BNI PBS-504-001-K008
BNI PBS-504-002-K008
Profibus IO-Link Panelmaster
User´s Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BNI PBS-504-002-K008 and is the answer not in the manual?

Questions and answers

Summary of Contents for Balluff BNI PBS-504-002-K008

  • Page 1 BNI PBS-504-001-K008 BNI PBS-504-002-K008 Profibus IO-Link Panelmaster User´s Guide...
  • Page 2: Table Of Contents

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 1 Notes for the User About this guide Structure of the guide Typografical conventions 1.3.1 Enumerations 1.3.2 Actions 1.3.3 Syntax 1.3.4 Cross references Symbols Abbreviations 2 Safety Intended use Installation and startup General safety instructions...
  • Page 3: Notes For The User

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Notes for the user 1.1 About this guide This guide describes The BNI PBS-… serves as a decentralized input/output module for connecting to a Profibus network. The integrated IO-Link ports enable simple linking of IO- Link capable sensors, actuators and sensor / actuator hubs.
  • Page 4: Safety

    2.5 Hazardous voltage Note Disconnect all power before servicing equipment. Note In the interest of product improvement, the Balluff GmbH reserves the right to change the specifications of the product and the contents of this manual at any time without notice. www.balluff.com...
  • Page 5: Basis Knowledge

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Basis knowledge 3.1 Product Balluff Network Interface BNI PBS-...:  description Used for connecting sensors/actuators to a Profibus-DP network.  Sensors/actuators can be connected through 4 standard I/O ports. Connection options: A total of 8 ports are available which can be freely configured. If for example 4 IO-Link ports are configured, 4 standard I/O ports can be used.
  • Page 6: Communication Mode

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Basis knowledge 3.4 Communication Process data (cyclical): mode The GSD file provides different data modules for representing the sensor map: • Inputs: 1 byte – 32 bytes • Outputs: 1 byte – 32 bytes •...
  • Page 7: Getting Started

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Getting started 3.1 Connection overview Front side BNI PBS-504-00x.. Input / Output / IO-Link port 1 LED: Input / Output / IO-Link port Input / Output / IO-Link port 3 IO-Link logo Input / Output / IO-Link port 2...
  • Page 8: Mechanical Connection

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Getting started 3.2 Mechanical The module BNI PBS-504… is attached using 4 M5x10. connection The thread insert for mounting the module is 8mm. 1 Mounting holes with 8mm thread insert 2.Ground connection 3 Power supply interface, terminal plugs...
  • Page 9: Electrical Connection

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Getting started 3.3 Electrical connection 3.3.1 Power supply The power supply is connected to terminal plugs, spring type on the back side of the unit. 1 2 3 4 5 6 1 2 3 4 5 6...
  • Page 10: Profibus Interface

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Getting started 3.3.2 Profibus The bus connection is made using the SUBD 9-Pin female connector. interface The address is set on the address switch. Profibus (SUB-D 9 Pin female) Function Protection ground Not connected...
  • Page 11: Connecting Sensors / Actuators

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Getting started 3.4 Connecting Four I/O ports are provided for connecting the actuators / sensors for Standard I/O Sensors / and/or IO-Link Actuators 3.4.1 IO-Link port IO-Link port M12, A coded, female +24 V DC, 1,4 A...
  • Page 12: Technical Data

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Technical data 4.1 Dimensions Front side 4.2 Dimensions Cutout Backside Dimensions represents standard cutout type 24. 4.3 Mechanical data Plastic Housing material Fieldbus Profibus: SUB-D 9 Pin (female) Supply power Terminal plugs, spring type (on the backside)
  • Page 13: Electrical Data

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Technical data 4.4 Electrical Data Operating voltage 18 ... 30 V DC Operation voltage AUXPower 18 ... 30 V DC, 12A, no internal fuse external protection requested Ripple < 1 % ≤ 200 mA Current draw without load -5 C …...
  • Page 14: Function Indicators

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Technical data 4.6 Function indicators LED 1 LED 2 LED 3 LED 4 Status LEDs Indicator Function LED 1 Green US Power supply sensors / Bus communication ok US Power supply sensors / Bus communication under voltage...
  • Page 15: Included Material

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Included material The BNI PBS … consists of the following components: 5.1 Included material  IO-block  2 blind plugs M12  20 labels  1 grommet www.balluff.com...
  • Page 16: Appendix

    Balluff Network Interface Profibus, BNI PBS-504-00x-K008 Appendix Ordercode BNI PBS-504-00x-K008 Balluff Network Interface Profibus Functions 504 = IP 54 IO-Modul, 4x IO-Link interfaces Pin 4, 4x AUX power interfaces Variants 000 = Standard version 001 = Software release 001 002 = IO-Link specification 1.1...
  • Page 17 Balluff Network Interface Profibus, BNI PBS-504-00x-K008 www.balluff.com...
  • Page 18 Balluff Network Interface Profibus, BNI PBS-504-00x-K008 www.balluff.com Balluff GmbH Schurwaldstrasse 9 73765 Neuhausen a.d.F. Germany Tel. +49 7158 173-0 Fax +49 7158 5010 www.balluff.com balluff@balluff.de...
