Cover
R3267 Series OPT08
Rx Control Option
Operation Manual
MANUAL NUMBER
FOE-8370665C00
Applicable models
R3264
R3267
R3273
First printing September 1, 1999
1999
C
ADVANTEST CORPORATION
All rights reserved.
Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R3264 and is the answer not in the manual?

Questions and answers

Related Manuals for ADVANTEST R3264

Summary of Contents for ADVANTEST R3264

  • Page 1 Cover R3267 Series OPT08 Rx Control Option Operation Manual MANUAL NUMBER FOE-8370665C00 Applicable models R3264 R3267 R3273 First printing September 1, 1999 1999 ADVANTEST CORPORATION All rights reserved. Printed in Japan...

  • Page 2: Safety Summary

    Note that Advantest bears absolutely no responsibility for the result of operations caused due to incorrect or inappropriate use of this instrument. If the equipment is used in a manner not specified by Advantest, the protection provided by the equipment may be impaired.
  • Page 3 Note that the estimated lifespan for the parts listed below may be shortened by factors such as the environment where the instrument is stored or used, and how often the instrument is used. The parts inside are not user-replaceable. For a part replacement, please contact the Advantest sales office for servicing.
  • Page 4 Safety Summary Main Parts with Limited Life Part name Life Unit power supply 5 years Fan motor 5 years Electrolytic capacitor 5 years LCD display 6 years LCD backlight 2.5 years Floppy disk drive 5 years • Hard Disk Mounted Products The operational warnings are listed below.

  • Page 5: Environmental Conditions

    Environmental Conditions This instrument should be only be used in an area which satisfies the following conditions: • An area free from corrosive gas • An area away from direct sunlight • A dust-free area • An area free from vibrations Direct sunlight Dust Corrosive...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS R3267 Series Option08 Rx Control Option Operation Manual TABLE OF CONTENTS OUTLINE OF THE PRODUCT ..............Outline ......................... BEFORE STARTING ..................Confirmation of the accessories ................How to connect to R3560, R3561 or R3562 ............2.2.1 Connecting the R3267 Series to R3560 ............2.2.2 Connecting the R3267 Series to R3561 or R3562 ........
  • Page 7 R3267 Series Option08 Rx Control Option Operation Manual Table of Contents Setup Example ..................... 6-46 ALPHABETICAL INDEX ..................
  • Page 8 R3267 Series Option08 Rx Control Option Operation Manual LIST OF ILLUSTRATIONS Title Page Connection between R3267 Series and R3560 (Rear panel) ..........Connection between R3267 Series and R3560 (Front panel) ........... Connection between R3267 Series and R3561 or R3562 (Rear panel) ......Serial port selection screen ....................
  • Page 9 R3267 Series Option08 Rx Control Option Operation Manual List of Illustrations Title Page 5-17 External I/Q Parameter Setup Dialog Box ................ 5-24 5-18 Save Register List Dialog Box ..................5-25 5-19 Recall Register List Dialog Box ..................5-26 5-20 Connecting the DUT ......................5-27 5-21 STD Parameter Setup Dialog Box ..................
  • Page 10 R3267 Series Option08 Rx Control Option Operation Manual List of Illustrations Title Page 6-39 Clock/Timing Signal Parameter Setup Dialog Box ............6-47 6-40 General Parameter Setup Dialog Box ................6-48 6-41 Frame Parameter Setup Dialog Box <Reverse: RC1> ............6-49 6-42 Traffic Channel A Parameter Setup Dialog Box ..............
  • Page 11 R3267 Series Option08 Rx Control Option Operation Manual LIST OF TABLES Title Page Standard accessories ......................Time defined according to the system mode and the rate ..........3-11 Effective setting condition in Burst Trigger functions ............. 3-11 SACCH settable range ...................... 3-13 Scramble pattern setting range ..................

  • Page 12: Outline Of The Product

    When you control R3267 Series and R3560, R3561 or R3562 from GPIB by using external personal com- puter, connect the external computer to both GPIB ports and control them individually. Some functions may not be supported depending on the version of the R3560 main unit. Before using, contact the nearest ADVANTEST Field Office or representative.

  • Page 13: Before Starting

    Check the quantity and rating of standard accessories to assure their conformance with Table 2-1. Table 2-1 Standard accessories Specification Items Quantity Remarks (Type) R3560 interface cable A01274 R3267 Series OPT08 ER3267/73OPT08 English Operation Manual Note: Please inform ADVANTEST the type when you order additional accessories.

  • Page 14: How To Connect To R3560, R3561 Or R3562

    R3267 Series Option08 Rx Control Option Operation Manual 2.2 How to connect to R3560, R3561 or R3562 How to connect to R3560, R3561 or R3562 2.2.1 Connecting the R3267 Series to R3560 Connections on the rear panel Connect the cable (see note *1) from the serial I/O connector on the R3267 Series to the serial I/O connector on the R3560 as shown in Figure 2-1.

  • Page 15: Connecting The R3267 Series To R3561 Or R3562

    R3267 Series Option08 Rx Control Option Operation Manual 2.2 How to connect to R3560, R3561 or R3562 2.2.2 Connecting the R3267 Series to R3561 or R3562 Connections on the rear panels. Connect the cable (see note *1) from the serial I/O connector on the R3267 Series to the serial I/O connec- tor on the R3561 or R3562 as shown in Figure 2-3 which shows the R3267 Series and R3561 rear panels.

  • Page 16: Serial Port Setting

    R3267 Series Option08 Rx Control Option Operation Manual 2.3 Serial port setting Serial port setting Pressing CONFIG and RS232 displays the serial port setting menu. Before using OPT08, check that Rx Control is selected. If a mode other than Rx Control is selected, change the mode to Rx Control.

