Checking th e LEDs
You can verify the IntelliJack installation by checking the LEDs.
LED
(LAN)
(Power)
(Power-
forwarding)
CA UTION: Make sure the wiring closet port
connected to the IntelliJack white cable is
configured as a standard MDI-X port.
Description
On—the IntelliJack is connected to the network
and a link has been established.
Off—there is no connection to the network.
On—the IntelliJack is receiving power (local or
via the network). When you first connect power
to the IntelliJack, there is a delay of
approximately 5 seconds. The power LED light
blinks once or twice before remaining solid on.
Off—the IntelliJack is not receiving power.
On—the IntelliJack is connected to and is
forwarding power to an IEEE 802.3af-compliant
device.
Off—the IntelliJack is not connected to or is not
forwarding power to an IEEE 802.3af-compliant
device.

Checking the LEDs

11
