weather can be displayed as an overlay on your chart panel. When weather overlay is selected, the chart menu will increase to show the available weather options. ¼ Note: Weather options will not be shown when the cursor is active. 112 | Weather | Lowrance HDS Gen2 Touch... -
Page 115: Weather Symbology
Shades of color are used to show precipitation type and intensity. Darkest color indicates highest intensity. Precipitation type Color codes Rain From light green (light rain) - yellow - orange - to dark red (heavy rain) Snow Blue Mixed Pink | 113 Weather | Lowrance HDS Gen2 Touch... -
Page 116: Wave Indication
Waves lower than the minimum value will not be color coded. Weather icons Several weather icons are available to show current or predicted weather conditions. You can tap an icon to display detailed weather information. 114 | Weather | Lowrance HDS Gen2 Touch... -
Page 117: Weather Alarms
You can setup the lightning or storm alarms to be within a certain range of your vessel. You can also get an alarm if a severe weather forecast alarm is issued for your chosen marine zone. | 115 Weather | Lowrance HDS Gen2 Touch... -
Page 118: Weather Reports
You can read tropical statements including information about tropi- cal weather conditions. These statements are available for the entire Atlantic and the Eastern Pacific. You can access tropical statements from the Weather options menu. 116 | Weather | Lowrance HDS Gen2 Touch... -
Page 119: Animating Sirius™ Weather Graphics
(the predictions) When activated the time for the current graphic animation will be displayed in the lower left corner of the chart panel. | 117 Weather | Lowrance HDS Gen2 Touch... -
Page 120: Audio
The menus differ from one audio source to another as shown in the following sections. Media bar Repeat Volume Audio Source Artist Track level Shuffle Media bar Station RDS Display Audio Signal Volume Source strength level 118 | Audio | Lowrance HDS Gen2 Touch... -
Page 121: Audio Controls
Tune forward Mute audio Tune backward AM/FM iPod & USB SIRIUS ¼ Note: For iPod, iPhone or USB, tap and hold Skip + or Skip- to fast forward or rewind the current track. | 119 Audio | Lowrance HDS Gen2 Touch... -
Page 122: Using The Am/Fm Radio
Using the AM/FM radio Selecting AM/FM tuner region Before playing FM or AM radio, you must select the appropriate AM and FM tuner regions for your location. 120 | Audio | Lowrance HDS Gen2 Touch... -
Page 123: Using Sirius Radio
You can create of list of your favorite SIRIUS channels from within the channels list. You will not be able to add unsubscribed channels. When a favorite list is available, you scroll through the list by dragging the screen vertically. | 121 Audio | Lowrance HDS Gen2 Touch... - Page 124 The same code must be entered before a locked channel can be released. Mixer You can make adjustments to audio settings by tapping Mixer on the audio options menu. 122 | Audio | Lowrance HDS Gen2 Touch...
-
Page 125: Maintenance
Touch crosshair shown on screen to perform nine points calibration After successful calibration the unit will return to normal application screen | 123 Maintenance | Lowrance HDS Gen2 Touch... -
Page 126: Backing Up Your System Data
The files are copied to a SD card inserted in the card slot on the front of your unit. Different output formats are available: Used to transfer data from one HDS Gen2 Touch User Data File version 5 system to another... - Page 127 ¼ Note: To export waypoints, routes and trails to a non-HDS unit, select a compatible file format and export the file to a SD or microSD card that works with the non-HDS unit. | 125 Maintenance | Lowrance HDS Gen2 Touch...
- Page 128 ¼ Note: To export waypoints, routes and trails to a non-HDS unit, select a compatible file format and export the file to a SD or microSD card that works with the non-HDS unit. 126 | Maintenance | Lowrance HDS Gen2 Touch...