  • Page 17: How To Operate The R3560

    R3267 Series Option08 Rx Control Option Operation Manual 3.1 Outline HOW TO OPERATE THE R3560 This chapter describes all key functions of the R3560. Outline Figure 3-1 Initial screen The operation menu of R3560 is placed under the ADVANCE. Press ADVANCE and Rx Control [R3560], R3267 Series becomes R3560 control mode and displays Initial screen shown in Figure 3-2 to set and measure R3560.
  • Page 18 R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Reference This section describes the functions of all panel and soft keys. • Menu Index: Use this index as a key index to Chapter 3. • Menu Map: Shows a list of hierarchical menus on a panel key basis. •...
  • Page 19 R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference 3.2.2 Menu Map All R3560 soft menus, which are under the ADVANCE key, are shown below. NOTE: Represents a panel key. Represents a dialog box. Unless otherwise noted, the soft menus are shown. ADVANCE Rx Control [R3560]...
  • Page 20 R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference 3.2.3 Functional Description Output frequency setting FREQ Sets output frequency. The frequencies which can be set are different depending on the system mode. PDCL: PDC 800 MHz band PDCH: PDC 1.5 GHz band DNT: Downlink traffic channel UPT:...

  • Page 21: Ber Measurement Screen

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference BER measurement Press SINGLE or REPEAT(START/STOP) to start the measurement. Press REPEAT(START/STOP) to stop the current measurement. Enters into BER (Bit Error Rate) measurement mode. Figure 3-3 BER measurement screen Parameter Setup Dialog box for BER measurement parameter setting is displayed to set bit length or average number of times, etc.
  • Page 22 R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Bit Length Set BER measurement time with the bit length. The setting range of the bit length is 1000 to 1000000 bits. Average Times Set measurement averaging count. The setting range of the averaging count is 1 to 32 times. Interval Set interval time between receipt of measurement start from R3560 and actual measurement start.

  • Page 23: Sens Measurement Screen

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Receiver sensitivity (Sens) measurement Press SINGLE or REPEAT(START/STOP) to start the measurement. Press REPEAT(START/STOP) to stop the current measurement. Sens Enters into the receiver sensitivity measurement mode. Figure 3-5 Sens measurement screen Parameter Setup Displays a dialog box to set the receiver sensitivity measurement parameter and sets output level, etc to start the receiver sensitivity measurement.
  • Page 24 R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Start Set output level (the search upper limit value) to start sensitivity measurement. The relationship between the search upper limit value and the search lower limit value should be; Search upper limit value > Search lower limit value. Stop Set output level (the search lower limit value) to end sensitivity measurement.

  • Page 25: Setup Setting Screen

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Sync ON/OFF Switch the synchronization burst output of PHS to ON/OFF. This is available only on conditions that the system mode is PHS and that the slot pattern is DNT/UPT. When ON is selected, the synchronization burst frame is output.
  • Page 26 R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Slot Config Sets slot pattern. FIL: FILL pattern DEV: Frame for device evaluation DNT: Downlink traffic channel UPT: Uplink traffic channel DSYNC: Downlink synchronization burst frame (PHS only) USYNC: Uplink synchronization burst frame (PHS only) Modulation Switches modulation and non-modulation of the output.

  • Page 27: Timing Of Rf Signal Output Vs The Burst Trigger Input Signal

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Trigger Delay Sets the delay from the input signal of the R3560 Burst Trigger in terminal in symbols. When a signal effective to the Burst Trigger in terminal is gotten,delay can be changed within ±10 symbols (resolution of 0.1 symbols) based on the time “T”...

  • Page 28: Slot Setting Screen

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Slot Setup The dialog box to set modulation pattern and communication rate in the slot is displayed. Figure 3-9 SLOT setting screen Rate Switch the communication rate. The setting can be performed only when the system mode is PDCL/PDCH.

  • Page 29: Sacch Settable Range

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Burst (*1) Switch ON/OFF of the current slot which was selected at Slot. Sets the slot to ON. OFF: Sets the slot to OFF. Color Code (*1, *2) Set the color code in the slot. The setting can be performed only when the system mode is PDCL/PDCH.

  • Page 30: Scramble Pattern Setting Range

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Scramble Code (*2) Set scramble pattern. The setting ranges are different depending on the system mode. Table 3-4 Scramble pattern setting range Setting range System mode Minimum value Maximum value PDCL/PDCH 0 (Hexadecimal) 1FF (Hexadecimal)

  • Page 31: Setting Value Of The Synchronization Word

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Sync Word Specify the slot and change the synchronization word. This command can be set when the system mode is PDCL or PDCH and the slot configuration is UPT or DNT. Setting value of the synchronization word is shown in Table 3-5.

  • Page 32: Save Operation Screen

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Saving Saves all currently-set conditions to the R3560 backup memory according to the specified mem- ory number. Save The save operation screen is displayed. To select the memory number and to execute data saving, use a knob. Figure 3-10 Save operation screen In the save operation screen, the major settings inside the R3560 backup memory are displayed.

  • Page 33: Ber Measurement Screen (In Occurrence Of Sync Error)

    R3267 Series Option08 Rx Control Option Operation Manual 3.2 Reference Recalling Re-sets all set conditions of the memory according to the specified memory number of the R3560 backup memory. Recall The recall operation screen is displayed. To select the memory number and to execute data recalling, use a knob.

  • Page 34: Ber Measurement Connection

    R3267 Series Option08 Rx Control Option Operation Manual 3.3 Example of the measurement (BER measurement) Example of the measurement (BER measurement) Here explains the outline of the operation with a measurement example of a receiver which has a control mode to receive physical channel for down communication. Receiver controller Receiver...
  • Page 35 R3267 Series Option08 Rx Control Option Operation Manual 3.3 Example of the measurement (BER measurement) Press LEVEL and set R3560 output level to a suitable level for the receiver. Set the receiver in a receivable mode using the receiving controller. Pressing BER and BER Param displays dialog box for BER counter setting.

