- Page 1 Operator's Manual Cutter CU200 / CU400 / CU600 Made in Germany...
- Page 2 Operator's Manual Edition: 05/2017 - Part No. 9009931 Copyright This documentation as well as translation hereof are property of cab Produkttechnik GmbH & Co. KG. The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original intended purpose demand the previous written authorization by cab.
-
Page 3: Table Of Contents
Table of Contents Introduction ..................4 Instructions ..................4 Intended Use ...................5 Safety Instructions ................6 Environment ..................6 Technical Data .................7 Mounting ..................8 Operation ..................10 Preparation ..................10 Standard Operation ...............10 Cutting on Demand ................ 11 Operation Without Cover Plates ............ 12 Printer Configuration ..............13 Maintenance .................15 Cleaning ..................15 Changing the Blades ..............17... -
Page 4: Introduction
Introduction 1.1 Instructions Important information and instructions in this documentation are designated as follows: Danger! Draws your attention to an exceptionally grave, impending danger to your health or life. Warning! Indicates a hazardous situation that could lead to injuries or material damage. -
Page 5: Intended Use
Introduction 1.2 Intended Use • The device is intended exclusively as an option for the printers of the SQUIX series for cutting suitable materials that have been approved by the manufacturer. Any other use or use going beyond this shall be regarded as improper use. -
Page 6: Safety Instructions
Introduction 1.3 Safety Instructions • Disconnect the printer from the electrical outlet before mounting or removing the cutter. • The cutter may only be operated when it is mounted on the printer. • Risk of injury, particularly during maintenance, the cutter blades are sharp. •... -
Page 7: Technical Data
Introduction 1.5 Technical Data Cutter CU200 CU400 CU600 for printer type SQUIX 2 SQUIX 4 SQUIX 4M SQUIX 6.3 SQUIX 4.3 SQUIX 4.3M Material width max. Material weight cardboard g/m² 60 - 300 Material thickness 0,05 - 1,1 Cutting length >... -
Page 8: Mounting
Mounting Removing Covers Loosen screw (2) and remove cover (1). Loosen screws (4) and remove cover (3). Mounting Cutter Tray Attention! For cutter operation there has to be mounted a tear-off plate or a dispense plate on the printer, to lead the material through the blades of the cutter. - Page 9 Mounting Mounting Cutter Attention! Disconnect the printer from the electrical outlet before mounting or removing the cutter. Insert the pins (3) of the cutter (5) into the holes (1) of the printer. Press the cutter against the printer. That way the plug of the cutter will be connected to the peripheral port (2) of the printer.
-
Page 10: Operation
Operation 3.1 Preparation Insert labels for tear-off mode Operator's manual of the printer. Place the media strip between the printhead and the drive roller, so that the front edge of the strip reaches through the cutter. Insert ribbon Operator's manual of the printer. ... -
Page 11: Cutting On Demand
Operation 3.3 Cutting on Demand In the "Cut on Demand" mode the print job will be split into steps, which can be released separately. Choose Printing > Print on demand = On. 4. Printer Configuration. Send a print job. ... -
Page 12: Operation Without Cover Plates
Operation 3.4 Operation Without Cover Plates Due to the most varied materials it can come in rare cases to transportation problems of the material depend of the cover plates. It's possible to clear this problem with dismounting the cover plates. Warning! Risk of injury! ... -
Page 13: Printer Configuration
Printer Configuration Note! The values of the setup are basic settings for the current printer/ cutter combination. After changing the cutter or printer a re-adjustment may be necessary. Changes required for processing different print jobs should be implemented by additional offsets available in the software. The offset values from setup and software are added together for execution. - Page 14 Printer Configuration Backfeed Start menu. Select Setup > Printing. Parameter Meaning Default Backfeed smart Method for backfeeding the label medium. Backfeeding is necessary in the cutting and peel-off modes since a label is pushed out passed the front edge of the next label above the print line when peeling off/cutting.
-
Page 15: Maintenance
Maintenance 5.1 Cleaning Warning! Disconnect the printer from the electrical outlet. Attention! Risk of injury. The cutter blades are sharp. 1. Remove the cutter from the printer. 2. Loosen the screws (2,4) and remove the cover sheets (1,3). 3. Remove dust and paper particles with a soft brush or a vacuum. 4. - Page 16 Maintenance Note! When cutting through the label material instead of the label gap remains of adhesive may accumulate on the blades. If operating in backfeed mode, such remains of adhesive may be deposited on the drive roller as well. Clean often the drive roller ( Printer Operator's Manual) and the cutter blades.
-
Page 17: Changing The Blades
Maintenance 5.2 Changing the Blades Warning! Disconnect the printer from the electrical outlet. 1. Remove the cutter from the printer. 2. Remove the cover sheets 5.1 on page 15. 3. Turn the axle (3) of the circular blade (2) with a screwdriver for slotted head screws (slot width 7 mm) so that the inscription (1) of the blade points downward. - Page 18 Maintenance 8. Remove spring (6) and lineal blade (12). 9. Insert the axle of the (new) lineal blade withe the washer (B) in the bearing (10) of the mounting plate. 10. Hang in the slack spring (6) to the pins of the mounting plate (9) and the lineal blade (11).
-
Page 19: Setting The Initial State Of The Cutter
Maintenance 5.3 Setting the Initial State of the Cutter To operate the cutter correctly after cleaning or after changing the blades the circular blade (4) and the clock wheel (11) must be adjusted to each other. 1. Unscrew the screws (1), (3) and (6, at the rear). 2. - Page 20 Maintenance 1 - right 2 - wrong 3 - wrong 4. Check the position of the clock wheel (11). • If the clock wheel is in the right position 1, the edge (10) of the clock wheel (11) is located in the area of the marking (9). If the clock wheel is in position 2 or 3 turn the circular blade to reach the position 1 : •...
-
Page 21: Licenses
• Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment EU Declaration of Conformity https://www.cab.de/media/pushfile.cfm?file=2788 6.2 FCC NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
