Port Pinouts

This section describes pin functions for port connectors on the rear of the system.

VGA Port Connector

The VGA port provides an interface to a VGA terminal. Table 9–1 lists pin assignments
for the VGA port.
Table 9–1: VGA Port Pinouts
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
9-6 AlphaServer 1000A Rackmount Owner's Guide
Signal Function
Red Red color driver
Green Green color driver
Blue Blue color driver
NC Not connected
GNDB Video ground
GNDB Video ground
GNDB Video ground
GNDB Video ground
NC Not connected
GNDB Video ground
NC Not connected
NC Not connected
HSYNC Horizontal synch
VSYNC Vertical synch
NC Not connected