  • Page 36: Initial Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.1 Outline HOW TO OPERATE THE R3561 This chapter describes all key functions of the R3561. Outline Figure 4-1 Initial screen The operation menu of R3561 is placed under the ADVANCE. Press ADVANCE and Rx Control [R3561], R3267 Series becomes R3561 control mode and displays Initial screen shown in Figure 4-2 to set and measure R3561.

  • Page 37: Reference

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Reference This section describes the functions of all panel and soft keys. • Menu Index: Use this index as a key index to Chapter 4. • Menu Map: Shows a list of hierarchical menus on a panel key basis. •...
  • Page 38 R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Synth Ref ..........4-5 Traffic PRBS ........... 4-4, 4-9 Unit ............4-5, 4-12 Upper Limit ..........4-5, 4-12...
  • Page 39 R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference 4.2.2 Menu Map A list of soft menus, which are under the ADVANCE key, used with the R3561 are shown below. NOTE: Represents a panel key. Represents a dialog box. Unless otherwise noted, the soft menus are shown.
  • Page 40 R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Frequency Setup Link Level Setup Channel Mode Modulation ON/OFF Generator Mode Output ON/OFF Equalizing Data Burst Clock Setup Eb/No [CH A/No] Cal/Test CH A Save Level Ratio Recall CH B Preset Level Ratio CH C...

  • Page 41: General Dialog Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference 4.2.3 Functional Description Setting the output frequency FREQ A window prompting numeric values is displayed. Sets the output frequency. Use the up or down keys, the data knob and the numeric keys to enter data. Setting the output level LEVEL A window prompting numeric values is displayed.
  • Page 42 R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Channel Mode Selects the base band channel multiplexing. When in the Reverse link, only SINGLE mode can be used. MULT: Multiplexed output from channels A, B and C is obtained. SINGLE: Outputs channel A only.

  • Page 43: Frame A Dialog Box Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference PN Offset Sets the PN sequence offset value. 1PN Offset = 64 chips I/Q Source Selects the signal to be input to the IQ-Modulator. INTERNAL: Connects the internal base band IQ signal. EXT AC: Couples the external IQ signal with an AC coupling.

  • Page 44: Channel Signals

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Table 4-1 Channel Signals Channel Signal Type Description PILOT When LINK is set to FORWARD, this becomes the PILOT channel based on the TIA/EAI IS95 standards. ZEROS When LINK is set to REVERSE, the data pattern (ZEROES) is DATA ALL0.

  • Page 45: Edit Menu Dialog Box Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Figure 4-5 Edit Menu Dialog Box Screen The items you set to ON (on this screen) can be changed on the general dialog box screen shown in Figure 4-3. If you set unnecessary items to OFF, these items will be skipped when operating the step keys.

  • Page 46: Freq Para. Dialog Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Setting the output frequency and output level Frequency & Level A dialog box related to frequency and level settings will be displayed. Frequency Setup A dialog box related to frequency parameter settings will be displayed. Figure 4-6 Freq Para.

  • Page 47: Level Para. Dialog Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Figure 4-7 Level Para. Dialog Screen Unit Selects the unit to display or enter the data. Upper Limit Sets the upper limit. Level Offset Toggles the level offset addition function on or off. Offset Value Sets the level offset value.

  • Page 48: Other Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Others Using this screen, other functions can be set. Other Furthermore, Preset, Clock Setup and so on are displayed. When return is pressed, the screen display returns to the initial screen. Figure 4-8 Other Screen Clock Setup The dialog box which sets various clock signals is displayed.

  • Page 49: Types Of Cdma Frame Clock

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Synth Ref Selects the reference frequency of the signal which is output from the SYNTHE REF IN terminal and input to the RF synthesizer reference circuit. When INTERNAL is selected, however, the internal reference oscillator signal is input to the RF synthesizer reference circuit.

  • Page 50: Cal/Self Test Screen

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Figure 4-10 Cal/Self Test Screen AWGN Calibrates the AWGN level and CDMA signal level. When the generator mode is selected to "Eb/Nt(Eb/No)", a calibration is required. CAUTION:It takes 10 to 30 seconds to perform the calibration. When an abnormal condition is detected during calibration, an error message will be displayed and the calibration will be terminated.

  • Page 51: Save/Recall Display Screen

    When the self-test detects an error, an error message and the corresponding error code will be displayed with the POWER, REMOTE and SYNTHE UNLOCK lights lit at the same time (for more detailed information on error codes, refer to the R3561 Operation manual). Contact the nearest ADVANTEST Field Office or representative. Save Saves the currently set value in the R3561 back-up memory.Pressing this key...

  • Page 52: Set Values When Preset

    R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Setting the Output level Output ON/OFF Toggles the output signal on or off 4.2.4 Preset Values Table 4-3 Set Values when Preset (1 of 4) Section Item to Be Set Channel Set value/Selected value Output frequency...
  • Page 53 R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Table 4-3 Set Values when Preset (2 of 4) Section Item to Be Set Channel Set value/Selected value Modulation Modulation ON/OFF Link FORWARD Channel mode MULTI Generator mode SIGNAL ONLY Equalizing Filter ON/OFF Data burst Eb/No (Eb/Nt) value...
  • Page 54 R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Table 4-3 Set Values when Preset (3 of 4) Section Item to Be Set Channel Set value/Selected value Frame Channel assignment TRAFFIC PRIMARY SYNC PILOT Channel code Traffic PRBS PN15 PN15 Data rate 9600bps...
  • Page 55 R3267 Series Option08 Rx Control Option Operation Manual 4.2 Reference Table 4-3 Set Values when Preset (4 of 4) Section Item to Be Set Channel Set value/Selected value Input/Output EVEN SEC/SYNC IN DISABLE CDMA CLOCK OUT EVEN SECOND IN CDMA TIMEBASE OUT Synthe Reference IN INTERNAL CDMA TIMEBASE IN...

