Climax MZ-1 User Manual

Smart home alarm control panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

1. INTRODUCTION _____________________________________________________________________ 1
2. APPLICATION OVERVIEW _____________________________________________________________ 2
3. GETTING STARTED __________________________________________________________________ 6
4. CONNECTING TO WEBPAGE __________________________________________________________ 9
5. SYSTEM SETTINGS _________________________________________________________________ 11
__________________________________________________________________________ 11
________________________________________________________________________ 13
__________________________________________________________________________ 16
__________________________________________________________________________ 18
_______________________________________________________________________ 20
________________________________________________________________________ 22
6. DEVICE MANAGEMENT ______________________________________________________________ 23
_______________________________________________________________________ 23
_____________________________________________________________________ 26
______________________________________________________________________ 27
_____________________________________________________________________ 28
7. CAPTURED EVENTS ________________________________________________________________ 33
8. HISTORY RECORDS _________________________________________________________________ 35
________________________________________________________________________ 35
9. PANEL CONTROL ___________________________________________________________________ 37
10. HOME AUTOMATION _______________________________________________________________ 38
11. FIRMWARE _______________________________________________________________________ 39

Table of Contents

Table of Contents
Table of Contents
Table of Contents
: _____________________________________________________________ 2
: ________________________________________________________________ 4
:_____________________________________________________________ 5
MZ-1/8 __________________________________________________ 6
MZ-1/8 ___________________________________________________ 6
___________________________________________________________________ 31
__________________________________________________________________ 31
___________________________________________________________ 32
__________________________________________________________ 32
_________________________________________________________________ 36

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MZ-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Climax MZ-1

Summary of Contents for Climax MZ-1

  • Page 1: Table Of Contents

    OWER UPPLY 2.3. S :_____________________________________________________________ 5 YSTEM EQUIREMENTS 3. GETTING STARTED __________________________________________________________________ 6 3.1. H MZ-1/8 __________________________________________________ 6 ARDWARE NSTALLATION FOR 3.2. S MZ-1/8 ___________________________________________________ 6 OFTWARE NSTALLATION FOR 4. CONNECTING TO WEBPAGE __________________________________________________________ 9 5. SYSTEM SETTINGS _________________________________________________________________ 11 5.1.

  • Page 2: Introduction

    This manual covers the installation, programming, and control of IP based MZ-1 and MZ-8 control panels. Both MZ-1 and MZ-8 supports full range IP reporting capability with webpage for setting configuration and system control, MZ-8 also has the extra function of reporting through...

  • Page 3: Application Overview

    2. Application Overview 2.1. Identifying the parts: Case A 1. Panel Status LED (Dual Colour - Red & Green) RED LED ON - System in Arm Mode. RED LED FLASHES - System in Home 1/2/3 Mode. GREEN LED ON - System in Disarm Mode. GREEN LED FLASHES - System in Learn Mode.
  • Page 4 3. Operational Status LED (Dual Colour - Yellow & Red) (with display priority) YELLOW LED ON - Network error LED OFF – Network ok LED Flashing Sequence: Network ok N etwork error ＞ 4. Buzzer 5. Ethernet Port 6. Learn / Reset Button 7.

  • Page 5: The Power Supply

    YELLOW LED ON – Other fault condition (not including AC Power Failure ). LED OFF – System normal. LED Flashing Sequence A larm A larm Memory P anel AC failure O ther Fault ： ＞ ＞ ＞ 3. Operational Status LED (Dual Colour - Yellow & Red) (with display priority) YELLOW LED ON - Network error LED OFF –...

  • Page 6: System Requirements

    2.3. System Requirements: The system requires a TCP/IP network environment for MZ-1/8 IP Panel to be included in your network. To install the CD Wizard, your computer must have: Microsoft Windows 98, ME, NT4.0, 2000, XP, Vista, 7 or 8 operating system.

  • Page 7: Getting Started

    3. Getting Started Read this section of the manual to learn how to set up your MZ-1/8 Panel and program System Settings over the Web page. 3.1. Hardware Installation for MZ-1/8 Step 1. Connect the Power Adaptor to a Wall Outlet and the other end to MZ-1/8. MZ-1/8 will emit one short beep and Panel Status GREEN LED will turn ON.
  • Page 8 Step 10. You will be able to locate the current MZ-1/8 IP address among the list. Displayed with MAC Address and Product version. Step 11. Once MZ-1/8 is identified, select MZ-1/8 and click on “Open Web Page” to link to the IP Security System Web page.
  • Page 9 The Configure setting is for you to setup the network setting manually. Step 1. Click on Configure Setting, the following window will display: Step 2. Enter the network information and MZ-1/8’s web user name and password. (Default) User Name: admin (Default) Password: admin1234 Step 3.

