Cover
R3267 Series OPT11
3GPP Level Calibration
Operation Manual
MANUAL NUMBER
FOE-8370635B01
Applicable
R3264
R3267
R3273
First printing December 25, 2000
2000
C
ADVANTEST CORPORATION
All rights reserved.
Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R3264 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADVANTEST R3264

Summary of Contents for ADVANTEST R3264

  • Page 1 Cover R3267 Series OPT11 3GPP Level Calibration Operation Manual MANUAL NUMBER FOE-8370635B01 Applicable R3264 R3267 R3273 First printing December 25, 2000 2000 ADVANTEST CORPORATION All rights reserved. Printed in Japan...
  • Page 2 Note that Advantest bears absolutely no responsibility for the result of operations caused due to incorrect or inappropriate use of this instrument. If the equipment is used in a manner not specified by Advantest, the protection provided by the equipment may be impaired.
  • Page 3 Note that the estimated lifespan for the parts listed below may be shortened by factors such as the environment where the instrument is stored or used, and how often the instrument is used. The parts inside are not user-replaceable. For a part replacement, please contact the Advantest sales office for servicing.
  • Page 4 Safety Summary Main Parts with Limited Life Part name Life Unit power supply 5 years Fan motor 5 years Electrolytic capacitor 5 years LCD display 6 years LCD backlight 2.5 years Floppy disk drive 5 years • Hard Disk Mounted Products The operational warnings are listed below.
  • Page 5 Environmental Conditions This instrument should be only be used in an area which satisfies the following conditions: • An area free from corrosive gas • An area away from direct sunlight • A dust-free area • An area free from vibrations Direct sunlight Dust Corrosive...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS R3267 Series OPT11 3GPP Level Calibration Operation Manual TABLE OF CONTENTS INTRODUCTION ..................Product Description ................... Accessories ......................Precautions in Use ..................... Calibration ......................OPERATION ....................3GPP Level Calibration Data and the Setting Conditions ........ Using 3GPP Level Calibration Data ..............Measurement Sample ..................
  • Page 7 R3267 Series OPT11 3GPP Level Calibration Operation Manual LIST OF ILLUSTRATIONS Title Page Installed Option Labels ..................... 2 GHz Modulation Signal Measurement Sample (Using the 3GPP Level Calibration Function) ..............Setup of Level Calibration Test ..................
  • Page 8 R3267 Series OPT11 3GPP Level Calibration Operation Manual LIST OF TABLES Title Page Frequency Range for 3GPP Level Calibration Data and the Frequency ......Setting Conditions Used for 3GPP Level Calibrations ............. 3GPP Level Calibration (OPT11) ..................Equipment List ........................List for SG and PM Correction Data Setting ..............

  • Page 9: Introduction

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 1. INTRODUCTION INTRODUCTION This chapter includes a product overview, information on the accessories, and notes on using this option and the calibration intervals. Product Description This option is designed to improve the Tx power measurement level accuracy in the 2 GHz band (1.8483 GHz to 2.1717 GHz) when the 3GPP level calibration option (OPT 11) is installed in the R3267 Series Spec- trum Analyzer.

  • Page 10: Calibration

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 1.4 Calibration Performing a calibration A calibration must be performed in order to improve the level accuracy of Tx Power measurement using the 3GPP level calibration function. CAUTION: The R3267 Series should be warmed up for at least 60 minutes before performing a calibration for OPT 11.

  • Page 11: Operation

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 2. OPERATION OPERATION This chapter describes 3GPP level calibration data and setting conditions, operating methods and provides measurement examples. 3GPP Level Calibration Data and the Setting Conditions Table 2-1 shows the frequency range for 3GPP level calibration data and the frequency interval between cal- ibrations.

  • Page 12: Using 3Gpp Level Calibration Data

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 2.2 Using 3GPP Level Calibration Data Using 3GPP Level Calibration Data Select whether or not 3GPP level calibration data is used. NOTE: The initial setting after the PRESET sets Level Cal Correction to ON. Press TRANSIENT and STD.

  • Page 13: Measurement Sample

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 2.3 Measurement Sample Measurement Sample A method of measuring 2-GHz modulation signal Tx power, which uses 3GPP level calibration data, is explained in this sample. Resetting the settings Press SHIFT and CONFIG(PRESET). The initial settings are read.
  • Page 14 R3267 Series OPT11 3GPP Level Calibration Operation Manual 2.3 Measurement Sample Press SINGLE. The modulation signal power is measured. The level of the modulation signal is displayed on the R3267 Series screen. Figure 2-1 2 GHz Modulation Signal Measurement Sample (Using the 3GPP Level Calibration Function)

  • Page 15: Reference

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 3. REFERENCE REFERENCE This chapter describes the keys used with the 3GPP level calibration option (OPT 11). For information on the other keys, refer to Section 3.3, “Functional Description” in R3267 Series Spectrum Analyzer Operation Manual.

  • Page 16: Menu Map

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 3.2 Menu Map Menu Map TRANSIENT Level Cal Correction ON/OFF Functional Description This section describes the keys used with the 3GPP level calibration option (OPT 11). 3.3.1 STD Menu Press the TRANSIENT and STD keys displays Level Cal Correction ON/OFF is displayed. Level Cal Correction ON/OFF Toggles the level correction function on or off.

  • Page 17: Remote Programming

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 4. REMOTE PROGRAMMING REMOTE PROGRAMMING A list of GPIB codes required for remote control is shown in this section. GPIB Command Index This GPIB command index can be used as the index for this Chapter. GPIB Command Pages LCALCORR OFF........