  • Page 56: Initial Screen (For The R3562 Standard Configuration)

    R3267 Series Option08 Rx Control Option Operation Manual 5.1 Outline HOW TO OPERATE THE R3562 This chapter describes all key functions of the R3562. Outline Figure 5-1 Initial Screen (For the R3562 Standard Configuration) The operation menu of R3562 is placed under the ADVANCE. Press ADVANCE and Rx Control [R3562], R3267 Series becomes R3562 control mode and displays the screen shown in Figure 5-3 to set and measure R3562.

  • Page 57: Initial Screen (With The R3562 Opt 65 Installed)

    R3267 Series Option08 Rx Control Option Operation Manual 5.1 Outline [Setting up the communication system] Figure 5-2 Initial Screen (with the R3562 OPT 65 Installed) If OPT65 is installed in the R3562, the R3562 communication system must always be set to the 3GPP mode. When the Comm.sys key on the Initial screen is set to cdma2000 (highlighted) (Figure 5-2), a mode is not set correctly.

  • Page 58: R3562 Control Main Screen (3Gpp)

    R3267 Series Option08 Rx Control Option Operation Manual 5.1 Outline Figure 5-3 R3562 Control Main Screen (3GPP)
  • Page 59 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Reference This chapter describes the functions of all panel and soft keys. • Menu Index: Use this index as a key index to Chapter 5. • Menu Map: Shows a list of hierarchical menus on a panel key basis. •...
  • Page 60 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference 5-10, 5-24 Modulation..........5-6, 5-10 Modulation ON/OFF ....... 5-6, 5-8, 5-9, 5-16, 5-23, 5-26 Offset Value..........5-8, 5-22 Other ............5-6, 5-23 Output ON/OFF ........5-6, 5-8, 5-10, 5-16, 5-23, 5-26 Parameter Setup ........

  • Page 61: Menu Map

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference 5.2.2 Menu Map A list of soft menus, which are under the ADVANCE key, used with the R3562 are shown below. NOTE: Represents a panel key. Represents a dialog box. Unless otherwise noted, the soft menus are shown.
  • Page 62 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference TPC Repeat Count TPC Insert [TPC Insert] DPCCH Setup Direction DTCH/DCCH Setup Count more 1/2 TFCI [DTCH] Data [DCCH] Data TPC Insert TPC Repeat Count DPCCH Setup [TPC Insert] DTCH/DCCH Setup Direction Ext Trigger Count...
  • Page 63 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Frequency Setup Freq Input Level Setup CH Start Freq. CH Step Freq. Modulation ON/OFF CH Start No. Output ON/OFF Step Size *5 Unit Upper Limit Level Offset Offset Value Step Size *5 ALC Mode Clock &...

  • Page 64: Ber Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference 5.2.3 Functional Description This section describes the front panel keys and the soft menus associated with them. FREQ A window prompting numeric values is displayed. Sets the output frequency. Use the up or down keys, the data knob and the numeric keys to enter data.

  • Page 65: Clock/Timing Signal Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference OFF: Does not modulate the RF output. Output ON/OFF Turns the RF output on or off. Turns the RF signal on. OFF: Turns the RF signal off. Quit Exits from BER Measurement Mode. Modulation Displays the modulation 1/2 menu.

  • Page 66: General Parameter Setup Dialog Box (For The Downlink)

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference SLOT TIMING: Outputs the slot timing. CHIP CLOCK: Outputs the CHIP clock. TPC REPEAT: Outputs the first slot timing used for the TPC com- mand sequence during Repeat operation. TPC INSERT: Outputs the first slot timing used for the TPC com- mand sequence during the Insert operation.
  • Page 67 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference DPCH Channel Config. Select the channel configuration from the following list. PHYS.(8)/30ksps: Assigns Physical Data Mode with a slot format number of 8 and a channel symbol rate of 30 [ksps]. PHYS.(9)/30ksps: Assigns Physical Data Mode with a slot format number of 9 and a channel symbol rate of 30 [ksps].
  • Page 68 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference number of 15, an information bit rate of 384 [kbps] and a channel symbol rate of 480 [ksps]. DPDCH Data Selects the data to be input to the DPDCH when DPCH Channel Config is set to Physical Data Mode.
  • Page 69 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference PHYS.(5)/480ksps: Assigns Physical Data Mode with a slot format number of 5 and a channel symbol rate of 480 [ksps]. PHYS.(6)/960ksps: Assigns Physical Data Mode with a slot format number of 6 and a channel symbol rate of 960 [ksps].

  • Page 70: Std Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Uses the bit configuration for the slot format num- ber 5. [Gain Parameter] Sets the gain (power) ratio for a DPCCH to a DPDCH. There are four possible combinations. DPCCH Gain Code Sets the ratio for DPCCH gain to βc, using the gain parameter code if DPDCH gain to βd is 1.
  • Page 71 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference I/Q Direction Exchanges the external IQ terminals between the input and output and selects the IQ signal paths to the IQ modulator. OFF: Turns off the IQ output, and inputs the internal baseband signal to the IQ modulator.

  • Page 72: Dtch/Dcch Parameter Setup Dialog Box (For The Downlink)

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference TPC Repeat Count Sets the TPC slot length for the Repeat operation. [TPC Insert] Inserts TPC commands of 1 or 0 into consecutive slots as speci- fied by the TPC insertion slot length during the Repeat operation. Direction Selects the direction (Up or Down) during the Insert operation.
  • Page 73 R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Sets whether or not FEC (Convolutional or Turbo Coding) pro- cessing is performed. FEC processing is performed. OFF: FEC processing is not performed. Sets the mode used to generate CRC data which is based on the calculated CRC value.

