OPERATING INSTRUCTIONS

Wear safety glasses. Stand to one side of the strap when tensioning.
PLEASE NOTE: Do not operate tool without strap, as damage to the tool may occur.
1. With the dispenser placed
behind you, bring the strap over
the top and around the package,
place the straps together and
remove any excess slack.
2. Using your right hand, squeeze
the tension motor and stationary
handle together to open the
feedwheel and strap path. Using
your left hand, insert the
overlapped straps under the
feedwheel and through the
welding mechanism.
Leave only a short tail ahead of
the feedwheel and make sure
straps are aligned behind the
tool. Do not make a joint over a
void area of the package.
Make sure all bystanders are clear before proceeding.