  • Page 10: Connecting To Webpage

    4. Connecting to Webpage Step 1. Select MZ-1/8 in the Finder software and click on “Open Webpage” to connect to MZ-1/8 webpage. Alternatively, enter MZ-1/8 IP address displayed in Finder into your browser’s address section and click “GO”. Step 2.
  • Page 11 Step 4. You will enter the Control Panel webpage, the current Control Panel information will be displayed.

  • Page 12: System Settings

    User Code The User Codes are used for users to acess the alarm system. A total of 10 4-digit User Codes can be stored in MZ-1/8. Each individual User can be given a name for easy recognition when viewing system events.
  • Page 13 Temporary Code The Temporary Code is used to access the system for a temporary user and is valid only once per arming and once per disarming. Afterwards, the Temporary Code is automatically erased and needs to be reset for a new Temporary user. The Temporary Code consists of 4 digits and is not activated as default by the factory.

  • Page 14: Report

    5.2. Report This page is for you to enter the report destination setting. MZ-1/8 can store up to 8 report destinations. Reporting Type: MZ-1/8 supports 5 reporting types: IP/RF reporting in CID format: Reporting destination format: ip://Account@Server IP:Port/CID For Example: ip://6543@59.124.123.22:8765/CID...
  • Page 15 Reporting destination format: // Account@Tel number For Example: //1234@0926064587 1234 @27940001 Reporting type Account (4-8 digits) Telephone Number Email reporting Reporting destination format: mailto: user@example.com For Example: mailto: sales@climax.com.tw mailto: sales@climax.com.tw Reporting type Email Account < > < > Reporting type must be entered in lowercase letters...
  • Page 16 Groups: You can assign reporting destinations to different groups, the reporting groups function according to the following rules: The reporting priority is based on to group number sequence. From Group 1 Group Group 2 Group 3 ….etc When more than one reporting destinations are assigned to a group, if a report is sent to one of the detinations successfully, the system will stop reporting to the rest of the reporting destination in the same group and move on to report to the next group.

  • Page 17: Panel

    5.3. Panel This page is for you to configure panel settings. Keyword The Keyword is used for receiving commands from users. When a user sends a command to the Control Panel, the correct keyword must be entered along with a valid User PIN code for the Control Panel to recognize the command.
  • Page 18 Interval: Set the interval waiting time Offset Period: This is to set the time delay before the first “Auto Check-in Report” report to be made. For example, if “Offset” time period is set to 2 Hours, then the Control Panel will make the first “Auto Check-in Report” report after 2 hours, High Temp.

  • Page 19: Area

    5.4. Area This page is for you to configure area settings. Final Door Final Door On: When the system is Away Armed with a Door Contact set to Entry attribute, the system will automatically arm the system once the Door Contact is closed even if the entry delay timer has not expired yet.
  • Page 20 Factory default is set to 10 seconds. Exit Delay Set the Exit Delay Timer for Away Arm, Home Arm 1, Home Arm 2, and Home Arm 3 modes. When you arm the system, the system will enter your selected arm mode after the Exit Delay Timer expires Factory default is set to 10 seconds.

  • Page 21: Network

    5.5. Network This page is for you to configure network settings. DHCP On: If DHCP is set to On, the Network will obtain the IP address automatically with a valid Network DHCP Server. Therefore, you won’t need to do any settings. You can only set DHCP to On if your Network environment supports DHCP.
  • Page 22 After finishing above settings, click “Submit” to update settings. XMPP XMPP setting enables the Control Panel to query the set destination. This setting is required for the Control Panel to connect to Climax’s Home Portal Server for further remote control. XMPP: server address. ex: xmpp://user:password@example.com...

  • Page 23: Upload

    5.6. Upload This page is for you to set upload destination for captured pictures and videos from PIR Camera and PIR Video Camera. Enter an email address, FTP address, server address, or mobile number for MMS delivery For email delivery, the SMTP setting under Network must be completed. The format is: mailto: user@example.com For MMS delivery to mobile phone (MZ-8 only), the MMS setting under RF must be completed.

  • Page 24: Device Management

    6. Device Management This page for you to learn in, edit, delete and control all the accessory devices. A total of 40 devices are allowed to be learnt in to the system, including RF and ZigBee devices. Only 6 PIR Cameras (VST-852/VST-852 Pro) or Video Camera (VST-873/VST-873Pro) can be learnt into the system.
  • Page 25 device information when you refresh the page, it means the Control Panel received supervision code from the sensor instead of learn code. Please resend the learn code again. Step4. Tick the device # box, then click “Add” to include the device in the Control Panel. Step5.
  • Page 26 Step7. After learning a device into the Control Panel, the Device Webpage will be changed to list all available functions. Local Learning: The Control Panel feature local learning function for you to learn in the device without using the webpage Step1.

  • Page 27: Add Device

    6.2. Add Device For RF devices, you can also add device into the Control Panel by entering the device’s RF code. (This function cannot be used with ZigBee devices) Step1. Select the zone number you want to assign the new device to Step2.