  • Page 74: Dpcch Parameter Setup Dialog Box (For The Uplink)

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference <When set to Uplink> TPC Insert The TPC command is inserted during Repeat operation. The direction and slot length of the TPC command you want to in- sert can be specified in the TPC Insert item in the DPCCH Param- eter dialog box.

  • Page 75: Dtch/Dcch Parameter Setup Dialog Box (For The Downlink)

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Figure 5-12 DTCH/DCCH Parameter Setup Dialog box (For the Downlink) [DTCH] The DTCH value set when the data mode for the channel config- uration settings is set to Information Data Mode is valid. Data Selects the data used for Information data.

  • Page 76: Ext Trigger Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference PN9 ERR: Selects PN9 with an error of 1%. Sets whether or not FEC (Convolutional or Turbo Coding) pro- cessing is performed. FEC processing is performed. OFF: FEC processing is not performed. Sets the mode used to generate CRC data which is based on the calculated CRC value.

  • Page 77: Frequency Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Frequency & Level Displays the Frequency & Level menu. Frequency Setup Displays the Frequency Parameter Setup dialog box. Figure 5-14 Frequency Parameter Setup Dialog Box Freq Input Selects the frequency entry mode. FREQUENCY: Directly enters a frequency value.

  • Page 78: Clock/Timing Signal Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Step Size Sets the step value of the step keys. ALC Mode Selects the ALC operating mode. Automatically selects the optimum operating mode depending on the R3562 settings. (For details, refer to the R3562 Operation manual.) AUTO: Normal ALC S/H:...

  • Page 79: External I/Q Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference 15 MHz: Uses an external signal of 15 MHz. INTERNAL: Uses the internal reference signal. 10MHz Ref Adj. Sets internal reference signal’s frequency difference to be correct- MOD-TB In Selects the reference signal used for the modulation. 3.84 MHz: Uses an external signal of 3.84 MHz.

  • Page 80: Save Register List Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference INPUT: Inputs the IQ signal from the outside to the IQ mod- ulator. OUTPUT: Turns on the IQ output, and inputs the internal baseband signal to the IQ modulator. NOTE: The level and modulation accuracy of the RF output can- not be guaranteed while in the OUTPUT mode.

  • Page 81: Recall Register List Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.2 Reference Recall Displays the Recall Register List dialog box. Recall is performed when the ENTER is pressed after the register has been selected. Figure 5-19 Recall Register List Dialog Box Preset Initializes the settings.

  • Page 82: Connecting The Dut

    R3267 Series Option08 Rx Control Option Operation Manual 5.3 Measurement Example Measurement Example This example shows the BER measurement of channel used in the Downlink. Measurement conditions: The items to be measured are shown below. Set the measurement conditions to be suitable for the targeted measurement.

  • Page 83: Std Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.3 Measurement Example Setting up the unit under test The measurement conditions are set accodeing to the specifications of the unit under test. Initialization Press ADVANCE, Rx Control[R3562], Other and Preset. Setting the output signal Press FREQ, 2, 1, 1, 0 and MHz.

  • Page 84: General Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.3 Measurement Example Figure 5-22 General Parameter Setup Dialog Box Set the following items. Scrambling Code:0 DPCH Channel Config: INFO.(11)/12.2kbps DPDCH DATA:PN9 DPCH Channel. Code: [Channel Power Ratio] CPICH: P-CCPCH: DPCH: 10. Press more 2/2 and DTCH/DCCH Setup. The DTCH/DCCH Parameter Setup dialog box is displayed.

  • Page 85: Ber Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 5.3 Measurement Example Figure 5-23 DTCH/DCCH Parameter Setup Dialog Box 11. Set the following items for DTCH and DCCH. Data:PN9 FEC:ON CRC:NORMAL 12. Press Return. Setting the BER counter 13. Press BER and Parameter Setup. The BER Parameter Setup dialog box is displayed.

  • Page 86: Measurement Result On The Bit Error Rate

    R3267 Series Option08 Rx Control Option Operation Manual 5.3 Measurement Example 14. Set the following items. Data:PN9 Bit Length:10000 Clock Edge:NEG Data Polarity:POS Starting the measurement 15. Press REPEAT. The bit error rate is displayed. Figure 5-25 Measurement Result on the Bit Error Rate 5-31...

  • Page 87: Initial Screen

    R3267 Series Option08 Rx Control Option Operation Manual 6.1 Outline HOW TO OPERATE THE R3562 OPT65 This chapter describes all key functions of the R3562 OPT65 cdma2000 option. Outline The operation menu of R3562 is placed under the ADVANCE. Press ADVANCE and Rx Control [R3562], R3267 Series becomes R3562 control mode and displays the screen shown in Figure 6-2 to set and measure R3562.

  • Page 88: R3562 Control Main Screen (Cdma2000)

    R3267 Series Option08 Rx Control Option Operation Manual 6.1 Outline Figure 6-2 R3562 Control Main Screen (cdma2000)

  • Page 89: Reference

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Reference This chapter describes the functions of all panel and soft keys. • Menu Index: Use this index as a key index to Chapter 6. • Menu Map: Shows a list of hierarchical menus on a panel key basis. •...
  • Page 90 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference DCCH Setup ........... 6-9, 6-32 6-45 Eb/No ............6-6, 6-7, Modulator..........6-10, 6-45 6-15, 6-16, Modulator Cal Corr......... 6-45 6-19, 6-22 Modulator Cal Corr ON/OFF....6-10 Entry Mode ..........6-9, 6-32 Offset Value ..........
  • Page 91 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference 6-12, 6-42 Unit ............6-10, 6-41 Upper Limit ..........6-10, 6-41 Walsh Len..........6-26, 6-28, 6-30 Walsh No..........6-26, 6-28, 6-30...