-
Page 129: Index
Cancel navigation 14, 38 Chart Favorites panel 8 3D 23 Files 74 3D boat selection 27 Copying all files 75 Categories 25 Copying files to SD card 75 Creating routes 21 Viewing screenshots 74 | 127 Index | Lowrance HDS Gen2 Touch... - Page 130 Fish’n Chip 30 Log all channels 46 Look ahead 28 Viewing sonar data 46 Photo overlay 29 Loran 39 Photo transparency 30 Phantom loran 39 Presentation type 31 Settings 39 Rock filtering 31 128 | Index | Lowrance HDS Gen2 Touch...
- Page 131 PDF reader 76 Radar status 93 Point 1 antenna Rain clutter 84 COG/SOG Filter 108 Range 82 Configuration 107 Range offset 93 Configure/Offset 108 Range rings 83, 89 Disabling heading sensor 108 | 129 Index | Lowrance HDS Gen2 Touch...
- Page 132 Auto range 57 Networking 50 Contrast 58 Source 50 DownScan 55 Noise rejection 45 Flip left/right 58 Palettes 49 Frequency 57 Pausing sonar 50 History preview 56, 58 Ping speed 45 Log sonar 58 130 | Index | Lowrance HDS Gen2 Touch...
- Page 133 Settings 36 Symbology 113 Troubleshooting 124 Transparency 115 Wave indication 114 Weather reports 116 Units 78 Using the touchscreen 9 Utilities Alarms 73 Files Copying files 75 Find 73 PDF reader 76 | 131 Index | Lowrance HDS Gen2 Touch...
- Page 134 Navico Databases License Agreement THIS IS A LEGAL AGREEMENT BETWEEN THE END-USER WHO FIRST PURCHASES THIS PRODUCT AS A CONSUMER ITEM FOR PERSONAL, FAMILY, OR HOUSEHOLD USE ("YOU") AND NAVICO, THE MANUFACTURER OF THIS PRODUCT ("WE", "OUR", OR "US"). USING THE PRODUCT ACCOMPANIED BY THIS LICENSE AGREEMENT CONSTITUTES ACCEPTANCE OF THESE TERMS AND CONDITIONS.
-
Page 135: Databases Limited Warranty
Databases Limited Warranty “We”, “our”, or “us” refers to Navico, the manufacturer of this product. “You” or “your” refers to the first person who purchases the product as a consumer item for personal, family, or household use. The Databases Limited Warranty applies to the one or more databases that your product may contain. -
Page 138: Installation Guide
Broadband 3G™ Radar Broadband 4G™ Radar Installation Guide ENGLISH www.bandg.com www.simrad-yachting.com www.lowrance.com... - Page 140 Connect interconnection cable to the scanner Connect the interconnection cable to radar interface box Connect the Broadband radar to your display Lowrance: HDS USA (no MARPA) Lowrance: HDS outside USA or with MARPA / chart overlay Simrad: NSS B&G: Zeus Simrad: NSO, NSE and NSS...
- Page 141 Industry Canada RSS-Gen. • CE compliant with R&TTE directive. For further compliance information please refer to our websites: http://www.simrad-yachting.com/Products/Marine-Radars http://www.lowrance.com/Products/Marine http://www.bandg.com/Products Industry Canada IC: 4697A-3G4G Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 142 Copyright © 2011 Navico Holding AS. W arranty The warranty card is supplied as a separate document. In case of any queries, refer to the brand web site of your display or system. www.lowrance.com www.simrad-yachting.com www.BandG.com Welcome | Broadband 3G/4G™ Radar Installation Guide...
