228-30179
DIFFERENTIAL REFRACTIVE DETECTOR
RID-1 OA
FOR SHIMADZU
HIGH-PERFORMANCE LIQUID CHROMATOGRAPH
USER'S MANUAL
Read the instruction manual thoroughly before you use the product. Keep
this instruction manual with care so that you can use it any time you need it.
CHROMATOGRAPHIC & SPECTROPHOTOMETRIC
INSTRUMENTS DIVISION
KYOTO, 3 A P A N