  • Page 92: Menu Map

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference 6.2.2 Menu Map A list of soft menus, which are under the ADVANCE key, used with the R3562 are shown below. NOTE: Represents a panel key. Represents a dialog box. Unless otherwise noted, the soft menus are shown.
  • Page 93 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference FORWARD LINK (RC1, RC2) Equalizing Filter Generator Mode Eb/No Primary Ch.(Eb) Power Adjustment Ch. [PICH] [SYNCH] [FCH(A)] [FCH(B)] [FCH(C)] FORWARD LINK (RC3, RC4, RC5) Equalizing Filter Generator Mode Eb/No Primary Ch.(Eb) Power Adjustment Ch.
  • Page 94 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference REVERSE LINK (RC1) Coding Channel [FCH(A)] REVERSE LINK (RC2) Coding Channel [FCH(A)] REVERSE LINK (RC3) Coding Channel [DCCH] [SCH2(A)] [FCH(B)] [SCH(C)] REVERSE LINK (RC4) Coding Channel [DCCH] [SCH2(A)] [FCH(B)] [SCH(C)]...
  • Page 95 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference REVERSE LINK (RC1, RC2) FCH(TRCH A) Setup Data more 1/2 Repeat Pattern Error Ratio REVERSE LINK (RC3, RC4) Block Interleaver Add. Bit Error PICH Setup DCCH Setup Gating SCH2(TRCH A) Setup Gating Rate FCH(TRCH B) Setup Power Control Pattern...
  • Page 96 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Frequency Setup Freq Input Level Setup CH Start Freq. CH Step Freq. Modulation ON/OFF CH Start No. Output ON/OFF Step Size Unit Upper Limit Level Offset Offset Value Step Size ALC Mode Clock &...

  • Page 97: Ber Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference 6.2.3 Functional Description This section describes the front panel keys and the soft menus associated with them. FREQ A window prompting numeric values is displayed. Sets the output frequency. Use the up or down keys, the data knob and the numeric keys to enter data.

  • Page 98: Clock/Timing Signal Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference OFF: Does not modulate the RF output. Output ON/OFF Turns the RF output on or off. Turns the RF signal on. OFF: Turns the RF signal off. Quit Exits from BER Measurement Mode. Modulation Displays the Mod.

  • Page 99: General Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference 2 MHz: Uses an external signal of 2 MHz. 2.4576 MHz: Uses an external signal of 2.4576 MHz. 4.9152 MHz: Uses an external signal of 4.9152 MHz. 5 MHz: Uses an external signal of 5 MHz. 9.8304 MHz: Uses an external signal of 9.8304 MHz.
  • Page 100 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Burst Toggles the Fundamental Channel burst on or off. Turns the burst on. OFF: Turns the burst off. NOTE: The burst is automatically turned off when Radio Config- uration is set to 3 or 4. EXT Trigger Sets whether or not the baseband block of this instrument is syn- chronized with the even-second signal input to the EXT TRIG IN...

  • Page 101: General Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference NOTE: First perform an AWGN calibration before setting the generator mode to Eb/No. Eb/No Sets an Eb/No(Nt) value for the primary channel. Primary Ch.(Eb) The primary channel is fixed for Radio Configuration 1 or 2. <When Reverse Is Set to RC3 or RC4>...
  • Page 102 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference PN Offset Sets a PN offset value for the even-second signal if EXT Trigger is set to ENABLE and the instrument is synchronized with the even-second signal. One PN offset is 64 chips. As a result, the relationship between the chip quantity and the PN offset setting value is as shown be- low: OFFSET [in chips] = Round-off (64 ×...
  • Page 103 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference PICH: Selects Pilot Channel as the output supplemental channel. DCCH: Selects Dedicated Control Channel as the output supplemental channel. SCH2(A): Selects Supplemental Channel 2 as the output sup- plemental channel. FCH(B): Selects Fundamental Channel as the output supple- mental channel.

  • Page 104: General Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Table 6-1 Example 1 showing when the Output Level Supplemental Channel is OFF Channel Case a Case b Pilot Channel -5dB -10dB Dedicated Control -5dB -10dB Channel Supplemental -5dB -10dB Channel 2(A) If the output level supplemental channel is not selected (or off), any channel level that is 20 dB or more than the sum total channel...
  • Page 105 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Equalizing Turns Equalizing Filter on or off. Generator Mode Selects a signal input to the IQ modulator. SIGNAL: Selects a CDMA signal. NOISE: Selects an AWGN signal with a bandpass of 2 MHz.

  • Page 106: Example 1 Showing When The Output Level Supplemental Channel Is Off

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference [SYNCH] Turns the Sync Channel output on or off, and sets Power Ratio. [FCH(A)] Turns the Fundamental Channel(A) output on or off, and sets Power Ratio. [FCH(B)] Turns the Fundamental Channel(B) output on or off, and sets Power Ratio.

  • Page 107: General Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Table 6-4 Example 2 showing when the Output Level Supplemental Channel is OFF Channel Setting level Limit value Pilot Channel -1.9dB Upper limit value Sync Channel -2.0dB Upper limit value Fundamental Channel(A) -18.9dB Lower limit value...
  • Page 108 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Eb/No Sets an Eb/No(Nt) value for the primary channel. Primary Ch.(Eb) Selects the primary channel from the Traffic channels A, B and C with the outputs turned on. The selected channel is used as the tar- get channel of Eb/No(Nt).