  • Page 18: Gpib Command Codes

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 4.2 GPIB Command Codes GPIB Command Codes The following table list the GPIB commands by function. Table 4-1 3GPP Level Calibration (OPT11) Talker Request Function Listener Code Code Output Format Level Cal Correction Level Cal Correction LCALCORR ON...

  • Page 19: Performance Verification Test

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 5. PERFORMANCE VERIFICATION TEST PERFORMANCE VERIFICATION TEST A list of GPIB codes required for remote control is shown in this section. GENERAL 5.1.1 Introduction This chapter provides R3267 Series OPT11 performance verification test procedures. 5.1.2 Test Equipment The Table 5-1 lists recommended test equipment.

  • Page 20: Performance Verification Test Record Sheet

    Output Level: -15 dBm to +10 dBm Option B11 Schwarz Aging Rate: 1 x 10 exp-6/year Impedance: 50 Ω RF Cable A01002 Advantest RF_CBL1 Connector Type: SMA(m)-SMA(m) Frequency Range: DC to 3.0 GHz VSWR: ≤ 1.1 Length: 0.7 m approx. Impedance: 50 Ω...

  • Page 21: 5.1.4 Performance Verification Procedure

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 5.1.4 Performance Verification Procedure 5.1.4 Performance Verification Procedure Typeface conventions used in this manual. *Panel keys and soft keys are printed in a contrasting typestyle to make them stand out from the text as follows: Panel keys: Boldface type Example: FREQ, FORMAT...

  • Page 22: Performance Verification Test Procedure

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 5.2 Performance Verification Test Procedure Performance Verification Test Procedure 5.2.1 Level Calibration Description Measure level calibration measurement accuracy for 3GPP system. Firstly measure a signal generator output signal level for several testing points by using RF power meter and RF power sensor as reference data.

  • Page 23: Setup Of Level Calibration Test

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 5.2.1 Level Calibration Setup Figure 5-1 Setup of Level Calibration Test Procedure Part 1 Measuring SG output level On the PM, set dBm display mode. On the PM, perform ZERO. Connect equipment as shown in Figure 5-1. On the SG, set control as follow;...

  • Page 24: List For Sg And Pm Correction Data Setting

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 5.2.1 Level Calibration 10. Repeat steps 8. through 9. for each frequency listed on Table 5-2. Table 5-2 List for SG and PM Correction Data Setting SG Output Frequency (GHz) PM Correction Data (GHz) 1.9473 1.9473 2.0001...

  • Page 25: Setting Of Sg And R3267 Series

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 5.2.1 Level Calibration 21. Record the measurement result in the Tx Power column on the performance ver- ification test record sheet. 22. Calculate measurement accuracy subtracting PM measurement result from Tx Power. Record the result in the actual column on the performance verification test record sheet.

  • Page 26: Performance Verification Test Record Sheet

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 5.3 Performance Verification Test Record Sheet Performance Verification Test Record Sheet ATT=10 dB Specification Result Measured value of power R3267 Series Tx Power Measured error meter (dBm) Measured value(dBm) Frequency (GHz) Min. (dB) Max.
  • Page 27 R3267 Series OPT11 3GPP Level Calibration Operation Manual 5.3 Performance Verification Test Record Sheet ATT=50 dB Specification Result Measured value of power R3267 Series Tx Power Measured error meter (dBm) Measured value(dBm) Frequency (GHz) Min. (dB) Max. (dB) Pass/Fail (dB) 1.8483 -0.4 1.9011...

  • Page 28: Specifications

    R3267 Series OPT11 3GPP Level Calibration Operation Manual 6. SPECIFICATIONS SPECIFICATIONS The specifications for the 3GPP level calibration option (OPT 11) are shown below. Calibration frequency range 1848.3 MHz to 2171.7 MHz Level measurement range +25 dBm to -60 dBm ≤...

  • Page 29: Appendix

    R3267 Series OPT11 3GPP Level Calibration Operation Manual APPENDIX A.1 Error Message List Code Error message Description Invalid Level Cal Correction data. Contact qualified engineer.

  • Page 30: Alphabetical Index

    ALPHABETICAL INDEX ALPHABETICAL INDEX R3267 Series OPT11 3GPP Level Calibration Operation Manual ALPHABETICAL INDEX [Numerics] 3GPP Level Calibration Data ....2-2 REFERENCE .......... 3-1 3GPP Level Calibration Data and REMOTE PROGRAMMING ....4-1 the Setting Conditions ......2-1 SPECIFICATIONS ......... 6-1, A-1 Accessories ..........
  • Page 31 (3) You may not reverse engineer, de-compile, or disassemble, all or any part of, the SOFTWARE. Liability ADVANTEST shall have no liability (1) for any PRODUCT failures, which may arise out of any misuse (misuse is deemed to be use of the SOFTWARE for purposes other than it's intended use) of the SOFTWARE.
  • Page 32 Product. 3. If the Product is found to be defective during the Warranty Period, ADVANTEST will, at its option and in its sole and absolute discretion, either (a) repair the defective Product or part or component thereof or (b) replace the defective Product or part or component thereof, in either case at ADVANTEST s sole cost and expense.
  • Page 33 Product, the Product may not be repairable. Please contact the nearest ADVANTEST office listed at the end of this Operation Manual or ADVANTEST...