-
Page 143: Welcome
Welcome Congratulations on your purchase of the latest technology available in recreational marine radar. The special features designed into this radar are: • “Revolutionary improvement in situational awareness” - provides unprecedented ability to distinguish hazards and other objects • Radar is fi nally easy enough for casual users – identifi es targets clearly with out complicated tuning adjustments •... -
Page 144: Additional Benefi Ts Of Fmcw Radar Are
FMCW = Frequency Modulated Continuous Wave The scanner transmits a ‘rising tone’ (Tx wave) with linearly increasing frequency. The wave propagates out from the transmitter retaining the frequency it had when it was transmitted. If it refl ects off an object, it will return to the receiver, still at the frequency it had when originally transmitted. -
Page 145: Radar System Overview
The RI11 interface box is used to connect to earlier NX series displays using a serial connection. A Y-cable may be used to add heading input for MARPA via NMEA0183. The 3G kit may be ordered with either interface box, however the Lowrance USA model (000- 10418-001) is not shipped with an RI10 or RI11 interface. -
Page 146: Installation
Installation Note: Follow these instructions carefully. Don’t take any shortcuts! • The Broadband Radar is factory sealed. It is not necessary to remove the cover. • Removing the cover will void the factory warranty. Tools Required Drill Torque wrench Drill bit 9.5 mm (3/8”) Screw driver Choose the scanner location... -
Page 147: Considerations For Direct Roof Mounting
Compass Broadband Radar 12.5 12.5 0.7 m (2.3 ft) Min Pulse Radar STBY Minimum distance to install near the Do not install the Broadband Radar on the same ships compass is 0.7 m (3.3 ft). beam plane as a conventional pulse radar. A pulse radar must be set to STBY or OFF any time the Broadband Radar is being operated. - Page 148 Better performance Broadband Radar Above illustrates that raising the Broadband scanner off the hard top allowing most of the radar energy to clear the hard top. Best performance Broadband Radar 850 mm Hard Top Width For best performance, the radar should be positioned to allow the beams to clear the superstructure of the boat.
- Page 149 Mounting the scanner Use the supplied mounting template and tape it securely to the chosen location. Before drilling, check that: • you have oriented the mounting template correctly so that the front of the scanner unit will face the front of the vessel •...
-
Page 150: Connect Interconnection Cable To The Scanner
Connect interconnection cable to the scanner The scanner interconnection cable connects the scanner to the RI10 interface box (or Lowrance HDS via and ethernet adapter cable - 3G U.S only). The cable connects to the scanner using a 14 pin connector. -
Page 151: Connect The Interconnection Cable To Radar Interface Box
Connect the interconnection cable to radar interface box (USA only) To connect interconnection cable to Lowrance HDS (see “Lowrance: HDS USA (no MARPA)” on page 14) Data Shield Black Yellow 1. Slide (F), (E) and (D) past the RJ45 connector 2. - Page 152 Shortening the cable It is not recommended to shorten the cable, but if it is unavoidable, use the pin-out below to re-terminate the cable with a new RJ45 plug. RJ45 Connector pinout Color White/Orange Orange White/Green Blue White/Blue Green White/Brown Brown Required to complete RJ45 Connector...
-
Page 153: Connect The Broadband Radar To Your Display
Ethernet adapter cable. 5 pin yellow male to RJ45 female 1.8 ft (6ft). Included in 3G™ kit 000- 10418-001 (Lowrance USA only). Can connect directly to the HDS, or via a NEP-2 Ethernet switch, or using a free Ethernet port on a LSS-1 Structure Scan module (if applicable) ... -
Page 154: Lowrance Hds Outside Usa Or With Marpa / Chart Overlay
Lowrance HDS outside USA or with MARPA / chart overlay Simrad NSS (NMEA2000 network) The 3G and 4G radar connects to the Lowrance HDS and Simrad NSS in the same manner Lowrance HDS Simrad NSS FUSE FUSE FUSE NMEA2000 Network... -
Page 155: Simrad Nso, Nse And Nss
B&G Zeus Simrad NSO, NSE and NSS (SimNet network) Zeus B&G Zeus SIMRAD NSO, NSE or NSS MFD FUSE FUSE Parts required for FUSE Chart overlay / MARPA SimNet Network Alternative: NMEA0183 heading NMEA2000 cables SimNet cables White RX+ Brown RX- Ethernet cable Ethernet cables if AT10HD... -