  • Page 109: Example 1 Showing When The Output Level Supplemental Channel Is Off

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference The output of the channel selected as the output level supplemen- tal channel cannot be turned off. After the output level supplemental channel has been selected, a channel level setting cannot be changed if the sum total of all the output channels exceeds 0 dB, and any channel whose output is currently turned off cannot be turned on.

  • Page 110: Std Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference STD Setup Displays the STD Parameter setup dialog box. Figure 6-9 STD Parameter Setup Dialog box I/Q Direction Exchanges the external IQ terminals between the input and output and selects the IQ signal paths to the IQ modulator. OFF: Turns off the IQ output, and inputs the internal baseband signal to the IQ modulator.

  • Page 111: Frame Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference [FCH(A)] Frame The frame length is fixed at 20 msec for RC1 or RC2. Rate Selects Data Rate. Fixed at Convolutional for RC1 or RC2. NOTE: The selection range for each parameter complies with the associated standards.

  • Page 112: Frame Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Figure 6-13 Frame Parameter Setup Dialog Box <When Reverse Is Set to RC 4> Coding Channel Selects a channel on which realtime coding is performed. DCCH: Performs realtime coding for Dedicated Control Channel.

  • Page 113: Frame Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Selects either Turbo Coding or Convolutional Coding. NOTE: The range for each parameter is prescribed by the stan- dard. For more information, refer to Section 2.3, “cdma2000 Function” and Section 3.2, “Channel Setup” in “R3562 OPT65 OPERATING MANUAL.”...
  • Page 114 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference FCH(A): Performs realtime coding for Fundamental Chan- nel(A). FCH(B): Performs realtime coding for Fundamental Chan- nel(B). FCH(C): Performs realtime coding for Fundamental Chan- nel(C). OFF: Turns realtime coding function off for each chan- nel.

  • Page 115: Frame Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Figure 6-16 Frame Parameter Setup Dialog Box <When Forward Is Set to RC3> Figure 6-17 Frame Parameter Setup Dialog Box <When Forward Is Set to RC4> 6-29...

  • Page 116: Frame Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Figure 6-18 Frame Parameter Setup Dialog Box <When Forward Is Set to RC5> Coding Channel Selects a channel on which realtime coding is performed. SCH(A): Performs realtime coding for Supplemental Chan- nel(A).

  • Page 117: Traffic Channel A Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Quasi Orthogonal Spreading can be performed using Forward Link RC3, RC4 or RC5. Select Functions 0 thru 3 which conform to the associated standards. NOTE: The selection range for each parameter complies with the associated standards.

  • Page 118: Pich Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Sets each CRC value correctly. OFF: Sets each CRC value to 0. ADD ERR: Adds an error to each CRC. Error Ratio Selects an error ratio that is added to CRC. Block Interleaver Toggles the Block Interleaving function on or off.

  • Page 119: Dcch Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Figure 6-21 DCCH Parameter Setup Dialog Box DATA Selects the data pattern input to the realtime coder (Information data) or the data pattern input to the spreading section (Physical data). PN9: Selects a 9-stage PN code data pattern.

  • Page 120: Traffic Channel B Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference DATA Selects the data pattern input to the realtime coder (Information data) or the data pattern input to the spreading section (Physical data). PN9: Selects a 9-stage PN code data pattern. PN15: Selects a 15-stage PN code data pattern.

  • Page 121: Traffic Channel C Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Rep. Pattern Specifies a value [in hexadecimal] for the arbitrarily set four bits. Selects a type of CRC to be added to the channel data. Sets each CRC value correctly. OFF: Sets each CRC value to 0.

  • Page 122: Traffic Channel A Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Add. Bit Error Selects whether or not an error of 1% is added to the Information or Physical data pattern. <When Forward Is Set to RC1 or RC2> FCH(TRCH A) Setup Displays the Traffic Channel A Parameter Setup dialog box.

  • Page 123: Traffic Channel B Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Figure 6-26 Traffic Channel B Parameter Setup Dialog Box DATA Selects the data pattern input to the realtime coder (Information data) or the data pattern input to the spreading section (Physical data).

  • Page 124: Traffic Channel A Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference DATA Selects the data pattern input to the realtime coder (Information data) or the data pattern input to the spreading section (Physical data). PN9: Selects a 9-stage PN code data pattern. PN15: Selects a 15-stage PN code data pattern.

  • Page 125: Traffic Channel B Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Rep. Pattern Specifies a value [in hexadecimal] for the arbitrarily set four bits. Selects a type of CRC to be added to the channel data. Sets each CRC value correctly. OFF: Sets each CRC value to 0.

  • Page 126: Traffic Channel C Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Add. Bit Error Selects whether or not an error of 1% is added to the Information or Physical data pattern. <When Forward Is Set to RC3, RC4 or RC5> SCH(TRCH C) Setup Displays the Traffic Channel C Parameter Setup dialog box.

  • Page 127: Frequency Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Figure 6-31 Frequency Parameter Setup Dialog Box Freq Input Selects the frequency entry mode. FREQUENCY: Directly enters a frequency value. CHANNEL No: Enters a channel number. CH Start Freq. Sets the channel start frequency. CH Step Freq.

  • Page 128: Clock/Timing Signal Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference ALC Mode Selects the ALC operating mode. Automatically selects the optimum operating mode depending on the R3562 settings. (For details, refer to the R3562 Operation manual.) AUTO: Normal ALC S/H: Sample and hold using the reference modulation pat- tern.
  • Page 129 R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference INTERNAL: Uses the internal reference signal. 10MHz Ref Adj. Sets internal reference signal’s frequency difference to be correct- MOD-TB In Selects the reference signal used for the modulation. 1 MHz: Uses an external signal of 1 MHz.