  • Page 28: Walk Test

    6.3. Walk Test Step1. Press “Start Walk Test” under either Learning or Device Management webpage. The Control Panel will enter Walk Test page. Step2. Press the learn button on your device (please refer to device manual for detail) to transmit a test code. Step3.

  • Page 29: Edit Device

    6.4. Edit Device After you learn in a device to the system, you should proceed to edit its setting. Step1. Under Device Management webpage, click “Edit”. The Control Panel will enter device editing page. Step2. Proceed to edit device settings, click “Submit” when you are satisfied with all settings or information..
  • Page 30 Name: Enter a name for the device, A maximum of 20 characters are allowed Zone: Select the device zone number. Attribute: For Door Contact you are requested to select the device attribute from Burglar, Home Omit, Home 1/2 Omit, Home 1/3 Omit, Home Access, Delay Zone, Away Only, Entry, Away Entry, 24 Hr, Fire, Medical Emergency, Water, Set/Unset Silent Panic, Personal Attack.
  • Page 31 When the system is in any Armed mode, and the Control Panel is counting down the Entry Delay, if a “Burglar” device is triggered, the Control Panel will not respond. During the Exit Delay period, if a “Burglar” device is triggered, the Control Panel will not respond .

  • Page 32: Delete Device

    Water The Water device is active all the time and does not have to be armed or disarmed. An Event Code of #154 will be reported with trigger. Set/Unset (For Door Contact Only) If the Door Contact is set to Set/Unset, the system will be disarmed when the Door Contract is triggered, and armed when Door Contact is closed.

  • Page 33: Power Switch Control

    6.7. Power Switch Control This section is for you to control Power Switch in the system Switch On: Select the desired Power Switch, then choose the time length you want to turn on the Power Switch, then click “Switch On” to confirm. Switch Off: Select the desired Power Switch, then click “Switch Off”...

  • Page 34: Captured Events

    7. Captured Events Pictures/Videos captured by PIR Camera and PIR Video Cameras will be displayed in this page. Only the pictures/videos of the 6 latest events will be stored. Click on the image or video to view the file. Time: The time when the picture/video is captured. Device: The Zone number of the PIR Camera/Video Camera triggered.
  • Page 35 Waiting for Capture: The PIR Camera/Video Camera is sending captured picture/video the the Control Panel. For Alarm Image/Video, if you disarm the Control Panel under this status, the captured image/video will be deleted and no image/picture will be sent. Upload: The PIR Camera/Video Camera has finished sending image/picture to Control Panel.

  • Page 36: History Records

    8. History Records 8.1. History The Control Panel history events are recorded in this page. The History memorizes the last 50 Panel events including: All Alarm Events with Device Zone- All Fault Warning Events from Panel or Device All Arming And Disarming Events by Panel and Remote Controller All Arming and Disarming Events by Remote Keypad with User information.

  • Page 37: Reported Event

    8.2. Reported Event The reported event history are recorded in this page.. A total of 50 reported events can be recorded with Time, CID Event Code, Device Group/Zone and User information. Time: The time when the Control Panel begins the report CID Event Code Format: The CID event code is recorded in 4 digits format of “Prefix + Event Code”...

  • Page 38: Panel Control

    9. Panel Control Under this page, you can choose to Away Arm, Home Arm 1/2/3, or Disarm the system. If any fault exists within the system, they will be displayed under this page. Current Mode Control Panel current mode. Away Arm: Away Arm will arm all devices in the system.

  • Page 39: Home Automation

    10. Home Automation This page is for you to setup Home Automation rules with condition and execution setting to control the alarm system or home appliance automatically. A total of 20 Home Automation rules are available for setting. Step1. Click “Edit” to configure setting for the selected rule number. You will enter edit page. Step2.

  • Page 40: Firmware

    Greater Temp: The rule will be activated when the temperature rises above set value. Lower Temp: The rule will be activated when the temperature drops below set value. Timer: The rule will be activated when system reaches set time Step3. Set the Execution Rule Switch Group: All Power Switches in selected group will be turned On/Off for set duration according to your setting.
  • Page 41 I n s t a n t I n s t a n t N o R e s p o n s e B u r g l a r B u r g l a r H o m e O m i t H o m e O m i t H o m e O m i t H o m e O m i t...
  • Page 42 I n s t a n t I n s t a n t I n s t a n t I n s t a n t I n s t a n t I n s t a n t I n s t a n t I n s t a n t S i l e n t S i l e n t P a n i c...
  • Page 43 137 – Panel Tamper When the Control Panel tamper switch is triggered. 147 – Sensor Supervision Failure When MZ-1/8 fails to receive the signal transmitted from any one of the devices individually for a preset period. 151 – Gas 154 – Water leakage...
  • Page 44 When fault exists in system, and the system is armed by ignoring the fault event. (Arm Fault Type set to Direct Arm) 602 – Periodic test report When MZ-1/8 makes periodic Check-in reporting. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
