Option BG troubleshooting
SPG8000 Master Sync / Clock Reference Generator Service Manual
This section contains instructions and procedures for troubleshooting the Option
BG. These procedures will help you decide whether it is necessary to replace
your Option BG module.
If the SPG8000 does not boot up or if the display is not working, go to the
beginning of the troubleshooting section. (See page 65, Troubleshooting.)
Required equipment.
The equipment listed in the following table is required for troubleshooting.

Table 17: Equipment required for Option BG troubleshooting

Equipment description
Screwdriver handle
#1 Phillips tip
Procedure.
1. Before you start to troubleshoot a problem, back up your instrument settings
to a preset. (See page 65, Back up your instrument settings.)
2. Check the diagnostics in the SPG8000 troubleshooting table. (See Table 15.)
The diagnostics check many of the signals that the Main board provides to
the BG board.
3. Run the slot I/O test on the Genlock/Black board. This tests many of the
signals needed by the BG board.
4. Use the Option BG troubleshooting diagram to troubleshoot the option. (See
Figure 23.)
5. After the problem is solved, recall the preset that you created.
Minimum requirements/example
Accept Phillips-driver bits
Phillips-driver bit for #1 size screw heads
