QUICK START GUIDE
Cisco Model SPA 525G Quick Start Guide
Welcome
Thank you for choosing the Cisco Small Business IP phone. This guide describes how to install your phone and how to perform some
basic tasks.
1
Installing Your IP Phone
Use these procedures to install the phone and connect it to your network.
Do not insert a telephone line cord into the port marked "AUX".
Step 1. Turn the phone over to expose the ports on the back of
the unit.
Step 2. Insert one end of the phone cord the into slot marked with a
phone symbol (the Handset Port). Insert the other end into
the jack at the bottom of the handset (not shown).
Step 3. (Optional) Connect the desk stand by lining up the tabs on
the desk stand with the slots on the back of the phone. Slide
the bottom tabs into the slots and lightly press down on the
top of the desk stand. It should easily slide into the top slots.
Do not force.
Step 4. If you are using an external power source, plug one end of
the power cord into the building's power outlet and insert the
other end of the power cord into the phone base.
Step 5. Connect your phone to the network:
• Using a wired Ethernet Connection—Insert the Ethernet cable into the slot marked "SW" (the Switch Port). Insert the other end of the
Ethernet cable into the appropriate device on your network, such as a network switch. The Cisco SPA 525G provides a second Ethernet
port (the PC Port). You can connect a PC to this port to provide network access to the PC. (Note: This option is only available when the
phone is connected to the network via the wired Ethernet connection).
• Using a Wireless Connection—Your phone has a built-in wireless adapter. You must unplug the Ethernet connection before configuring
Wi-Fi. See the Cisco Small Business IP Phone SPA 525G (SIP) User Guide for more information.
1
