Page 1: User Manual
ST240 User Manual Suntech International Ltd. - Page 2 ST240 User Manual ST240 Installation Guide 1. Decide the location of ST240 and GPS Antenna, and check the cable ways. Check whether the location of ST 240 is far away from other electric equipment. GPS Antenna must have a sky-view and must be far away from other antenna.
- Page 3 ST240 User Manual Tighten the six screws 3. Connect Event lines with relevant lines of vehicle. Event Cable Color pin Description Red: VCC (8 - 30V) Connect the red line to 12 VDC /24 VDC Constant power of vehicle Black: Ground...
- Page 4 4. Check GPS/GPRS operation and operation with LEDs. It takes 3~10 minutes for GPS connected. Green LED- indicates GPS status RED LED- indicates GPRS status Caution: Direction of ST240 is very important when installed in the vehicle. Make sure that top side of ST240...
- Page 5 ST240 User Manual 5. Trouble Shooting (LED Indicator) - Blue LED: Indicates GPRS status. GPRS Blink Count Remarks Normal Server Com. Error <Possible Cause> 1. Server or network parameter is wrong. 2. Server is closed. 3. Temporary network barrier GPRS Com. Error <Possible Cause>...
- Page 6 ST240 User Manual - RED LED: Indicates GPS status. Blink Count Remarks Normal No Fix <Possible Cause> 1. If power on, GPS chipset is trying to find position during some minutes. 2. GPS antenna lays on weak or no GPS signal position 3.
- Page 7 ST240 User Manual device, pursuant to Part 15 of the FCC Rules. These limits are frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