Page 156: Ri10 Connections
SimNet connection was lost after power up Note: Lowrance HDS units sold in the USA do not require an interface box and the scanner connects directly to the display or Ethernet switch. If chart overlay or MARPA are required for... -
Page 157: Connect Power
12 -24 V DC (+) Yellow Black BATT (-) For systems not using radar interface box (Lowrance 3G USA only): • Connect the red wire to power positive 12 or 24 V DC. Use a 5 Amp fuse • Connect the yellow wire to power source that will turn on the system (see above) •... -
Page 158: Setup And Confi Guration
The following sections cover the available adjustments. Note that the menu examples used are from the Simrad NSE. While these diff er aesthetically from the Lowrance interface, the content is essentially the same. Entering radar setup on your display Enter radar installation by pressing MENU >... -
Page 159: Adjust Bearing Alignment
Adjust bearing alignment... Adjust the heading marker. This is to align with the heading marker on the screen with the center line of the vessel, this will compensate for any slight misalignment of the scanner during installation. Any inaccuracy will be evident when using MARPA or chart overlay. Point the boat to the end of a head land or peninsula. -
Page 160: To Start The Radar
To start the radar: From the radar screen select the Transmit button. RI10 heading source selection: The RI10 receives heading via SimNet or NMEA2000 network and transmits this data to the radar, where MARPA processing is performed. For Simrad installations with more than one SimNet heading source the RI10 will use the Simrad group source. -
Page 161: Dual Range Setup
6. The radar source selection is not global, so will only apply to the display on which the source was selected. The radar source will need to be setup for each display on the network. Once the radar sources have been set up they will be retained for every system power-up until changed by the user Dual Range setup (Broadband 4G Radar only):... -
Page 162: Maintenance
Maintenance Clean the radome using soapy water and a soft cloth. Avoid using abrasive cleaning products. Do not use solvents such as gasoline, acetone, M.E.K etc. as this will damage the dome surface. After years of use the drive belt may have to be replaced. The transmitter in the Broadband Radar is solid state and will not require regular replacement, unlike the magnetron found in conventional pulse radar. -
Page 163: Dimension Drawings
Dimension Drawings Scanner 489.6 mm (19.28”) 488.6 mm (19.24”) FRONT 233.0 mm (9.17”) 128.3 mm (5.05”) 128.3 mm (5.05”) Description Cable entry area Cable retention channel Bolt holes x 4 M8 x 30 mm Breather 24 | Dimension Drawings | Broadband 3G/4G™... -
Page 164: Radar Interface Box
Radar interface box 171 mm (6.76") 154 mm (6.06") | 25 Dimension Drawings | Broadband 3G/4G™ Radar Installation Guide... -
Page 165: Specifi Cations
NMEA0183 with RI11 interface box NMEA2000 / SimNet with RI10 interface box Inter connecting cable length Lowrance 10 m (33 ft) Simrad, B&G 20 m (65.6 ft) Maximum inter connecting cable length 30 m (98.5 ft) – available as option... -
Page 166: Broadband 4G™ Radar
High Speed Ethernet Heading NMEA2000 / SimNet with RI10 interface box Inter connecting cable length Lowrance 10 m (33 ft) Simrad, B&G 20 m (65.6 ft) Maximum inter connecting cable length 30 m (98.5 ft) – available as option Bolts (4) -
Page 167: Navico Broadband Radar Part Numbers
Broadband scanner interconnection cable 30 m (98.5 ft) Ethernet cables 000-00127-56 Adapter cable: yellow Ethernet male to RJ45 2 m (6.5 ft) female (Supplied with Lowrance USA SKU) 000-00127-28 Ethernet cable 0.6 m (2 ft) 000-0127-51 Ethernet cable 1.8 m (6 ft) -
Page 168: Rf Exposure Compliance Certifi Cate
RF exposure compliance certifi cate | 29 RF exposure compliance certifi cate | Broadband 3G/4G™ Radar Installation Guide... - Page 169 30 | RF exposure compliance certifi cate | Broadband 3G/4G™ Radar Installation Guide...
- Page 170 | 31 RF exposure compliance certifi cate | Broadband 3G/4G™ Radar Installation Guide...
- Page 173 www.lowrance.com...