  • Page 130: External I/Q Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference Figure 6-34 External I/Q Parameter Setup Dialog Box I/Q Direction Exchanges the external IQ terminals between the input and output and selects the IQ signal paths to the IQ modulator. OFF: Turns off the IQ output, and inputs the internal baseband signal to the IQ modulator.

  • Page 131: Save Register List Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.2 Reference OFF: Does not perform the calibration correction. Modulator The IQ-modulator balance calibration is conducted. The correc- tion data obtained from the calibration is ready to be used when the calibration has been completed. Modulator Cal Corr Toggles the modulator calibration correction mode on or off.

  • Page 132: Connecting The Dut

    R3267 Series Option08 Rx Control Option Operation Manual 6.3 Setup Example Setup Example In this example, the output signals from the R3562, which are used for Reverse Link channel’s FER mea- surements, are set. Measurement conditions: The items to be measured are shown below. Set appropriate values for each measurement.

  • Page 133: Std Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.3 Setup Example Press Modulation and STD Setup. The STD Parameter Setup dialog box is displayed. Figure 6-38 STD Parameter Setup Dialog Box Set the following items. I/Q direction:OFF Link:REVERSE Radio Config:RC1 Press Clock &...
  • Page 134 R3267 Series Option08 Rx Control Option Operation Manual 6.3 Setup Example Set the following items. Synthe Ref In:INTERNAL MOD-TB In [MHz]: 19.6608 Press General Setup. The General Parameter Setup dialog box is displayed. Figure 6-40 General Parameter Setup Dialog Box 10.

  • Page 135: Frame Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.3 Setup Example Figure 6-41 Frame Parameter Setup Dialog Box <Reverse: RC1> 12. Set the following items. Coding Channel:FCH(A) [FCH(A)]: Frame: 20msec Rate [kbps]: FEC: CONVO 6-49...

  • Page 136: Traffic Channel A Parameter Setup Dialog Box

    R3267 Series Option08 Rx Control Option Operation Manual 6.3 Setup Example 13. Press more 2/2 and FCH(TRCH A) The Traffic Channel A Parameter Setup dialog box is displayed. Figure 6-42 Traffic Channel A Parameter Setup Dialog Box 14. Set the following items. Data:PN9 CRC:ON Block Inter lever:ON...

  • Page 137: Alphabetical Index

    ALPHABETICAL INDEX R3267 Series Option08 Rx Control Option Operation Manual ALPHABETICAL INDEX [Symbol] 6-35, 6-36, 6-37, 6-38, [Channel Power Ratio] ......5-6, 5-13 6-39, 6-40 [DCCH] ........... 5-7, 5-18, ALC Mode ..........4-5, 4-12, 5-20, 6-6, 5-8, 5-23, 6-8, 6-17, 6-10, 6-42 6-26 Average Times ........
  • Page 138 R3267 Series Option08 Rx Control Option Operation Manual Alphabetical Index 5-8, 5-22, 6-38, 6-39, 6-10, 6-41 6-40 CH Start No..........4-5, 4-11, Data ............5-6, 5-7, 5-8, 5-22, 5-9, 5-17, 6-10, 6-41 5-18, 5-20, CH Step Freq.......... 4-5, 4-11, 6-6, 6-9, 5-8, 5-22, 6-11...
  • Page 139 R3267 Series Option08 Rx Control Option Operation Manual Alphabetical Index 6-10, 6-43 6-21 EXT Trigger ..........6-14, 6-15 Ext Trigger ..........5-7, 5-21 Ext Trigger Setup ........5-7, 5-21 How to connect to R3560, R3561 External Trigger ........6-6 or R3562 ..........2-2 HOW TO OPERATE THE R3560 ..
  • Page 140 R3267 Series Option08 Rx Control Option Operation Manual Alphabetical Index Mode ............3-3, 3-9 Pattern ............. 3-3 MOD-TB In ..........5-6, 5-8, P-CCPCH ..........5-6 5-10, 5-24, PICH Setup ..........6-9, 6-32 6-6, 6-10, PN Offset ..........4-4, 4-5, 6-12, 6-43 4-8, 6-6, Modulation ..........
  • Page 141 R3267 Series Option08 Rx Control Option Operation Manual Alphabetical Index TPC Repeat Count ........5-7, 5-17, 5-19 SACCH ........... 3-3, 3-13 Traffic PRBS ........... 4-4, 4-9 Save ............3-3, 3-16, Trig Polarity ..........3-3, 3-10, 4-5, 4-16, 5-7, 5-21 5-8, 5-25, Trigger Delay ..........
  • Page 142 (3) You may not reverse engineer, de-compile, or disassemble, all or any part of, the SOFTWARE. Liability ADVANTEST shall have no liability (1) for any PRODUCT failures, which may arise out of any misuse (misuse is deemed to be use of the SOFTWARE for purposes other than it's intended use) of the SOFTWARE.

  • Page 143: Limited Warranty

    Product. 3. If the Product is found to be defective during the Warranty Period, ADVANTEST will, at its option and in its sole and absolute discretion, either (a) repair the defective Product or part or component thereof or (b) replace the defective Product or part or component thereof, in either case at ADVANTEST s sole cost and expense.
  • Page 144 Product, the Product may not be repairable. Please contact the nearest ADVANTEST office listed at the end of this Operation Manual or ADVANTEST...
  • Page 145 SALES & SUPPORT OFFICES Advantest America Measuring Solutions, Inc. (North America) New Jersey Office 258 Fernwood Avenue, Edison, NJ 08837 Phone: (1) (732) 346-2600 Facsimile: (1) (732) 346-2610 Santa Clara Office 3201 Scott Blvd., Santa Clara, CA 95054 Phone: (1) (408) 988-7700 Facsimile: (1) (408) 987-0688 ROHDE &...

This manual is also suitable for:

R3267R3273

Table of Contents
